Radiographic Anatomy of Bones and Joints Indian Medical PG Practice Questions and MCQs
Question 1: Epiphyseal tumor before fusion of epiphysis:
- A. Chondrosarcoma
- B. Chondroblastoma (Correct Answer)
- C. Giant cell tumor
- D. Ewing's sarcoma
Explanation: ***Chondroblastoma*** - This is primarily an **epiphyseal tumor** that occurs predominantly in adolescents and young adults **before epiphyseal fusion**. - It is a **benign cartilaginous tumor** that typically presents with pain and swelling around the affected joint. *Chondrosarcoma* - This is a **malignant cartilaginous tumor** that typically occurs in older adults, usually after epiphyseal fusion. - While it can occur in various bones, it is generally found in the **metaphysis or diaphysis**, not primarily the epiphysis before fusion. *Giant cell tumor* - This tumor is typically found in the **epiphysis/metaphysis** but primarily occurs in skeletally mature individuals **after epiphyseal closure**. - It is characterized by its aggressive nature and high recurrence rate, but is less common before epiphyseal fusion. *Ewing's sarcoma* - This is a highly **malignant bone tumor** that primarily affects the **diaphysis** of long bones and flat bones. - It is common in children and young adults but is not characteristically an epiphyseal tumor before fusion.
Question 2: CT numbers of water and bone are respectively:
- A. 100,0
- B. +1000,-100
- C. 0, + 1000 (Correct Answer)
- D. 0,-1000
Explanation: ***0, + 1000*** - The **CT number (Hounsfield Unit)** for **water** is defined as **0**, serving as a reference point for all other tissues in CT imaging. - **Bone**, particularly **cortical bone**, has a high density and thus corresponds to a CT number of approximately **+1000 HU**. *100,0* - This option incorrectly assigns a CT number of **100 to water**, which is fundamentally incorrect as water is defined as **0 HU**. - It also assigns **0** to **bone**, which is the CT number for water, not bone. *+1000,-100* - This option correctly identifies **+1000 HU** for dense bone but incorrectly assigns **-100 HU to water**, which is the CT number typically associated with fat, not water. *0,-1000* - While **0 HU** is correct for water, **-1000 HU** is the CT number for **air**, not bone. - Bone has a high positive CT number due to its high density, whereas air has a very low negative CT number.
Question 3: The image shows a highlighted region on the dorsal aspect of the hand (anatomical snuffbox). Which of the following anatomical structures form the boundaries or floor of this region?
- A. Abductor pollicis longus muscle.
- B. Styloid process of the radius.
- C. Extensor pollicis longus muscle.
- D. All of the above anatomical structures. (Correct Answer)
Explanation: ***All of the above anatomical structures.*** - The image highlights the **anatomical snuffbox**, a triangular depression on the radial dorsal aspect of the hand. Its boundaries are formed by the tendons of the **extensor pollicis longus muscle** (ulnar side), and the **abductor pollicis longus** and **extensor pollicis brevis muscles** (radial side). - The **styloid process of the radius** forms the floor of the anatomical snuffbox along with the scaphoid and trapezium bones. All the options listed are key anatomical features associated with this region. *Extensor pollicis longus muscle.* - This muscle forms the **ulnar (medial) border** of the anatomical snuffbox. - Its tendon can be palpated during **thumb extension** and contributes to the overall structure of the highlighted area. *Abductor pollicis longus muscle.* - This muscle, along with the extensor pollicis brevis, forms the **radial (lateral) border** of the anatomical snuffbox. - Its tendon is visible and palpable on the radial side of the highlighted region when the thumb is abducted. *Styloid process of the radius.* - This bony prominence is located at the **distal end of the radius** on the radial side of the wrist. - It forms part of the **proximal floor** of the anatomical snuffbox, contributing to its definition.
Question 4: Osteoarthritis is associated with all of the following except -
- A. Subchondral sclerosis
- B. Ca++deposition in joint space (Correct Answer)
- C. Osteophyte formation
- D. Decreased joint space
Explanation: ***Ca++deposition in joint space*** - **Calcium pyrophosphate dihydrate (CPPD) crystal deposition** in the joint space is characteristic of **pseudogout**, not osteoarthritis [1]. - While some **calcification** may occur in osteophytes, direct **calcium crystal deposition** in the synovial fluid is not a primary feature of osteoarthritis [1]. *Subchondral sclerosis* - **Subchondral sclerosis** refers to the increased bone density that occurs beneath the cartilage in areas of stress in osteoarthritis. - This is a common radiological finding in osteoarthritis, reflecting the bone's response to increased mechanical load. *Osteophyte formation* - **Osteophytes** (bone spurs) are bony projections that form along the joint margins in osteoarthritis [2]. - They are a hallmark feature of the disease, resulting from the body's attempt to repair and stabilize the damaged joint [2]. *Decreased joint space* - **Decreased joint space** on radiographs is a classic sign of osteoarthritis, indicating loss of articular cartilage thickness [2]. - As the cartilage erodes, the distance between the bones within the joint decreases. **References:** [1] Cross SS. Underwood's Pathology: A Clinical Approach. 6th ed. Common Clinical Problems From Osteoarticular And Connective Tissue Disease, pp. 683-684. [2] Kumar V, Abbas AK, et al.. Robbins and Cotran Pathologic Basis of Disease. 9th ed. Bones, Joints, and Soft Tissue Tumors, pp. 1210-1212.
Question 5: In which of the following conditions is joint erosion NOT a primary feature?
- A. Psoriatic arthropathy
- B. Rheumatoid arthritis
- C. Osteoarthritis
- D. SLE (Correct Answer)
Explanation: ***SLE*** - While arthritis is common in **Systemic Lupus Erythematosus (SLE)**, it is typically **non-erosive**, meaning it does not cause damage to the **cartilage** or **bone** [1]. - Joint involvement in SLE is often characterized by **arthralgias** or a **reversible inflammatory arthritis**. *Osteoarthritis* - **Osteoarthritis** is definitively characterized by the **progressive erosion of articular cartilage**, leading to **bone-on-bone friction** and structural changes. - This condition involves **wear-and-tear** that directly causes damage to the joint surfaces. *Psoriatic arthropathy* - **Psoriatic arthropathy** (Psoriatic Arthritis) is an inflammatory condition that can lead to significant **joint erosion** and **destruction**, particularly in the small joints of the hands and feet [1]. - It often features characteristic radiographic changes such as **"pencil-in-cup" deformities** due to bone resorption and erosion [1]. *Rheumatoid arthritis* - **Rheumatoid arthritis** is a classic example of an inflammatory arthritis where **joint erosion** is a primary and hallmark feature, driven by **synovial inflammation** and pannus formation. - Persistent inflammation in RA leads to **cartilage destruction** and **subchondral bone erosion**.
Question 6: Which of the following is not a feature of ankylosing spondylitis?
- A. Morning stiffness is a feature of ankylosing spondylitis.
- B. Improvement with exercise is a feature of ankylosing spondylitis.
- C. Asymmetric joint involvement (Correct Answer)
- D. Pain relief with NSAIDs is a feature of ankylosing spondylitis.
Explanation: ***Asymmetric joint involvement*** - While ankylosing spondylitis can involve peripheral joints, the axial skeletal involvement (sacroiliac joints and spine) is typically **symmetric** [1]. - **Asymmetric joint involvement** is more characteristic of other spondyloarthropathies, such as **psoriatic arthritis** or **reactive arthritis** [1]. *Morning stiffness is a feature of ankylosing spondylitis* - Patients with ankylosing spondylitis frequently experience significant **morning stiffness**, often lasting more than 30 minutes, which is a classic symptom of inflammatory back pain [2]. - This stiffness is due to the characteristic **inflammation** of the axial skeleton, particularly the sacroiliac joints and spine. *Improvement with exercise is a feature of ankylosing spondylitis* - The back pain and stiffness associated with ankylosing spondylitis typically **improve with activity and exercise**, distinguishing it from mechanical back pain which often worsens with movement [2]. - Regular physical activity helps to reduce the **stiffness and discomfort** by promoting joint mobility. *Pain relief with NSAIDs is a feature of ankylosing spondylitis* - Nonsteroidal anti-inflammatory drugs (**NSAIDs**) are often very effective in providing **significant pain relief** for patients with ankylosing spondylitis, especially early in the disease course [3]. - Their effectiveness in reducing pain and inflammation is a key diagnostic clue and a cornerstone of initial symptomatic treatment.
Question 7: A radiograph is obtained from a child with scoliosis. What is the name of the angle used to measure spinal curvature?
- A. Bohler's Angle
- B. Ferguson's Angle
- C. Cobb's Angle (Correct Answer)
- D. Pauwels' Angle
Explanation: **Cobb's Angle** - **Cobb's angle** is the primary method for measuring the severity of **scoliosis** on radiographs. - It is measured by drawing lines parallel to the superior endplate of the most tilted superior vertebra and the inferior endplate of the most tilted inferior vertebra of the curve; the angle between these two lines (or their perpendiculars) is the Cobb angle. *Bohler's Angle* - **Bohler's angle** is used in the assessment of **calcaneus fractures** and is measured on a lateral foot radiograph. - A decrease in this angle is indicative of a calcaneal fracture. *Ferguson's Angle* - **Ferguson's angle**, also known as the lumbosacral angle, measures the inclination of the sacrum relative to the horizontal in the standing position. - It is primarily used in the assessment of **spondylolisthesis** and other lumbosacral conditions. *Pauwels' Angle* - **Pauwels' angle** is used to classify **femoral neck fractures** based on the angle of the fracture line relative to the horizontal. - It helps determine the severity and stability of femoral neck fractures, guiding treatment decisions.
Question 8: A 7-year-old child presents with a lesion in upper tibia. X-ray shows radiolucent area with Codman's triangle and sunray appearance. Diagnosis is
- A. Osteosarcoma (Correct Answer)
- B. Osteoid Osteoma
- C. Ewing sarcoma
- D. Chondrosarcoma
Explanation: ***Osteosarcoma*** - The classic radiographic features of **Codman's triangle** (periosteal elevation) and **sunray appearance** (spiculated periosteal reaction) are highly characteristic of osteosarcoma. - This tumor commonly affects the **metaphysis of long bones** in children and young adults, with the distal femur and proximal tibia being frequent sites. *Osteoid Osteoma* - This is a **benign bone tumor** characterized radiographically by a small radiolucent **nidus** surrounded by a rim of dense sclerosis. - It does not present with Codman's triangle or sunray appearance and typically causes **nocturnal pain relieved by NSAIDs**. *Ewing sarcoma* - Ewing sarcoma often presents with an **"onion skin" periosteal reaction** (layers of new bone formation) due to its aggressive nature. - While it can be destructive and radiolucent, it typically does not classically exhibit the sunray appearance or a distinct Codman's triangle as prominently as osteosarcoma. *Chondrosarcoma* - Chondrosarcoma is a **malignant cartilaginous tumor** that usually affects older adults more commonly than children. - Radiographically, it often shows a **lobulated appearance** with **punctate or ring-and-arc calcifications** within the lesion, not the sunray or Codman's triangle findings.
Question 9: Holdsworth classification of thoracolumbar spine fracture is based on how many columns of spine?
- A. Two (Correct Answer)
- B. Three
- C. Four
- D. Five
Explanation: ***Two*** - The **Holdsworth classification** focuses on the **biomechanical stability** of the spine and divides the vertebral column into two main columns: the **anterior column** and the **posterior column**. - This classification was foundational for understanding spinal instability, particularly related to **flexion-rotation injuries**. *Three* - The **Denis classification** is based on a **three-column model** (anterior, middle, and posterior columns) and is more commonly used in current practice for describing thoracolumbar spine fractures. - While Denis expanded upon Holdsworth's ideas, Holdsworth himself only described two columns. *Four* - There is no widely recognized or primary classification system for thoracolumbar spine fractures that uses a **four-column model**. - Spinal fracture classifications primarily revolve around two- or three-column models, or more recently, morphological and neurological injury patterns (e.g., AO Spine classification). *Five* - A **five-column model** is not standard for classifying thoracolumbar spine fractures in medical literature. - Comprehensive classifications usually incorporate factors beyond just column numbers, such as injury morphology, neurological status, and integrity of the disc and ligaments.
Question 10: Radiographically, the lesion shown in the image could be:
- A. Cherubism
- B. Garre's osteomyelitis (Correct Answer)
- C. Fibrous dysplasia
- D. Osteosarcoma
Explanation: ***Garre's osteomyelitis*** - The radiographs show **periosteal new bone formation** resembling an **"onion skin"** appearance, which is characteristic of **Garre's osteomyelitis** (chronic osteomyelitis with proliferative periostitis). - This condition is typically a **reaction to low-grade chronic infection** or irritation, often seen in the periosteum of the mandible. *Cherubism* - Cherubism is a **fibro-osseous lesion** characterized by bilateral, symmetric enlargement of the jaws, giving a "cherubic" appearance. - Radiographically, it presents as **multilocular radiolucencies** with poorly defined borders, usually in children. *Fibrous dysplasia* - Fibrous dysplasia is a developmental anomaly where normal bone is replaced by **fibrous tissue and immature bone**. - Radiographically, it often has a **"ground glass" appearance** or a "peau d'orange" texture, differentiating it from the periosteal reaction seen in the image. *Osteosarcoma* - Osteosarcoma is a **malignant bone tumor** that typically shows a mix of osteolytic and osteoblastic areas, often with a **"sunburst" or "spiculated" periosteal reaction**. - While it involves periosteal reaction, the pattern and typical aggressive nature differ from the more layered and milder appearance of Garre's osteomyelitis.
