Core Principles - Justify, Optimize, Limit!

ICRP recommendations guide radiation safety through three core principles:

  • Justification: Any radiation practice must yield a net benefit.
  • Optimisation (ALARA/ALARP): Keep exposures As Low As Reasonably Achievable/Practicable, balancing societal and economic factors.
  • Dose Limitation: Apply dose limits for occupational and public exposures (not for patient's medical exposure).

⭐ The three fundamental principles of radiation protection are Justification, Optimisation (ALARA), and Dose Limitation.

Dose Metrics - Quantifying Exposure

  • Absorbed Dose (D): Energy deposited per unit mass of tissue.
    • Unit: Gray (Gy); 1 Gy = 1 J/kg.
  • Equivalent Dose ($H_T$): Absorbed dose adjusted for radiation type's biological effect.
    • Unit: Sievert (Sv).
    • $H_T = \sum_R W_R \cdot D_{T,R}$ ($W_R$: Radiation Weighting Factor).
  • Effective Dose (E): Equivalent dose adjusted for tissue sensitivity.
    • Unit: Sievert (Sv).
    • $E = \sum_T W_T \cdot H_T$ ($W_T$: Tissue Weighting Factor; sum for all tissues = 1).

Radiation Weighting Factors ($W_R$):

Radiation Type$W_R$ Value
Photons (X-rays, $\gamma$-rays)1
Electrons, Muons1
Alpha particles20
NeutronsVariable (energy-dependent)

Bio-Effects - Radiation's Toll

📌 STochastic = STatistical/chance, no threshold; DEterministic = DEfinite outcome above threshold.

Two main types of biological effects from radiation:

FeatureDeterministic Effects (Tissue Reactions)Stochastic Effects
BasisCertainty of effectProbability of effect
ThresholdYes (dose must be exceeded)No (assumed, LNT model)
Dose RelationSeverity ↑ with dose ↑Probability ↑ with dose ↑ (severity independent)
OutcomeSomatic (e.g., skin erythema, cataract ~0.5 Gy acute for lens)Somatic (cancer), Genetic/Heritable
  • Genetic/Heritable effects: Affect offspring of the exposed individual.

⭐ Stochastic effects are characterized by an increase in the probability of occurrence with increasing dose, without a dose threshold.

Stochastic vs Deterministic Radiation Effects

Practical Protection - Time, Distance, Shielding

📌 TDS: Time, Distance, Shielding - your radiation safety trio!

  • Time: Minimise duration of exposure near radiation sources.
  • Distance: Maximise distance from the source.
    • Obeys Inverse Square Law: Dose Rate $\propto 1/d^2$.
  • Shielding: Use appropriate barriers between source and personnel.
    • Attenuation described by $I = I_0 e^{-\mu x}$.
    • Key concepts: Half Value Layer (HVL), Tenth Value Layer (TVL).
    • Materials: Lead (Pb), Concrete.
    • PPE: Lead aprons (standard 0.25 mm or 0.5 mm Pb equivalence), thyroid shields, leaded glasses.

Time, Distance, Shielding Radiation Protection

⭐ The Inverse Square Law states that the intensity of radiation from a point source decreases with the square of the distance from the source (Intensity $\propto 1/d^2$).

Dose Limits & Monitoring - Staying Safe

CategoryParameterAnnual Limit (mSv)
OccupationalEffective Dose20 (avg/5yr, max 50/yr)
Lens of Eye20
Skin (avg over 1cm²)500
Hands & Feet500
PublicEffective Dose1
Lens of Eye15
Skin (avg over 1cm²)50
  • Personnel Dosimetry: TLD (Thermo Luminescent Dosimeter), OSLD (Optically Stimulated Luminescence Dosimeter), Film badges.

⭐ For a pregnant occupational worker, once pregnancy is declared, the dose to the foetus should not exceed 1 mSv during the remainder of the pregnancy.

Personnel dosimeters (TLD badge and ring dosimeters)

High-Yield Points - ⚡ Biggest Takeaways

  • ALARA Principle (As Low As Reasonably Achievable) guides all radiation safety practices.
  • Core principles: Justification (benefit outweighs risk), Optimization (ALARA), Dose Limitation.
  • Minimize exposure using Time (↓), Distance (↑), Shielding (TDS).
  • Inverse Square Law: Radiation intensity rapidly decreases with distance (proportional to 1/distance²).
  • Deterministic effects (e.g., skin erythema) have a threshold; Stochastic effects (e.g., cancer) are probabilistic.
  • Occupational whole-body effective dose limit: 20 mSv/year (averaged over 5 years).
