Post-Surgical Cardiovascular Imaging

Post-Surgical Cardiovascular Imaging

Post-Surgical Cardiovascular Imaging

On this page

CABG Imaging - Grafting Goods

  • Graft Types:
    • Arterial: LIMA (to LAD = workhorse), RIMA.
    • Venous: SVG (Saphenous Vein Graft).
    • Radial Artery.
  • CTA (Coronary CT Angiography):
    • Primary non-invasive tool.
    • Assesses: Patency, stenosis (>50% significant), occlusion, aneurysm.
    • Optimal timing: 1-6 months post-op (baseline), then as needed.
  • DSA (Digital Subtraction Angiography):
    • Gold standard for diagnosis/intervention.
    • Use if CTA inconclusive or intervention planned.
  • Key CTA Checks:
    • Graft origin, course, anastomosis, run-off.
    • Competitive flow from native vessels.
    • Stenosis: Proximal/distal anastomosis, body.

⭐ Patency: LIMA to LAD > Radial Artery > SVG. LIMA to LAD is gold standard graft. 📌 Mnemonic: LIMA Lasts, SVG Sags (Saphenous Vein Grafts sag/stenose earlier).

Prosthetic Valve Imaging - Valve Vibes

  • Valve Types:
    • Mechanical: Durable (e.g., bileaflet). Lifelong anticoagulation.
    • Bioprosthetic (Tissue): Porcine, bovine. Risk of Structural Valve Deterioration (SVD).
  • Key Imaging:
    • Echocardiography (TTE/TEE): Initial & follow-up. Assesses gradients, regurgitation.
    • CT Angiography (CTA): Anatomy, Paravalvular Leak (PVL), thrombus, pannus.
    • Fluoroscopy: Mechanical valve leaflet motion.
  • Complications (📌 Mnemonic: "VALVES"):
    • Valve thrombosis/pannus
    • Abscess (Endocarditis)
    • Leak (Paravalvular)
    • Vegetations (Endocarditis)
    • Embolism
    • Structural failure/Dehiscence
  • Thrombus vs. Pannus (CT):
    FeatureThrombusPannus
    AttenuationLow (<90 HU)Higher (soft tissue)
    OnsetAcute/SubacuteChronic

⭐ Cine fluoroscopy is excellent for assessing mechanical valve disc mobility; Cine MRI is a radiation-free alternative.

Aortic Repair Imaging - Aorta Alerts

Types of Endoleaks in EVAR

  • Primary Goal: Detect complications post EVAR/TEVAR (Endovascular/Thoracic Endovascular Aortic Repair).
  • Key Complications:
    • Endoleaks (most common, see flowchart)
    • Graft infection, migration, kinking
    • Pseudoaneurysm at anastomoses
    • Graft limb stenosis/occlusion
    • Aortoenteric fistula (rare, catastrophic)
  • Imaging: CTA is gold standard. Monitor aneurysm sac diameter: stability or shrinkage indicates success. Sac expansion >5mm is concerning for endoleak or endotension.
  • Surveillance: Lifelong imaging (CTA/MRA/US) crucial. Typically at 1, 6, 12 months, then annually if stable.

⭐ Type II endoleak is the most common type following EVAR, often from lumbar arteries or IMA. Many are managed conservatively if aneurysm sac is stable/shrinking.

Post-Op Complications - Sternal Scares & More

  • Sternal Dehiscence & Instability:
    • Clinical: Sternal pain, clicking, palpable gap, instability.
    • CXR: Wire fracture/migration, sternal separation > 2-3 mm.
    • CT: Defines extent, associated collections, early osteomyelitis.
  • Sternal Wound Infection & Mediastinitis:
    • Spectrum: Superficial cellulitis to deep mediastinitis.
    • Mediastinitis: Fever, sepsis, chest pain, purulent discharge.
    • Risk factors: Diabetes, obesity, smoking, prolonged bypass.
    • CT (gold standard):
      • Retrosternal fluid collections, abscess formation.
      • Peristernal soft tissue stranding, edema, enhancement.
      • Gas bubbles, air-fluid levels (ominous).
      • Sternal osteomyelitis (erosion, sequestrum, involucrum).

    ⭐ CT signs of mediastinitis include retrosternal fluid collections, soft tissue stranding, and gas bubbles.

  • Other common issues: Post-op hematoma, seroma, hypertrophic scarring, keloid formation.

Sternal Dehiscence on X-ray with Sternal Wires

High‑Yield Points - ⚡ Biggest Takeaways

  • CABG: CTA for graft patency, sternal dehiscence, and mediastinitis.
  • Prosthetic Valves: Echo (TTE/TEE) for leaks, thrombus, vegetations; CT for pannus/structure.
  • Aortic Grafts (EVAR/TEVAR): CTA is crucial for endoleaks, infection, and pseudoaneurysms.
  • Device Leads: CXR for position/fracture; CT/Echo for perforation, thrombosis.
  • LVADs: Echo/CT for pump thrombosis, outflow graft issues, and device infection.
  • Sternal Complications: CT is best for early detection of dehiscence or mediastinitis.
