Special Forms of Strabismus

On this page

Duane Syndrome - Retracting Rebels

  • Congenital Cranial Dysinnervation Disorder (CCDD) affecting horizontal eye movements.
  • Pathophysiology: Agenesis/hypoplasia of abducens (CN VI) nucleus/nerve; aberrant innervation of lateral rectus (LR) by oculomotor nerve (CN III).
  • Huber Classification:
    • Type 1: Limited abduction (most common, ~80%).
    • Type 2: Limited adduction.
    • Type 3: Limited abduction AND adduction.
  • Key Features:
    • Globe retraction & palpebral fissure narrowing on attempted adduction.
    • Upshoot or downshoot of the globe on adduction (leash phenomenon).
    • Anomalous head posture (e.g., face turn).
  • 📌 Mnemonic: Duane's Retracts (Globe Retraction on adduction).
  • Associations: Goldenhar syndrome, Klippel-Feil anomaly, Wildervanck syndrome.

⭐ Unilateral involvement is more common (~85%), with the left eye being more frequently affected than the right.

Concomitant vs Inconcomitant Squints - Foundation Concepts

Concomitant Squint (Comitant Strabismus)

  • Definition: Squint where the degree of deviation remains constant in all directions of gaze.
  • Key Features:
    • Equal limitation of movement in both eyes.
    • Primary and secondary angles of deviation are equal.
    • No restriction on forced duction test.
    • Full range of ocular movements (ductions and versions).
  • Etiology:
    • Refractive errors (accommodative esotropia).
    • Sensory deprivation (dense cataract, severe refractive error).
    • Motor fusion defects.
  • Examples: Accommodative esotropia, basic esotropia, intermittent exotropia.

Inconcomitant Squint (Incomitant Strabismus)

  • Definition: Squint where the degree of deviation varies with direction of gaze.
  • Key Features:
    • Unequal limitation of movement between the two eyes.
    • Primary angle ≠ Secondary angle of deviation.
    • Positive forced duction test (if restrictive).
    • Limited range of ocular movements in affected directions.
  • Types:
    • Paralytic: Due to nerve palsy (CN III, IV, VI palsies).
    • Restrictive: Due to mechanical restriction (thyroid eye disease, orbital fractures).
    • Mixed: Combination of paralytic and restrictive components.

Clinical Differentiation

FeatureConcomitantInconcomitant
Deviation angleSame in all gazesVaries with gaze direction
Ocular movementsFull rangeLimited in affected directions
Forced duction testNegativeMay be positive (restrictive)
DiplopiaRare (suppression)Common
Head postureUsually normalOften abnormal (compensatory)

Hess Chart Patterns

  • Concomitant: Symmetrical restriction pattern.
  • Inconcomitant: Asymmetrical pattern with greater restriction in the direction of the affected muscle.

📌 Clinical Significance: Understanding this fundamental classification is essential before studying specific forms like Duane syndrome, Brown syndrome, and other special strabismus types.

Brown Syndrome - Tendon's Tight Tug

Brown syndrome eye movement restriction

  • Pathophysiology: Restricted superior oblique (SO) tendon movement via trochlea.
    • Congenital: Short/tight SO tendon; tendon-trochlea anomaly.
    • Acquired: Trauma, surgery, inflammation (e.g., Rheumatoid Arthritis).
  • Key Signs:
    • ↓ Elevation in adduction (hallmark).
    • Normal elevation in abduction.
    • V-pattern strabismus.
    • Possible downshoot in adduction on attempted upgaze in adduction.
  • Diagnosis: Positive Forced Duction Test (FDT) for restriction.
  • 📌 Mnemonic: "Brown can't look UP and IN".
  • Management:
    • Observation if mild (many congenital cases improve).
    • Surgery (e.g., SO tenotomy/tenectomy, silicone expander) for: significant hypotropia in primary gaze, abnormal head posture (chin elevation), or disabling diplopia.

⭐ Forced duction testing is positive in Brown syndrome, indicating mechanical restriction, unlike inferior oblique palsy where it's negative for restriction to elevation in adduction.

CFEOM & Fixus - Frozen Stares

📌 Frozen Stare: Hallmark of these conditions.

  • Congenital Fibrosis of Extraocular Muscles (CFEOM)
    • Rare genetic disorders; non-progressive restrictive ophthalmoplegia.
    • Patho: Primary EOM dysinnervation & subsequent fibrosis.
    • Types:
      • CFEOM1 (AD): KIF21A gene. Bilateral ptosis, eyes fixed in downgaze (approx. 20-30°). Most common.
      • CFEOM2 (AR): ARIX/PHOX2A gene. Bilateral exotropia, ptosis.
      • CFEOM3 (AD): TUBB3 gene. Variable phenotype, often severe ophthalmoplegia.
    • Clinical: Marked limitation of eye movements, abnormal head posture.
  • Strabismus Fixus
    • Severe congenital strabismus; eye(s) fixed in extreme deviation (e.g., adduction, abduction).
    • Profound ductional limitation.
    • Often unilateral. CFEOM with bilateral ptosis and downgaze fixation

⭐ CFEOM1, due to KIF21A mutations, classically presents with bilateral ptosis and eyes fixed in approximately 20-30° of infraduction.

DVD & Cyclic Squints - Rhythmic Eye Plays

  • Dissociated Vertical Deviation (DVD)

    • Spontaneous, slow upward drift of one eye when covered or during inattention; eye returns to normal position on uncovering.
    • Often bilateral & asymmetric.
    • Key features: Excyclotorsion on up-drift, no corresponding hypotropia in the fellow eye (violates Hering's Law).
    • Commonly associated with infantile esotropia, latent nystagmus.
    • Treatment: Surgical (e.g., Superior Rectus recession, Inferior Oblique anteriorization).

    ⭐ DVD is a comitant deviation that does not obey Hering's law of equal innervation.

  • Cyclic Strabismus

    • Rare condition; characterized by periodic alternation of normal ocular alignment and manifest strabismus.
    • Most common form: Cyclic esotropia.
    • Typical cycle: 48 hours (e.g., 24 hours orthophoria, 24 hours esotropia).
    • Onset: Usually between 2-6 years of age.
    • Etiology: Uncertain; possibly due to disturbance in supranuclear control or biological clock mechanism.
    • Treatment: Surgical correction based on the angle of deviation measured during the strabismic phase.

High‑Yield Points - ⚡ Biggest Takeaways

  • Duane Syndrome: Abduction deficit, globe retraction, and palpebral fissure narrowing on adduction. Type 1 most common.
  • Brown Syndrome: Limited elevation in adduction due to superior oblique tendon restriction. Positive forced duction test.
  • Möbius Syndrome: Congenital facial diplegia and bilateral abducens palsy causing esotropia.
  • CFEOM: Genetic, restrictive ophthalmoplegia and ptosis.
  • Thyroid Eye Disease: Proptosis, lid retraction, restrictive strabismus (IR, MR commonly affected).
  • Myasthenia Gravis: Painless ophthalmoplegia, ptosis, diplopia worsening with fatigue.

Practice Questions: Special Forms of Strabismus

Test your understanding with these related questions

Inability to abduct left eye with LMN fascial palsy on same side. The lesion is in

1 of 5

Flashcards: Special Forms of Strabismus

1/10

_____ refers to a partial reversible loss of vision in one or both eyes in the absence of any organic disease of ocular media, retina, and visual pathway.

TAP TO REVEAL ANSWER

_____ refers to a partial reversible loss of vision in one or both eyes in the absence of any organic disease of ocular media, retina, and visual pathway.

Amblyopia
