Fracture Healing Process

On this page

Fracture Healing - Bone's Comeback Story

  • Stages (Indirect/Secondary Healing):
    • Inflammation (Day 1-7): Haematoma formation, release of growth factors (PDGF, TGF-β).
    • Soft Callus (Week 2-3): Fibrocartilaginous callus forms. Low $O_2$ tension. Provides initial stability.
    • Hard Callus (Week 4-12): Woven bone replaces soft callus via endochondral ossification. ↑$O_2$ tension.
    • Remodelling (Months-Years): Woven bone replaced by lamellar bone. Medullary canal restored. Governed by Wolff's Law.
  • Types of Healing:
    • Primary (Direct): Needs absolute stability (e.g., rigid internal fixation). No callus formation.
    • Secondary (Indirect): Involves callus. Occurs with relative stability (e.g., cast, IM nail).

Stages of secondary fracture healing

⭐ Primary bone healing (contact healing) occurs with interfragmentary strain < 2% under conditions of absolute stability, allowing direct Haversian remodeling across the fracture site without external callus formation.

Secondary Healing - Nature's Mending Magic

Most common type; occurs with non-rigid fixation (some motion). Characterized by callus formation. Stimulated by micromotion (strain <10%).

Radiographs of fracture healing at 2 and 5 weeks

  • Key Features:
    • Tolerates strain: 2-10%. Excessive motion (>10%) → non-union.
    • Involves both endochondral (cartilage precursor) and intramembranous ossification.
    • Callus provides stability, eventually resorbed.
  • 📌 Stages (sequential): Inflammation → Soft Callus → Hard Callus → Remodeling.

⭐ Callus formation is the hallmark of secondary bone healing, visible on X-rays, distinguishing it from primary healing.

Primary Healing & Factors - Fast Track & Roadblocks

  • Primary (Direct) Bone Healing:
    • Requires rigid internal fixation, minimal gap (< 0.01 mm contact; < 0.5-1 mm gap).
    • No external callus; direct Haversian remodeling via cutting cones (osteoclasts followed by osteoblasts).
    • Slower process than secondary healing. Cutting cone in primary bone healing
  • Key Factors Influencing Healing:
    • Systemic Promoters: Young age; good nutrition (protein, Vit C/D, Ca); Growth Hormone, Thyroid hormone.
    • Systemic Inhibitors: Old age; smoking; malnutrition; diabetes; corticosteroids; NSAIDs (high-dose/long-term); systemic infection.
    • Local Promoters: Good blood supply; stability (rigid/relative); small fracture gap; growth factors (e.g., BMPs).
    • Local Inhibitors: Poor blood supply (AVN risk); instability/excessive motion; large gap; local infection; severe soft tissue injury.

⭐ Smoking is a major detrimental factor, significantly impairing fracture healing by reducing microcirculation and osteoblast activity.

Healing Complications - When Bones Rebel

When fracture healing deviates, complications arise:

  • Delayed Union: Healing slower than expected (no clinical/radiological union by 3-6 months).
  • Nonunion: Complete failure of bony union, healing has ceased.
    • Hypertrophic (Elephant foot): Vascular, abundant callus; due to instability.
    • Atrophic (Pencil/Tapered end): Avascular, minimal/no callus; poor biology.
    • Oligotrophic: Viable cells, but inactive; no significant callus.
  • Malunion: Fracture heals with deformity (angulation, rotation, shortening).
  • Other: Infection (Osteomyelitis), Avascular Necrosis (AVN - e.g., scaphoid, femoral head), Joint Stiffness, CRPS.

⭐ The lower third of the tibia is a common site for nonunion due to its relatively poor blood supply.

X-ray series showing tibia fracture nonunion

High‑Yield Points - ⚡ Biggest Takeaways

  • Primary healing: Requires absolute stability (rigid fixation); no callus, direct Haversian remodeling.
  • Secondary healing: Commonest; involves inflammation (hematoma), soft callus (2-3 wks), hard callus (3-12 wks), then remodeling (Wolff's Law).
  • Callus Formation: Soft callus (fibrocartilage) gives initial stability; hard callus (woven bone) forms by endochondral ossification.
  • Remodeling: Woven bone replaced by lamellar bone, restoring strength/shape over months-years.
  • Key Mediators: BMPs, TGF-β, PDGF, FGFs are vital.

Practice Questions: Fracture Healing Process

Test your understanding with these related questions

Nonunion is most common in fracture of the:

1 of 5

Flashcards: Fracture Healing Process

1/8

In pseudoarthrosis, the central portion of the callus undergoes _____ degeneration

TAP TO REVEAL ANSWER

In pseudoarthrosis, the central portion of the callus undergoes _____ degeneration

cystic
