NEET-PG 2019 - Radiology PYQs Practice Questions

Q: Boot shape of heart in TOF is due to:

Right ventricular hypertrophy. ***Right ventricular hypertrophy*** - The characteristic **boot-shaped heart (coeur en sabot)** seen in Tetralogy of Fallot (TOF) on a chest X-ray is primarily due to **right ventricular hypertrophy** and the small pulmonary artery. - The hypertrophied right ventricle lifts the cardiac apex, while the concavity in the area of the pulmonary artery (due to **pulmonary stenosis**) gives the heart its distinctive shape. *Enlargement of the left atrium* - Left atrial enlargement is not a feature of **Tetralogy of Fallot**; in fact, chronic pulmonary outflow obstruction often leads to a relatively normal or small left atrium. - This condition involves right-sided heart abnormalities, and left atrial enlargement would suggest increased left-sided pressures, which are not typical for TOF. *Enlargement of the right atrium* - While right atrial enlargement can occur in severe cases of TOF due to increased resistance to blood flow, it is **right ventricular hypertrophy** that is the primary determinant of the classic boot-shaped cardiac silhouette. - Right atrial enlargement alone does not create the specific "boot" appearance which is largely due to the ventricular contour. *Hypertrophy of both ventricles* - In Tetralogy of Fallot, the primary ventricular abnormality is **right ventricular hypertrophy**, driven by the need to pump blood through a stenosed pulmonary artery. - The left ventricle typically maintains a normal size and function, as it primarily pumps into the systemic circulation and is not directly affected by the primary defects in the same way as the right ventricle. [Practice more Radiology PYQs on OnCourse]

Q: Identify the condition in the image below?

Lacunar infarct. ***Lacunar infarct*** - The image displays a small, well-demarcated **hypodensity** (darker area) in the basal ganglia region, characteristic of a lacunar infarct. - Lacunar infarcts are typically caused by **occlusion of small perforating arteries** and result in small, deep infarcts, often appearing as precise, round or ovoid lesions on CT. *Embolic infarct* - Embolic infarcts tend to be **larger**, wedge-shaped, and often extend to the cortical surface, unlike the deep, small lesion seen. - They are commonly associated with a **cardiac source** or large artery atherosclerosis leading to distal embolization. *Thrombotic infarct* - Thrombotic infarcts are usually **larger** areas of infarction due to occlusion of a major artery, often preceded by symptoms like TIAs. - While they also appear hypodense, they are typically **more extensive** and less precisely defined than a lacunar infarct in the early stages. *Intracerebral hemorrhage* - Intracerebral hemorrhage would appear as a **hyperdense** (bright white) area on a non-contrast CT scan due to the presence of acute blood. - The image clearly shows a **hypodense lesion**, ruling out acute hemorrhage. [Practice more Radiology PYQs on OnCourse]

Q: Identify the radiological procedure shown in the image?

Barium meal follow through. ***Barium meal follow through*** - The image shows opacification of the stomach and the entire small bowel loops via oral uptake of a contrast agent, which is characteristic of a **barium meal follow-through**. - This procedure tracks the passage of **barium** from the esophagus, stomach, and duodenum, through the jejunum and ileum, to assess the **small intestine's morphology and function**. *Barium enema* - A **barium enema** involves introducing contrast material rectally to visualize the **colon and rectum**, which is not depicted in this image. - The primary structures opacified in a barium enema are the **large intestine**, not the stomach and small bowel as seen here. *Enteroclysis* - **Enteroclysis** is a specialized study of the small bowel where contrast is directly instilled into the **duodenum** or **proximal jejunum** via a nasoenteric tube. - While it visualizes the small bowel, the image shows oral contrast progression from the stomach, not direct jejunal intubation. *Proctography* - **Proctography**, also known as defecography, is a dynamic study focused specifically on the **rectum and anal canal** during defecation. - This procedure is highly specific to the distal gastrointestinal tract for assessing anorectal function and does not visualize the stomach or extensive small bowel loops. [Practice more Radiology PYQs on OnCourse]

Q: Which of the following is water soluble contrast?

Iodine. ***Iodine*** - **Iodinated contrast media** (containing iodine atoms) are the most commonly used **water-soluble contrast agents** in medical imaging. - Examples include **non-ionic iodinated compounds** (iohexol, iopamidol, iopromide) and **ionic compounds** (diatrizoate, iothalamate). - The **iodine atoms** provide radiodensity (X-ray attenuation), while the organic molecular structure ensures **water solubility**. - These agents are safely excreted by the kidneys and are used intravenously for CT angiography, intravenous urography, and contrast-enhanced CT scans. *Barium* - **Barium sulfate** is a **water-insoluble** compound used as an oral or rectal contrast agent for imaging the gastrointestinal tract. - It remains in the GI lumen and is not absorbed; if extravasated into soft tissues, it can cause significant inflammatory reactions. - Used for barium swallow, barium meal, barium follow-through, and barium enema studies. *Bromine* - **Bromine** is not used as a contrast agent in medical imaging due to its high toxicity and unsuitability for diagnostic purposes. - It does not form stable, non-toxic water-soluble compounds appropriate for clinical imaging. *Calcium* - **Calcium** is a natural component of bone and provides intrinsic radiodensity on plain X-rays. - It is not administered as an exogenous contrast agent for diagnostic imaging purposes. [Practice more Radiology PYQs on OnCourse]

Q: Identify the condition based on the provided image.

Callosal dysgenesis. ***Callosal dysgenesis*** - The image shows **colpocephaly**, characterized by **dilatation of the posterior horns** of the lateral ventricles and narrowing of the anterior horns. This is a classic MRI finding in callosal dysgenesis. - The absence or partial formation of the **corpus callosum** leads to a high-riding third ventricle and parallel lateral ventricles, which are often visualized alongside colpocephaly. *Dandy-Walker syndrome* - Characterized by a **cystic dilatation of the fourth ventricle** that fills the posterior fossa, leading to an upward displacement of the tentorium. - This condition involves agenesis or hypoplasia of the **cerebellar vermis**, which is not depicted in this image. *Aicardi syndrome* - Aicardi syndrome is characterized by the triad of **agenesis of the corpus callosum**, **chorioretinal lacunae**, and **infantile spasms**. - While it includes agenesis of the corpus callosum, the image alone does not provide evidence of the ocular or seizure components of Aicardi syndrome. *Septo-optic dysplasia* - This condition is defined by the **triad of optic nerve hypoplasia**, **pituitary hormone abnormalities**, and **midline brain defects**, specifically hypoplasia or absence of the septum pellucidum. - The image does not show features specific to optic nerve hypoplasia or the typical midline cysts or absent septum pellucidum characteristic of septo-optic dysplasia. [Practice more Radiology PYQs on OnCourse]

Question 1

Boot shape of heart in TOF is due to:

Accepted Answer

Right ventricular hypertrophy

Answer

Enlargement of the left atrium

Answer

Enlargement of the right atrium

Answer

Hypertrophy of both ventricles

Question 2

Identify the condition in the image below?

Accepted Answer

Lacunar infarct

Answer

Embolic infarct

Answer

Thrombotic infarct

Answer

Intracerebral hemorrhage

Question 3

Identify the radiological procedure shown in the image?

Accepted Answer

Barium meal follow through

Answer

Barium enema

Answer

Enteroclysis

Answer

Proctography

Question 4

Which of the following is water soluble contrast?

Accepted Answer

Iodine

Answer

Barium

Answer

Bromine

Answer

Calcium

Question 5

Identify the condition based on the provided image.

Accepted Answer

Callosal dysgenesis

Answer

Dandy-Walker syndrome

Answer

Aicardi syndrome

Answer

Septo-optic dysplasia

Question 6

Identify the most likely diagnosis based on the chest X-ray findings in a patient with low-grade fever.

Accepted Answer

Miliary TB

Answer

ILD

Answer

Bronchopneumonia

Answer

Consolidation

Question 7

What is the most likely finding in the CT image of the left maxillary sinus in a patient with a history of allergic rhinitis?

Accepted Answer

Ground-glass opacity

Answer

Honeycomb appearance

Answer

Onion peel appearance

Answer

Double density

Question 8

A female patient presented with recurrent urinary tract infections. What is the most probable diagnosis based on the imaging findings?

Accepted Answer

Ureterocele

Answer

Congenital megaureter

Answer

Urinary stones

Answer

Ureteral duplication

Question 9

A 75-year-old female has chronic backache. X-ray of the spine is shown. What is the most likely diagnosis?

Accepted Answer

Osteoporosis

Answer

Spondylodiscitis

Answer

Pott's spine

Answer

Spondylolisthesis

Question 10

Gas absent from intestine (gasless abdomen) on x-ray is seen in which condition?

Accepted Answer

Acute pancreatitis

Answer

Ulcerative colitis

Answer

Intussusception

Answer

Necrotizing enterocolitis
