Heart failure (HFrEF, HFpEF)

On this page

Quick Overview

Heart failure (HF) affects >900,000 UK adults with 5-year mortality ~50%. HFrEF (reduced ejection fraction, LVEF ≤40%) and HFpEF (preserved ejection fraction, LVEF ≥50%) require distinct management strategies. NICE NG106 emphasizes BNP-guided diagnosis and quadruple therapy for HFrEF.

Core Facts & Concepts

Diagnostic Criteria

  • BNP thresholds (NICE NG106):
    • BNP >400 pg/mL or NT-proBNP >2000 pg/mL → urgent echo within 2 weeks
    • BNP 100-400 pg/mL or NT-proBNP 400-2000 pg/mL → routine echo within 6 weeks
    • Previous MI → refer regardless of BNP
  • Classification by LVEF:
    • HFrEF: LVEF ≤40%
    • HFmrEF (mildly reduced): LVEF 41-49%
    • HFpEF: LVEF ≥50%

Figure 1: Echocardiogram showing dilated left ventricle with reduced wall motion

HFrEF Pharmacological Pillars (NICE NG106 quadruple therapy):

Drug ClassFirst-line AgentsTarget DoseKey Benefit
ARNI/ACEiSacubitril-valsartan 97/103mg BD OR Ramipril 10mg ODMortality ↓25-30%Start ACEi, switch to ARNI if stable
Beta-blockerBisoprolol 10mg OD, Carvedilol 25mg BDMortality ↓35%Start low, titrate slowly
MRASpironolactone 25-50mg OD, Eplerenone 50mg ODMortality ↓30%Monitor K⁺ and creatinine
SGLT2iDapagliflozin 10mg OD, Empagliflozin 10mg ODMortality ↓13%, HF admission ↓30%Even if non-diabetic

Clinical Pearl: Start all 4 pillars within 4-6 weeks; don't wait for sequential titration to max doses.

Diuretic Management

  • Loop diuretics (furosemide 40-240mg OD) for symptom relief only-no mortality benefit
  • Adjust dose based on daily weights and fluid status
  • IV if oral absorption poor (bowel oedema)

Problem-Solving Approach

Step-by-Step HF Diagnosis

  1. Clinical suspicion: Breathlessness, orthopnoea, ankle oedema, fatigue
  2. Order BNP/NT-proBNP: Elevated in >95% of HF cases
  3. Transthoracic echo: Assess LVEF, valves, wall motion
  4. ECG + CXR: Identify arrhythmias, cardiomegaly, pulmonary oedema
  5. Bloods: FBC, U&E, TFTs, HbA1c, lipids (exclude reversible causes)

Figure 2: Chest X-ray showing cardiomegaly with bilateral pleural effusions

HFrEF Medication Initiation Algorithm

  1. Start ACEi + beta-blocker simultaneously at low doses
  2. Add MRA if NYHA II-IV persists (K⁺ <5.0 mmol/L, eGFR >30)
  3. Switch ACEi to ARNI after 4 weeks if symptomatic
  4. Add SGLT2i immediately (regardless of diabetes status)
  5. Titrate each drug to target/max tolerated dose every 2-4 weeks

🚩 Red Flags for Specialist Referral

  • NYHA III-IV despite optimal medical therapy
  • Symptomatic hypotension preventing up-titration
  • Refractory fluid overload
  • Consider device therapy: ICD if LVEF ≤35%, CRT if QRS ≥130ms

Analysis Framework

HFrEF vs HFpEF Key Differences

FeatureHFrEF (LVEF ≤40%)HFpEF (LVEF ≥50%)
PathophysiologySystolic dysfunction, dilated LVDiastolic dysfunction, stiff LV
Evidence-based RxQuadruple therapy (ARNI, BB, MRA, SGLT2i)SGLT2i (dapagliflozin), diuretics
Mortality benefit50-60% reduction with optimal therapyMinimal proven therapies
Device therapyICD, CRT if indicatedRarely indicated
PrognosisBetter with treatmentPoorer, limited options

⚠️ Warning: HFpEF lacks robust evidence-focus on treating comorbidities (HTN, AF, obesity) and symptom control with diuretics.

Drug Monitoring Essentials

  • ACEi/ARNI: Check U&E at 1-2 weeks; accept Cr rise <30%, K⁺ <5.5 mmol/L
  • MRA: Stop if K⁺ >5.5 mmol/L or eGFR <30 mL/min
  • SGLT2i: Monitor for genital infections, DKA (rare)

Visual Aid

NYHA Functional Classification

ClassSymptomsActivity Limitation
INo symptomsNo limitation
IISymptoms with moderate exertionSlight limitation
IIISymptoms with minimal exertionMarked limitation
IVSymptoms at restUnable to carry out any activity

Key Points Summary

Diagnosis: BNP >400 pg/mL (or NT-proBNP >2000) + echo showing LVEF ≤40% confirms HFrEF

HFrEF quadruple therapy: ARNI (or ACEi) + beta-blocker + MRA + SGLT2i-start all within 4-6 weeks for maximum mortality benefit (50-60% reduction)

Diuretics: For symptom relief only; no mortality benefit. Titrate loop diuretics to euvolaemia

HFpEF management: Limited evidence-SGLT2i (dapagliflozin 10mg OD) only proven therapy. Focus on BP control and treating comorbidities

Device therapy: ICD if LVEF ≤35% post-MI or dilated cardiomyopathy; CRT if QRS ≥130ms with LBBB

Monitoring: Accept Cr rise <30% and K⁺ <5.5 mmol/L when initiating RAAS inhibitors-don't stop prematurely

Common pitfall: Sequential drug titration delays benefit-initiate all 4 pillars early, then up-titrate simultaneously

Practice Questions: Heart failure (HFrEF, HFpEF)

Test your understanding with these related questions

A 61-year-old man presents with progressive dyspnea and fatigue. Echocardiogram shows severe aortic stenosis with valve area $0.5\mathrm{cm}^2$. He develops syncope during exercise testing. What is the most appropriate management?

1 of 5

Flashcards: Heart failure (HFrEF, HFpEF)

1/10

Coarctation of Aorta is usually at the insertion of the _____

TAP TO REVEAL ANSWER

Coarctation of Aorta is usually at the insertion of the _____

ligamentum arteriosum
