Upper Limb Fractures

On this page

Clavicle & Scapula Fx - Collar & Blade Breaks

  • Clavicle Fractures:

    • Common: Middle 1/3 (Allman I, ~80%). MOI: FOOSH, direct.
    • N/V check: Subclavian vessels, brachial plexus.
    • 📌 Allman: I (Mid), II (Lat - nonunion risk if CC ligs torn), III (Med).
    • Rx:
      • Non-op: Sling, Fig-8 (undisplaced).
      • ORIF: Displaced >2cm / shortening >1.5cm, skin tenting, open, N/V injury, floating shoulder. Clavicle fracture types (Allman classification)
  • Scapula Fractures:

    • High-energy; check associated injuries.
    • Types: Body (commonest), neck, glenoid, acromion, coracoid.
    • Rx:
      • Non-op (most): Sling, early ROM.
      • ORIF: Glenoid step >3-5mm / >20% involved; Neck angulation >40° / translation >1cm; Open fx.

    Floating Shoulder: Ipsilateral clavicle + scapular neck/glenoid fx. Causes glenohumeral instability. Usually requires ORIF of one/both.

  • Management Flowchart (Clavicle Fx):

Humerus Fx (All Parts) - Arm Bar Busters

  • General Nerve Risks (📌 ARM-U):

    • Axillary n.: Surgical Neck.
    • Radial n.: Mid-Shaft (Spiral Groove).
    • Median n.: Supracondylar.
    • Ulnar n.: Medial Epicondyle.
  • Proximal Humerus Fx:

    • Elderly, osteoporosis. Neer's Classification (4-parts; displaced if >1cm or >45°).
    • Nerve: Axillary n. (deltoid, regimental badge). Vascular: Circumflex arteries (↑AVN risk).
    • Tx: Sling (undisplaced) vs. ORIF/Arthroplasty (displaced).

    ⭐ Axillary nerve is most commonly injured in surgical neck of humerus fractures.

  • Humeral Shaft Fx:

    • Nerve: Radial n. (wrist drop); Holstein-Lewis Fx (distal 1/3 spiral).
    • Tx: Sarmiento brace (if <20° ant, <30° varus/valgus angulation) vs. ORIF/IMN. Nerves of the Humerus
  • Distal Humerus Fx (Supracondylar - Peds):

    • FOOSH. Gartland Classification.
    • Nerve: Median n. (AIN), Radial n. Vascular: Brachial a. (⚠️ Volkmann's Ischemia).
    • Complication: Cubitus varus (Gunstock deformity).

Elbow & Forearm Fx - Joint & Shaft Jumbles

  • Elbow Region Fx:
    • Supracondylar Humerus (SCH): Child, FOOSH. Gartland I-III.
      • Complications: Brachial art., AIN (no 'OK' sign), Median n., Cubitus varus, Volkmann's.
      • Tx: Cast (I), CRPP (II/III).
    • Radial Head: FOOSH. Mason I-IV (Type II: >2mm disp.).
      • Essex-Lopresti: Radial head Fx + DRUJ injury + IOM tear.
    • Olecranon: Direct blow. Displaced: TBW.
  • Forearm Shaft Fx:
    • Both Bones: Adults: ORIF plates. Child: Cast/Nails.
    • Nightstick Fx: Isolated ulna.
  • Fx-Dislocations (Unstable):
    • 📌 MUGR: Monteggia (Ulna Fx + Radial Head Disloc.); Galeazzi (Radius Fx + DRUJ Disloc.).
    • Monteggia: Bado types. Type I (Ant. RH disloc.) common.
    • Galeazzi: "Fx of necessity" (adult ORIF).

Elbow and forearm fracture types

⭐ Monteggia fracture-dislocation: Fracture of the proximal ulna with dislocation of the radial head. Bado Type I (anterior dislocation of radial head) is the most common.

Wrist & Hand Fx - Distal Damage Detail

  • Scaphoid Fx Complications:
    • Avascular Necrosis (AVN): Risk ↑ proximal pole (up to 100% if displaced) > waist > distal pole.
    • Non-union: Common, especially if diagnosis delayed or fracture displaced.
    • Treatment: Herbert screw often used for fixation.
  • Kienbock's Disease: AVN of the lunate bone.
  • Nerve Injuries:
    • Median N.: Acute Carpal Tunnel Syndrome (CTS) post-Colles' Fx, lunate dislocation. 📌 Tinel's/Phalen's signs.
    • Ulnar N.: Guyon's canal syndrome (e.g., hook of hamate Fx).
    • Superficial Radial N.: Injury with styloid fractures (Chauffeur's Fx), tight casts/handcuffs.
  • Compartment Syndrome: ⚠️ Forearm/hand. Key signs: Pain out of proportion, Paresthesia, Pallor, Paralysis, Pulselessness (late). Requires urgent fasciotomy.
  • Malunion & Stiffness: Common after metacarpal/phalangeal fractures; can impair hand function. Scaphoid blood supply: Volar and Dorsal views

⭐ Tenderness in the anatomical snuffbox is highly suggestive of a scaphoid fracture, even if initial X-rays are negative. Immobilize and repeat X-ray in 10-14 days or consider MRI/CT for early diagnosis.

High‑Yield Points - ⚡ Biggest Takeaways

  • Anterior shoulder dislocation is most common, risking axillary nerve injury.
  • Clavicle fractures: Middle third most common; managed with sling or figure-of-8.
  • Supracondylar humerus fractures (children) risk Volkmann's contracture (median nerve, brachial artery).
  • Colles' fracture: Dorsal angulation ("dinner fork"); Smith's fracture: Volar angulation.
  • Scaphoid fractures: Anatomical snuffbox tenderness; high risk of avascular necrosis.
  • Monteggia: Proximal ulna fracture with radial head dislocation. Galeazzi: Distal radius fracture with DRUJ dislocation.
