Methemoglobin - Blue Blood Blues

  • Definition: Hemoglobin with iron in ferric ($Fe^{3+}$) state, not ferrous ($Fe^{2+}$).

    • Cannot bind $O_2$; causes functional anemia & left-shifted $O_2$ dissociation curve.
  • Causes:

    • Congenital: Cytochrome b5 reductase deficiency, HbM disease.
    • Acquired: Drugs (nitrites, dapsone, sulfonamides, local anesthetics), toxins.
  • Clinical: "Chocolate cyanosis"; blood is chocolate brown.

    • Symptoms worsen with ↑MetHb levels (e.g., >20% cyanosis, >70% often fatal). ⭐ > Pulse oximetry often reads ~85% despite hypoxia (saturation gap).
  • Flowchart Summary:

  • Treatment:

    • Methylene Blue: 1-2 mg/kg IV (MetHb >20% / symptomatic).
      • ⚠️ G6PD deficiency: Contraindicated (hemolysis risk).
      • Alternatives if CI/severe: Ascorbic Acid, Exchange Tx.
  • 📌 Mnemonic: MetHb = Maroon blood, Methylene blue. Normal vs. Methemoglobinemia Blood Color A[Oxidants / Genetic Defects] --> B[Hb($Fe^{2+}$) → MetHb($Fe^{3+}$)]; B --> C[↓ $O_2$ Capacity → Hypoxia]; C --> D[Chocolate Cyanosis]; D --> E[Dx: Co-oximetry]; D --> F[Tx: Methylene Blue]; F -.-> G[⚠️ Check G6PD status!];

HbS & Sickle Cell - Crescent Calamity

  • Genetics: Autosomal recessive; Point mutation in β-globin gene (GAG → GTG).
    • Substitution: Glutamic acid (hydrophilic) → Valine (hydrophobic) at 6th position of β-globin chain (β6 Glu→Val). This promotes hydrophobic interactions under deoxygenation.
  • Pathophysiology: ↓ $O_2$ → HbS polymerization → RBC sickling (initially reversible, then irreversible) → Vaso-occlusion & hemolysis.
  • Triggers: Hypoxia, acidosis, dehydration, infection, cold.
  • Clinical: Vaso-occlusive crisis (pain), dactylitis (infants), acute chest syndrome, autosplenectomy (↑ infection risk: S. pneumoniae, H. influenzae, N. meningitidis), aplastic crisis (Parvovirus B19).

    ⭐ Howell-Jolly bodies on peripheral smear indicate functional asplenia.

  • Diagnosis: Hb electrophoresis (HbS), solubility tests (sickling test), HPLC.
  • Management: Hydroxyurea (↑ HbF), hydration, analgesia, oxygen, transfusions. Sickle cell anemia peripheral smear

Other Abnormal Hbs - Rogue Red Roundup

  • HbC Disease: ($\beta_6$ Glu→Lys; 📌 C for Lysine, Crystals)
    • HbCC: Mild chronic hemolytic anemia, splenomegaly.
    • Smear: Target cells, HbC crystals (rod-shaped).
    • Electrophoresis: With HbA2 & HbE.
  • HbE Disease: ($\beta_{26}$ Glu→Lys; 📌 E for East - SE Asia)
    • HbEE: Mild microcytic anemia.
    • HbE/$\beta$-thal: Severe anemia.
    • Electrophoresis: With HbA2 & HbC.
  • Unstable Hemoglobins: (e.g., Hb Köln, Hb Zurich)
    • Autosomal Dominant; mutations → Hb precipitation (Heinz bodies).
    • Congenital Heinz body hemolytic anemia. Oxidant stress ↑.
  • Hemoglobins with Altered O₂ Affinity:
    • High Affinity: (e.g., Hb Chesapeake): Familial erythrocytosis; Left shift ODC.
    • Low Affinity: (e.g., Hb Kansas): Familial cyanosis/mild anemia; Right shift ODC.

⭐ HbC crystals are pathognomonic, appearing as tetragonal or rod-shaped intracellular structures, especially after splenectomy or in dehydrated cells.

High‑Yield Points - ⚡ Biggest Takeaways

  • Methemoglobin (MetHb): Iron in Fe³⁺ (ferric) state, cannot bind O₂, causing functional anemia.
  • Key causes: Oxidant drugs (e.g., dapsone, nitrites), G6PD deficiency.
  • Clinical: Cyanosis, chocolate-brown blood, normal PaO₂, saturation gap.
  • Treatment: Methylene blue (activates reductase), Vitamin C.
  • HbS (Sickle Cell): β-globin gene mutation (Glu6Val). Autosomal recessive. Leads to vaso-occlusion.
  • HbC Disease: β-globin mutation (Glu6Lys). Milder hemolysis, HbC crystals, target cells.
  • Thalassemias: Quantitative defect in globin chain synthesis (α or β).

Practice Questions: Methemoglobin and Abnormal Hemoglobins

Test your understanding with these related questions

A child presents with recurrent chest infections and abdominal pain. There is a history of 1 blood transfusion in the past. On examination, he had icterus and mild splenomegaly. Electrophoresis shows increased HbA2, HbF, and S spike. What is the likely diagnosis?

1 of 5

Flashcards: Methemoglobin and Abnormal Hemoglobins

1/10

Hemoglobin C disease occurs due to a point mutation that substitutes _____ with lysine

TAP TO REVEAL ANSWER

Hemoglobin C disease occurs due to a point mutation that substitutes _____ with lysine

glutamic acid
