Thyroid Scintigraphy

On this page

Basics & Tracers - Glow & Go Juice

  • Principle: Gamma camera detects $\gamma$-rays from tracers in thyroid, assessing function & morphology.
  • Key Radiotracers:
Tracer$T_{1/2}$Energy ($\gamma$)Dose (Adult)MechanismNotes
$^{99m}$TcO$_4^-$6h140 keV $\gamma$2-10 mCiTrapped onlyMost common; low radiation
$^{123}$I13.2h159 keV $\gamma$100-400 µCiTrapped & OrganifiedIdeal physiology; good for ectopic tissue
$^{131}$I8d364 keV $\gamma$5-10 µCi (scan)Trapped & OrganifiedTherapy ($\beta^-$); high radiation (scan)

⭐ $^{99m}$Tc pertechnetate is trapped by thyroid follicular cells via the NIS symporter but is not organified, unlike iodine isotopes.

Why & Why Not - Scan Signals

  • Indications (Why - Interpreting Signals):
    • Thyrotoxicosis: Differentiate Graves'' disease (diffuse ↑ uptake) vs. Thyroiditis (↓ uptake).
    • Thyroid Nodules: Evaluate function (hot, warm, cold). Cold nodules warrant further investigation (e.g., FNAC).
    • Ectopic Thyroid Tissue: Detect uptake in aberrant locations (e.g., lingual, substernal).
    • Congenital Hypothyroidism: Assess for agenesis (no uptake) or dyshormonogenesis.
    • Post-Thyroidectomy: $I-131$ scan for remnant tissue or metastases (uptake indicates presence).
  • Contraindications/Limitations (Why Not - Affecting Signals or Safety):
    • Pregnancy (especially $I-131$; $Tc-99m$ pertechnetate is relatively contraindicated).
    • Breastfeeding (requires temporary cessation; duration depends on radiopharmaceutical).
    • Recent Iodine Exposure: Contrast media, amiodarone → ↓ tracer uptake.
    • Thyroid Hormone Therapy: Suppresses TSH → ↓ tracer uptake.

⭐ Thyroid scintigraphy is crucial for differentiating causes of thyrotoxicosis, especially distinguishing Graves'' disease (high uptake) from thyroiditis (low uptake).

How-To & Normal View - Picture Perfect Thyroid

  • Procedure:
    • Administer radiotracer (e.g., $^{\text{99m}}$Tc-pertechnetate, $^{\text{123}}$I, $^{\text{131}}$I).
    • Uptake time: 20 min for $^{\text{99m}}$Tc; 4-6h & 24h for $^{\text{123}}$I.
    • Imaging: Gamma camera, anterior view; patient supine, neck extended.
  • Normal Findings:
    • Butterfly-shaped gland; two lobes, connecting isthmus.
    • Homogeneous, symmetric tracer distribution.
    • Normal uptake: $^{\text{123}}$I: 10-30% (24h); $^{\text{99m}}$Tc: 0.5-4% (20 min).
    • 📌 "Perfectly Pictured Thyroid": Uniform, symmetric.

⭐ A normal thyroid scan shows homogeneous, symmetric tracer uptake in both lobes, with the isthmus often visible.

Hot, Cold & Sick - Nodule Nuisance News

Interpreting thyroid scintigraphy focuses on nodule activity and diffuse changes.

  • Nodule Types & Significance:

    FeatureHot NoduleCold Nodule
    Tracer Uptake↑ (Hyperfunctioning)↓ (Hypofunctioning)
    Malignancy RiskLow (<1%)Higher (15-20%)
    TSHOften ↓Normal / ↑
    Common CauseToxic Adenoma, MNGCyst, Colloid, Cancer
    Next StepTreat if toxicUS + FNA

    📌 Mnemonic: Cold is Cancer Concern.

  • Diffuse Patterns:

    • Graves': Diffusely ↑ uptake.
    • Thyroiditis (Subacute): Initially ↓ uptake (thyrotoxic phase), then ↑ (recovery).
    • Hashimoto's: Patchy, heterogeneous uptake. May show cold areas.

Thyroid Scintigraphy: Hot, Cold Nodules, Graves, Thyroiditis

⭐ Most thyroid cancers appear as 'cold' nodules on scintigraphy because malignant cells are typically less efficient at trapping or organifying iodine/technetium.

High‑Yield Points - ⚡ Biggest Takeaways

  • 99mTc-pertechnetate (trapping) is common; 123I (trapping & organification) for cancer, dyshormonogenesis.
  • Hot nodules are rarely malignant (<1%); cold nodules have higher malignancy risk (15-20%).
  • Graves' disease shows diffusely increased, homogenous uptake in the entire thyroid gland.
  • Toxic Multinodular Goiter (TMNG): multiple, discrete hot nodules with suppressed normal tissue.
  • Subacute thyroiditis (de Quervain's) typically shows markedly decreased or absent tracer uptake.
  • Discordant nodules (99mTc hot, 123I cold) suggest impaired organification, increasing malignancy concern.
