Electrocution - Watts Up?

Electric current passage. Ohm's Law: $V=IR$; Joule's Law: $Q=I^2Rt$.

  • Severity Factors (📌 DR. VACT):
    • Duration (t), Resistance (R) (skin: dry/wet)
    • Voltage (V), Amperage (I)
    • Current type (AC/DC), Tissue path
  • AC vs DC:
    • AC: More dangerous (3-5x), tetany ("can't let-go").
    • DC: Single convulsion, throws victim.
  • Critical AC (50Hz) Levels:
    • Perception: ~1 mA
    • Let-go: ~10-25 mA
    • VF: ~50-100 mA
    • Asystole: >4 A

⭐ AC is more dangerous than DC, causing tetany and having a lower threshold for Ventricular Fibrillation (VF).

Electrocution - System Overload

  • Cardiovascular System:
    • Arrhythmias: Ventricular Fibrillation (VF) with AC (50-100 mA), Asystole with DC.
    • Myocardial necrosis, coronary artery spasm, hypertension.
  • Respiratory System:
    • Tetany of respiratory muscles (e.g., diaphragm).
    • Central respiratory arrest (medullary depression).
    • Pulmonary edema, ARDS.
  • Nervous System:
    • Loss of consciousness, seizures, amnesia.
    • Peripheral neuropathy (motor/sensory deficits).
    • Spinal cord injuries (e.g., transverse myelitis).
  • Musculoskeletal System:
    • Fractures/dislocations (violent muscle contractions, falls).
    • Rhabdomyolysis → myoglobinuria.
    • Compartment syndrome.
  • Renal System:
    • Acute Kidney Injury (AKI) due to myoglobinuria, direct effects.
  • Vascular System:
    • Endothelial damage, thrombosis, aneurysm formation, delayed hemorrhage.

⭐ AC current (50-100 mA for VF) is more dangerous than DC of equivalent voltage, readily inducing tetanic muscle contraction and increasing risk of the "lock-on" phenomenon.

Electrocution - Spark of Evidence

  • Death from electric current. Severity factors: Current (Amps) - Ohm's Law $I = V/R$, while AC is generally more dangerous than DC due to sustained muscle contraction and ventricular fibrillation risk, the danger depends on voltage, amperage, frequency, duration, and body pathway.
  • External Findings:
    • Joule Burn (Electric Mark): Entry/Exit. Dry, firm, depressed, central pallor, hyperemic rim. Often painless.
      • Spark burns: Arcing near entry.
      • Metallization: Conductor metal deposited.
    • Lichtenberg figures (ferning): Rare, transient electrical injury sign; not pathognomonic for electrocution.
  • Internal Findings:
    • Often non-specific: Visceral congestion, petechiae.
    • HPE: Streaming of nuclei, endothelial pearls (non-specific findings).
  • Cause of Death: Ventricular fibrillation (AC), respiratory arrest, medullary paralysis (DC).

⭐ The most critical factor determining electrocution severity is the current (amperage), not the voltage.

Electrocution - Bolt & Blame

  • Severity Factors: Voltage, Current (Amperage), Resistance (Skin: Dry >40kΩ, Wet ~1kΩ), Type (AC/DC), Path, Duration. 📌 VCR-TPD.
  • Amperage is the more critical factor in determining harm extent, including death risk. Higher amperage causes greater injury for same exposure duration.
  • AC 3 to 5 times more dangerous than DC (causes tetany, "no-let-go" effect due to prolonged muscle contraction).
  • Joule Burn (Electric Mark): Entry - dry, firm, depressed, pale centre, hyperemic border. Exit - often larger, everted.
  • Common COD: Ventricular Fibrillation (VF), respiratory arrest.

Lightning vs. High Voltage (HV) Electrocution

FeatureHV AC ElectrocutionLightning Strike (Natural DC)
BurnsDeep Joule burns (entry/exit)Superficial; Flashover common
Lichtenberg FiguresAbsentPresent (Arborescent/fern-like; pathognomonic)
DurationPotentially longerExtremely short
ClothingSinged at contactOften torn/shredded
MagnetisationNoYes (metallic objects)
Tympanic MembraneUsually intactOften ruptured

Medico-Legal Investigation

High‑Yield Points - ⚡ Biggest Takeaways

  • Joule burn (electric mark): Characteristic lesion when present; dry, firm, depressed, avascular - but absence doesn't rule out electrocution.
  • AC more dangerous than DC: causes tetany, ↑ risk of Ventricular Fibrillation.
  • Skin resistance is key; wet skin drastically ↓ resistance, ↑ current flow.
  • Current pathway through heart/brain is critical for lethality.
  • Primary COD: Ventricular Fibrillation; also respiratory paralysis.
  • Amperage, not voltage, is the crucial factor for tissue damage.
  • Internal autopsy findings often non-specific; comprehensive scene investigation and history vital per BNSS procedures.

Practice Questions: Electrocution

Test your understanding with these related questions

A 32-year-old male is brought for autopsy after being found on a railway track, suspected of suicide. Examination reveals joule burns on the fingers and multiple lacerated wounds on the body, with edges that do not gape and are closely approximated, and no positive vital reaction zone is present. Based on the autopsy findings, what is the most likely manner of death in this case?

1 of 5

Flashcards: Electrocution

1/10

No vital reaction is seen in a(n) _____-mortem wound

TAP TO REVEAL ANSWER

No vital reaction is seen in a(n) _____-mortem wound

Post (Ante/Post)
