Thoracic Cage Sketch & Lines - Framework Foundations

  • Skeletal Framework:
    • Sternum: Manubrium (suprasternal notch, clavicular notches), Body, Xiphoid process.
    • Ribs: 12 pairs.
      • True ribs (1-7): Attach directly to sternum.
      • False ribs (8-10): Attach indirectly.
      • Floating ribs (11-12): No anterior attachment.
    • Thoracic Vertebrae: 12 (T1-T12).
  • Key Reference Lines:
    • Anterior: Midsternal, Midclavicular (MCL) - passes through midpoint of clavicle.
    • Lateral: Anterior Axillary (AAL), Midaxillary (MAL), Posterior Axillary (PAL).
    • Posterior: Scapular, Midvertebral.

⭐ The Sternal Angle (Angle of Louis) is a crucial landmark at the T4/T5 vertebral level, corresponding to the articulation of the 2nd rib. It marks the bifurcation of the trachea and the beginning/end of the aortic arch.

Anterior Thoracic Landmarks - Front-Row Seats

  • Suprasternal Notch (Jugular Notch):
    • Palpable U-shaped depression, superior manubrium.
    • Level: T2-T3 intervertebral disc.
  • Sternal Angle (Angle of Louis):
    • Manubriosternal joint; transverse ridge.
    • Articulates with 2nd rib / costal cartilage.
    • Level: T4-T5 intervertebral disc.
    • Key events: Tracheal bifurcation, aortic arch (start/end), azygos vein drains into SVC. ⭐> The Sternal Angle (Angle of Louis) is the most reliable landmark for identifying the 2nd rib and subsequently counting other ribs and intercostal spaces.
  • Xiphisternal Joint:
    • Inferior tip of sternum.
    • Level: T9 vertebra.
    • Marks: Inferior heart border, superior liver surface, central tendon of diaphragm.
  • Costal Margin:
    • Inferior edge of thoracic cage.
    • Formed by cartilages of ribs 7-10.
  • Nipple:
    • Males: Usually 4th intercostal space (ICS), midclavicular line (MCL).
    • Females: Position variable.
  • Midclavicular Line (MCL):
    • Vertical line from clavicle's midpoint.
    • Apex beat (PMI): Typically 5th ICS, just medial to left MCL.

Posterior & Lateral Landmarks - Backstage & Sidelines

  • Posterior:
    • Vertebral Spines:
      • C7 (Vertebra Prominens): Most prominent.
      • T3: Level with scapular spine.
      • T7: Level with inferior angle of scapula (arms at sides).
      • L4: Supracristal plane (Tuffier's line) at iliac crests.
    • Scapula:
      • Superior Angle: T2 level.
      • Spine: T3 spinous process.
      • Inferior Angle: T7 spinous process (varies T6-T9). Medial border.
  • Lateral:
    • Axillary Folds: Anterior (Pectoralis major), Posterior (Latissimus dorsi).
    • Axillary Lines: AAL, MAL, PAL for reference.
    • Ribs: Countable; 12th rib may be short.
    • Serratus Anterior: "Boxer's muscle".
    • Triangle of Auscultation: 📌 Mnemonic: LaTTeS (Latissimus, Trapezius, Scapula).

      ⭐ Borders: Latissimus dorsi, Trapezius, medial border of Scapula. Prime site for lung sounds (posterior lobes).

Visceral Projections & Clinical Hotspots - Organ Mapping

  • Lungs & Pleura:
    • Lung Apex: 2.5 cm above medial ⅓ clavicle.
    • Oblique Fissure: T3 spine → 6th CC.
    • Horizontal Fissure (R): 4th CC → oblique fissure (MAL, 5th rib).
    • Lung Inferior: Ribs 6 (MCL), 8 (MAL), 10 (Scapular).
    • Pleura Inferior: Ribs 8 (MCL), 10 (MAL), 12 (Paravertebral).
    • 📌 L2RAP: Lung 2 Ribs Above Pleura (inferiorly).
  • Heart:
    • Apex Beat: L 5th ICS, 9 cm from midsternum (MCL).
    • Borders: Sup (2L-3R CC), R (3-6R CC), L (2L CC-apex).
  • Tracheal Bifurcation: Sternal angle (T4/T5).
  • Clinical Hotspots:
    • Auscultation: Aortic R 2nd ICS, Pulm L 2nd ICS, Tricuspid L 4/5th ICS, Mitral L 5th ICS MCL.
    • Chest Drain: Triangle of Safety (4/5th ICS, ant. to MAL).
    • Pericardiocentesis: L 5/6th ICS parasternal/infrasternal.

⭐ The apex beat is normally located in the left 5th intercostal space, medial to the mid-clavicular line (approx. 9 cm from midsternum). Displacement indicates cardiomegaly or other conditions.

Loading diagram…

High‑Yield Points - ⚡ Biggest Takeaways

  • Sternal Angle (Louis): Key landmark at T4/T5 IV disc; 2nd rib articulation; tracheal bifurcation; aortic arch.
  • Suprasternal Notch: Palpable at T2/T3 vertebral level.
  • Xiphisternal Joint: T9 vertebra; marks inferior heart border, superior liver limit.
  • Apex Beat (PMI): 5th left ICS, medial to mid-clavicular line (MCL).
  • Nipple (Male): 4th intercostal space in MCL.
  • Inferior Angle of Scapula: Level of 7th rib or T7 spinous process (arm adducted).

Unlock the full lesson and continue reading

Signup to continue reading this lesson and unlimited access questions, flashcards, AI notes, and more

Scan to download app

Scan to download
UNLOCK FREE ACCESS

Practice Questions: Surface Landmarks of the Thorax

  1. 1. Shape of trapezius muscle is:

    • A. Fusiform
    • B. Trapezium
    • C. Triangular
    • D. Strap-shaped
    Show answer

    Answer: C. Triangular

    Triangular describes each individual trapezius muscle. Fusiform describes a spindle-shaped muscle rather than this broad, flat muscle. Strap-shaped describes an elongated, approximately uniform-width muscle rather than trapezius. Trapezium describes the combined outline of the paired trapezius muscles, not one unilateral muscle.

  2. 2. Which of the following is NOT a surface marking of the oblique fissure of the lung?

    • A. 5th rib in midaxillary line
    • B. 7th rib in midaxillary line
    • C. Spinous process of T3
    • D. 6th costal cartilage
    Show answer

    Answer: B. 7th rib in midaxillary line

    7th rib in midaxillary line - The oblique fissure typically extends anteriorly to the 6th costal cartilage, rather than reaching the 7th rib. - The 7th rib lies inferior to the usual anterior termination of the fissure, making it the option that is not a surface marking. 5th rib in midaxillary line - The oblique fissure crosses the fifth rib in the midaxillary line, so 5th rib is a valid surface landmark. Spinous process of T3 - Posteriorly, the oblique fissure begins near the spinous process of T3. - Thus, T3 marks the superior-posterior extent of the fissure and is a valid surface landmark. 6th costal cartilage - Anteriorly, the oblique fissure terminates near the 6th costal cartilage in the midclavicular line. - This 6th costal cartilage represents the inferior-anterior endpoint of the fissure and is therefore a valid surface marking.

  3. 3. All of the following statements about the spinal epidural space are true EXCEPT:

    • A. Ends at the sacrococcygeal membrane
    • B. Contains fat and venous plexuses
    • C. Continues into the skull
    • D. Lies outside of the dura mater
    Show answer

    Answer: C. Continues into the skull

    Continues into the skull is the exception because the spinal epidural space ends superiorly where the dura attaches at the foramen magnum. Ends at the sacrococcygeal membrane is true because this membrane closes the sacral hiatus inferiorly. Lies outside of the dura mater is true because the space lies between the spinal dura and the vertebral canal walls. Contains fat and venous plexuses is true because the spinal epidural space is a real space containing adipose tissue and the internal vertebral venous plexus.

  4. 4. A patient presents with winging of the scapula. Which nerve is most likely involved?

    • A. Thoracodorsal nerve
    • B. Lateral pectoral nerve
    • C. Long thoracic nerve
    • D. Musculocutaneous nerve
    Show answer

    Answer: C. Long thoracic nerve

    Long thoracic nerve - The long thoracic nerve innervates the serratus anterior, which protracts and upwardly rotates the scapula during shoulder movement. - Damage causes serratus anterior paralysis, making the medial border and inferior angle prominent and producing scapular winging. Lateral pectoral nerve - The lateral pectoral nerve supplies the pectoralis major, particularly its upper and middle portions. - Injury mainly weakens shoulder adduction and internal rotation; it does not directly impair the serratus anterior or cause scapular winging. Musculocutaneous nerve - The musculocutaneous nerve innervates the coracobrachialis, biceps brachii, and brachialis in the anterior compartment of the arm. - Its injury primarily impairs elbow flexion and forearm supination, rather than affecting scapular movement or producing winging. Thoracodorsal nerve - The thoracodorsal nerve supplies the latissimus dorsi, which extends, adducts, and internally rotates the humerus. - Injury weakens shoulder movements involving latissimus dorsi but does not directly denervate the serratus anterior or cause scapular winging.

  5. 5. What is the predominant abnormal radiographic finding on the supplied chest radiograph?

    • A. Hyperinflated lung fields
    • B. Reticular lung opacities
    • C. Globular cardiac enlargement
    • D. Perihilar airspace opacities
    Show answer

    Answer: B. Reticular lung opacities

    Reticular lung opacities is correct because diffuse fine linear markings forming a net-like pattern predominate in both lungs. Globular cardiac enlargement is incorrect because the cardiac silhouette is not enlarged. Hyperinflated lung fields is incorrect because emphysematous hyperlucency and flattened diaphragms are not the predominant findings. Perihilar airspace opacities is incorrect because the image does not show a predominantly confluent central airspace pattern.

  6. 6. Axillary nerve is accompanied by which artery ?

    • A. Posterior circumflex humeral artery
    • B. Anterior circumflex artery of humerus
    • C. Axillary artery
    • D. Subscapular artery
    Show answer

    Answer: A. Posterior circumflex humeral artery

    Posterior circumflex humeral artery - The axillary nerve accompanies the posterior circumflex humeral artery through the quadrangular space in the axilla. - Their close relationship makes both structures vulnerable during shoulder dislocation or fracture of the surgical neck of the humerus. Subscapular artery - The subscapular artery is the largest branch of the axillary artery and gives rise to the circumflex scapular and thoracodorsal arteries. - It does not accompany the axillary nerve through the quadrangular space; instead, it mainly supplies the subscapularis and latissimus dorsi regions. Anterior circumflex artery of humerus - The anterior circumflex artery of humerus arises from the axillary artery and wraps around the surgical neck of the humerus. - It runs mainly anteriorly and does not accompany the axillary nerve as the nerve passes posteriorly through the quadrangular space. Axillary artery - The axillary artery is the main arterial trunk of the axilla, but the axillary nerve is not described as accompanying this main trunk. - The nerve is specifically accompanied by the posterior circumflex humeral artery, a direct branch that passes with it through the quadrangular space.

  7. 7. Which of the following statements about the atrioventricular groove is true?

    • A. Also called anterior interventricular sulcus
    • B. Also called interatrial sulcus
    • C. Also called coronary sulcus
    • D. Also called posterior interventricular sulcus
    Show answer

    Answer: C. Also called coronary sulcus

    Also called coronary sulcus - The atrioventricular groove separates the atria from the ventricles on the external surface of the heart. - It is also called the coronary sulcus, which encircles the heart and marks the atrioventricular boundary. Also called anterior interventricular sulcus - The anterior interventricular sulcus separates the ventricles anteriorly, rather than separating the atria from the ventricles. Also called posterior interventricular sulcus - The posterior interventricular sulcus separates the ventricles posteriorly, rather than separating the atria from the ventricles. Also called interatrial sulcus - The interatrial sulcus marks the boundary between the atria, rather than between the atria and ventricles.

  8. 8. On a CT scan of the abdomen at the level of the upper lumbar vertebrae, which structure is a direct branch of the aorta and supplies blood to the ascending colon and proximal two-thirds of the transverse colon?

    • A. Structure B
    • B. Structure A
    • C. Structure C
    • D. Structure D
    Show answer

    Answer: C. Structure C

    Structure C is the superior mesenteric artery, which supplies the ascending colon and proximal two-thirds of the transverse colon. Structure D is the left renal vein, which drains the left kidney rather than supplying the colon. Structure B is the inferior vena cava, which returns systemic venous blood to the heart. Structure A is the aorta, the parent arterial trunk rather than the branch requested.

  9. 9. The thoracic duct crosses from the right to the left at the level of

    • A. T2 vertebra
    • B. T5 vertebra
    • C. T6 vertebra
    • D. T12 vertebra
    Show answer

    Answer: B. T5 vertebra

    T5 vertebra is the conventional level at which the thoracic duct crosses from right to left behind the oesophagus. T2 vertebra is above the usual crossover, where the duct is already on the left. T6 vertebra is below the conventional crossover. T12 vertebra is the level of entry into the thorax through the aortic hiatus, not the crossover. The duct usually terminates at the left venous angle, the junction of the left internal jugular and subclavian veins.

  10. 10. What is the SI unit of illuminance?

    • A. lm
    • B. lx
    • C. cd
    • D. cd/m²
    Show answer

    Answer: B. lx

    lx (lux) is the SI unit of illuminance, the luminous flux incident per unit area; 1 lx = 1 lm/m². cd (candela) is the SI unit of luminous intensity. cd/m² (candela per square metre) is the SI unit of luminance. lm (lumen) is the SI unit of luminous flux.

Flashcards: Surface Landmarks of the Thorax

  1. 1. Trans-tubercular plane lies at level of .

    Show answer

    L5 vertebra

  2. 2. Where does the small cardiac vein lie on the surface of the heart?

    Show answer

    Right atrioventricular sulcus

  3. 3. The secondary aortic (Erb's point) area is beside the sternum at the _____ _____ intercostal space

    Show answer

    left · third

  4. 4. mid arm circumference is measured between _____

    Show answer

    olecranon process and acromion process

  5. 5. d781e02957c14a2897c33e2b0224a109-ao-2

  6. 6. d4f504e7accc43959ee4fe5ea41ccd3b-ao-1

  7. 7. 10f93b3f6707442e87ec0271b17dfa60-ao-5

  8. 8. An imaginary plane drawn, extending between _____ of eye and the angle of _____, is known as _____

    Show answer

    medial canthus · mandible · Ohngren's line

  9. 9. _____ angle of scapula is at the level of spinous process of vertebra _____

    Show answer

    Inferior · T7
