Which of the following is not a cardiovascular monitoring technique

Transesophageal echocardiography

Pulmonary artery catheterization

Central venous pressure monitoring

Cerebral perfusion pressure is

mean arterial pressure - intracranial pressure

cerebral blood flow / brain surface area in m^2

cerebral blood flow * brain surface area in m^2

mean arterial pressure + intracranial pressure

A 30-year-old female patient developed features of septicemia, presenting with shock characterized by hypotension and low urine output, and was being treated for colonic necrosis. What is the most likely management?

IV fluids + antibiotics + norepinephrine

A patient of swine flu has developed severe respiratory distress. Which of the following findings confirm the diagnosis of ARDS in this patient?

PaO₂/FiO₂ ratio < 300 and PCWP < 18 mm Hg

PaO₂/FiO₂ ratio < 100 and PCWP < 18 mm Hg

Hemodynamic Monitoring for UPSC-CMS: High-Yield Internal Medicine Lessons

Intro & Key Parameters - Vitals Vigilantes

Hemodynamic Monitoring: Continuous assessment of cardiovascular system function to evaluate circulatory status & tissue perfusion.
Goals: Early detection of inadequacy, guide interventions (fluids, vasopressors), optimize oxygen delivery.
Key Parameters:
- Heart Rate (HR): Beats/min.
- Blood Pressure (BP): Systolic (SP), Diastolic (DP).
- Mean Arterial Pressure (MAP): $MAP = DP + 1/3(SP-DP)$. Target > 65 mmHg.
- Central Venous Pressure (CVP): Reflects RV preload. Normal: 2-8 mmHg.
- Peripheral Oxygen Saturation (SpO2): Target > 94%.

⭐ Mean Arterial Pressure (MAP) is a critical determinant of organ perfusion; a MAP < 60-65 mmHg often indicates inadequate tissue perfusion.

Arterial Line & CVP - Pressure Pointers

Arterial Line:
- Waveform: Systolic upstroke, peak, dicrotic notch (aortic valve closure), diastolic runoff.
- MAP Formula: $MAP \approx DBP + 1/3(SBP-DBP)$.
- Pre-cannulation (radial): Allen's test.
Central Venous Pressure (CVP):
- Waveform: 📌 a (atrial contraction), c (ventricular contraction - tricuspid bulge), x (atrial relaXation), v (venous filling), y (atrial emptYing - tricuspid opening).

Feature	Arterial Line	Central Venous Pressure (CVP)
Indications	Continuous BP, frequent ABGs	Volume status, fluid guide, central access
Normal Values	MAP 70-100 mmHg	2-8 mmHg
Complications	Thrombosis, embolism, infection, hematoma	Pneumothorax, infection, thrombosis, air embolism
Zeroing	Phlebostatic axis (4th ICS, mid-axillary)	Phlebostatic axis (4th ICS, mid-axillary)

Pulmonary Artery Catheter - Swan Song Secrets

The PAC (Swan-Ganz) offers advanced hemodynamic monitoring. Key for complex critical care. Pulmonary Artery Catheter Insertion & Waveforms

PAC Pressures & Interpretations:

Parameter	Normal (mmHg)	Significance
RAP (CVP)	2-8	RV preload; ↑ in RV failure, fluid overload
RVP	15-30 / 2-8	RV function; ↑ in PHTN, RV failure
PAP	15-30 / 4-12	Pulmonary circuit; ↑ in PE, ARDS, LV failure
PCWP	6-12	LV preload; ↑ in LV failure, fluid overload

SVR: $SVR = 80 \times (MAP - CVP) / CO$. Normal 800-1200 dynes·sec/cm⁵.
SvO2: 60-80%. ↓ indicates ↑O2 extraction (↓CO or ↑demand).

⭐ Pulmonary Capillary Wedge Pressure (PCWP) is a key indicator of left ventricular preload and is elevated in cardiogenic shock and fluid overload.

CO & Derived Parameters - Flow Finders

CO (Cardiac Output): $CO = HR \times SV$. Normal: 4-8 L/min.
CI (Cardiac Index): $CI = CO / BSA$. Normal: 2.5-4.0 L/min/m².
SVR (Systemic Vascular Resistance): $SVR = [(MAP - CVP) / CO] \times 80$. Normal: 800-1200 dynes·sec/cm⁵.
DO₂ (Oxygen Delivery): $DO_2 = CO \times CaO_2 \times 10$. Normal: 900-1100 mL/min.
CaO₂ (Arterial Oxygen Content): $CaO_2 = (Hb \times 1.34 \times SaO_2) + (PaO_2 \times 0.003)$. Normal: 17-20 mL/dL.

CO Measurement Techniques:

Technique	Method	Notes
Thermodilution (PAC)	Cold saline injectate (via PAC)	Gold standard, intermittent
Fick Principle	$CO = VO_2 / (CaO_2 - CvO_2)$	Measures O₂ consumption, less common
PiCCO	Transpulmonary thermodilution, pulse contour	Continuous, requires arterial & CVC lines
LiDCO	Lithium dilution, pulse power analysis	Continuous, requires arterial line

⭐ Mixed venous oxygen saturation (SvO2) or central venous oxygen saturation (ScvO2) is a critical marker of the adequacy of tissue oxygen delivery relative to tissue oxygen demand. Normal SvO2: 60-80%.

High‑Yield Points - ⚡ Biggest Takeaways

Pulmonary Artery Catheter (PAC) is key for measuring PAP, PAWP, CO, SvO2.

PAWP (Pulmonary Artery Wedge Pressure) reflects Left Atrial Pressure (LAP) and LVEDP (in absence of mitral stenosis).

Central Venous Pressure (CVP) estimates Right Atrial Pressure (RAP) and RV preload.

Mixed Venous Oxygen Saturation (SvO2), normal 60-80%, indicates global tissue oxygen extraction.

Low SvO2 (<60%) suggests ↑O2 consumption or ↓O2 delivery (e.g., ↓CO, ↓Hb, ↓SaO2).

Cardiac Index (CI), CO adjusted for BSA (CO/BSA), normal range: 2.5-4.0 L/min/m².

Different shock states (cardiogenic, septic, hypovolemic) exhibit distinct hemodynamic profiles; recognize these patterns for diagnosis and management.
