Instrumental Deliveries

On this page

Basics & Indications - Intervention Essentials

  • Instrumental delivery: Forceps or vacuum to assist vaginal birth.
  • Prerequisites:
    • Full cervical dilatation (10 cm)
    • Ruptured membranes
    • Engaged fetal head (Station ≥0)
    • Cephalic presentation
    • Adequate pelvis, empty bladder
    • Informed consent, adequate analgesia
  • Indications:
    • Maternal: Prolonged 2nd stage, exhaustion, medical conditions (e.g., cardiac).
    • Fetal: Non-reassuring fetal status (NRFS).

⭐ Prolonged 2nd stage: Nullipara >3h (epidural), >2h (no epidural); Multipara >2h (epidural), >1h (no epidural).

Prerequisites & Contraindications - Safety First Steps

  • Prerequisites (📌 Use "FORCEPS" checklist):
    • Full cervical dilation (10 cm); Fetal well-being (FHR).
    • Operator experienced; Obstruction absent (no CPD).
    • Ruptured membranes; Ready for C-section (backup).
    • Consent (informed); Cephalic (vertex) presentation.
    • Engaged head (≥0 station, ideally +2); Empty bladder; Effective analgesia.
    • Position of fetal head known precisely.
    • Station of head confirmed; Suitable instrument & setup.
  • Contraindications:
    • Absolute: Incomplete dilation, unengaged head, true CPD, non-vertex (brow/face), fetal bleeding/bone disorders, maternal refusal.
    • Vacuum-specific: Gestation <34 weeks (↑IVH risk); prior multiple scalp samples.

⭐ Trial: Abandon if no descent after 1-2 pulls, or delivery not imminent after 3 pulls / 15-20 mins (vacuum).

Instruments & Application - Toolkit Tactics

Forceps Delivery:

  • Types & Key Features:
    • Outlet: Wrigley's (low pelvic curve); Simpson's (fenestrated, molded head).
    • Rotational: Kielland's (transverse arrest; sliding lock; minimal pelvic curve).
  • Parts: Blades (cephalic & pelvic curves), Shank, Lock, Handles.
  • Application Essentials:
    • Prerequisites: Full dilatation, ROM, engaged head, known position, empty bladder, no CPD.
    • Technique: Left blade first (maternal left). Pajot's maneuver (axis traction). Episiotomy common.

Obstetrical forceps components and curves

Vacuum Assisted Delivery (Ventouse):

  • Types: Metal cups (e.g., Malmstrom), Soft cups (e.g., Silc, Bird).
  • Application Essentials:
    • Cup Placement: "Flexion point" (3cm anterior to posterior fontanelle, over sagittal suture).
    • Pressure: Negative 0.6-0.8 kg/cm² (or ~500-600 mmHg).
    • Traction: With uterine contractions, along pelvic axis.
  • ⚠️ Safe Use Limits: Max 3 pulls, 20 mins total time, 2 pop-offs.

⭐ Vacuum delivery is associated with higher rates of neonatal cephalohematoma and retinal hemorrhages, whereas forceps delivery carries a higher risk of maternal perineal trauma and fetal facial nerve palsy.

Flowchart: Instrumental Delivery Key Steps

Complications & Choice - Risk Rundown

Maternal Complications:

  • Forceps: ↑ Genital tract trauma (esp. 3rd/4th° tears), PPH, urinary retention.
  • Vacuum: ↓ Genital tract trauma; but ↑ risk of failed procedure.

Fetal Complications:

  • Forceps: Facial nerve palsy, skull # (rare), cephalohematoma (less common).
  • Vacuum: Cephalohematoma (common), scalp abrasions/lacerations, retinal hemorrhage, subgaleal hemorrhage (rare, serious).

Choice Factors: Gestational age, fetal presentation/position, maternal/fetal condition, operator skill.

FeatureForcepsVacuum
Maternal Trauma↑ (esp. severe perineal tears)
Fetal TraumaFacial N. palsy, skull #Cephalohematoma, scalp injury, retinal H.
Success RateHigherLower, detachment risk
AnalgesiaMore neededLess needed
<34 wksSuitableNo (Contraindicated)
RotationYes (e.g., Kielland's)Limited/No
Face/BreechYes (Piper for aftercoming head)No

High‑Yield Points - ⚡ Biggest Takeaways

  • Prerequisites are key: full dilatation, ruptured membranes, engaged head, adequate pelvis, empty bladder.
  • Indications: Maternal exhaustion, prolonged second stage, fetal distress.
  • Forceps: Preferred for preterm & face presentation. Kielland's forceps for rotation.
  • Ventouse: Apply at flexion point. Chignon is common. Risks include cephalohematoma.
  • Contraindications: Unengaged head, incomplete dilatation, CPD, fetal bleeding disorders (ventouse).
  • Failed instrumental delivery necessitates Cesarean section.
  • Complications: Maternal PPH, tears; Fetal facial palsy (forceps), cephalohematoma (ventouse).

Practice Questions: Instrumental Deliveries

Test your understanding with these related questions

The flexion point in ventouse (vacuum) delivery is located at:

1 of 5

Flashcards: Instrumental Deliveries

1/10

_____ maneuver is done for the delivery of aftercoming head in case of a breech presentation, when the back of the fetus fails to rotate to the symphysis

TAP TO REVEAL ANSWER

_____ maneuver is done for the delivery of aftercoming head in case of a breech presentation, when the back of the fetus fails to rotate to the symphysis

Prague's
