Polysomnography - Sleep Study Secrets
- Polysomnography (PSG) is a comprehensive, multi-parametric test that records various physiological variables during sleep. 📌 PSG: Patient Sleep Graphed.
- Primary Goals:
- Diagnose Obstructive Sleep Apnea (OSA) and assess its severity.
- Differentiate central, obstructive, and mixed apneas.
- Evaluate other sleep disorders (e.g., narcolepsy, periodic limb movement disorder).
⭐ Polysomnography is the gold standard for the diagnosis of Obstructive Sleep Apnea (OSA).
Polysomnography - Sensor Central Station
📌 SEE Cardio-Respiratory Activity: Sensors (EEG, EOG, EMG), Cardiac (ECG), Respiratory (Airflow, Effort, SpO2), Additional (Snoring, Position).
| Sensor/Channel | Parameter Measured | Clinical Significance (OSA/SDB) |
|---|---|---|
| Electroencephalogram (EEG) | Brain activity | Sleep staging; arousals |
| Electrooculogram (EOG) | Eye movements | REM sleep identification |
| Electromyogram (EMG) - Chin | Chin muscle activity | Muscle atonia (REM); bruxism |
| Electromyogram (EMG) - Limbs | Limb muscle activity | Periodic Limb Movements (PLMS) |
| Electrocardiogram (ECG) | Heart rate/rhythm | Arrhythmias; event-related HR changes |
| Nasal/Oral Airflow (Thermistor/Pressure) | Airflow | Apneas/hypopneas detection |
| Thoracic & Abdominal Effort (RIP) | Respiratory movements | Differentiates central vs. obstructive events |
| Pulse Oximetry (SpO2) | Oxygen saturation | Oxygen desaturation with events |
| Snoring Sensor (Microphone) | Snoring | Upper airway resistance indicator |
| Body Position Sensor | Supine, prone, lateral | Positional OSA/SDB identification |
⭐ Chin EMG demonstrating muscle atonia is a key feature for identifying REM sleep.
Polysomnography - Decoding Dream Data
Polysomnography (PSG) records multiple physiological parameters during sleep to diagnose sleep disorders.
- Sleep Staging (AASM Criteria):
- NREM Sleep: N1, N2, N3 (Slow Wave Sleep).
- REM Sleep.
- Key parameters: EEG (brain activity), EOG (eye movements), EMG (muscle tone).
- Respiratory Event Definitions:
- Apnea: Cessation of airflow ≥90% for ≥10s. Types: Obstructive, Central, Mixed.
- Hypopnea: Airflow reduction ≥30% for ≥10s associated with ≥3% O2 desaturation or an arousal.
- Key Indices:
- Apnea-Hypopnea Index (AHI): $AHI = \frac{\text{Total Apneas + Total Hypopneas}}{\text{Total Sleep Time (hours)}}$
- Respiratory Disturbance Index (RDI)
- Oxygen Desaturation Index (ODI)
- Arousal Index
- OSA Severity (AHI): 📌 5 (Normal limit), 15 (Mild ends), 30 (Moderate ends). Thresholds: Normal <5/hr; Mild 5-14.9/hr; Moderate 15-29.9/hr; Severe ≥30/hr.
⭐ An obstructive apnea is defined by continued or increased respiratory effort despite airflow cessation, distinguishing it from central apnea where effort is absent.
Polysomnography - Levels & Links
📌 PSG Types: Type I is In-Lab, the Ideal standard. As numbers go up (II, III, IV), comprehensiveness typically goes down.
| Type | Setting | Key Channels Monitored | Attended? | Primary Use | Advantages | Disadvantages |
|---|---|---|---|---|---|---|
| I | In-Laboratory | EEG, EOG, EMG, ECG, Airflow, Effort, SpO2, Snoring, Leg movements | Yes | Gold standard; Complex sleep disorders, CPAP titration | Highest accuracy, comprehensive data | Costly, inconvenient, less natural sleep |
| II | Home (Unattended) | Similar to Type I | No | OSA diagnosis, CPAP titration in select cases | Comprehensive data at home | Less accurate than Type I, no direct observation |
| III | Home (Unattended) | ≥3 channels (e.g., Airflow, Effort, SpO2, HR) | No | Uncomplicated OSA diagnosis | Convenient, lower cost | Limited data, may miss other disorders, higher failure rate |
| IV | Home (Unattended) | 1-2 channels (e.g., SpO2 ± Airflow/HR) | No | Screening for OSA, oximetry | Very convenient, lowest cost | Lowest accuracy, high false negative rate |
High‑Yield Points - ⚡ Biggest Takeaways
- Polysomnography (PSG) is the gold standard for diagnosing Obstructive Sleep Apnea (OSA).
- Key parameters include EEG, EOG, EMG, ECG, airflow, respiratory effort, and SaO2.
- Apnea-Hypopnea Index (AHI) quantifies OSA severity: Mild (5-15), Moderate (15-30), Severe (>30 events/hr).
- Differentiates obstructive, central, and mixed apneas.
- Assesses sleep architecture, including sleep stages and arousals.
- Oxygen Desaturation Index (ODI) is also a critical measure of nocturnal hypoxemia related to OSA events.
