Kidneys - Bean Scene Investigation

  • Location: Retroperitoneal, T12-L3. Right kidney typically lower. Hilum of left kidney near transpyloric plane (L1).
  • Size & Weight: Approx. 11x6x3 cm; 135-150 g.
  • Coverings (inward to outward):
    • Fibrous capsule (true capsule)
    • Perirenal fat (adipose capsule)
    • Renal fascia (Gerota's fascia) - encloses kidney & suprarenal gland (separated by a thin septum)
    • Pararenal fat (posteriorly)
  • Posterior Relations: Diaphragm, Transversus abdominis, Iliacus, Psoas major, Quadratus lumborum muscles; Subcostal (T12), Iliohypogastric (L1), & Ilioinguinal (L1) nerves/vessels. 📌 Mnemonic: 'D TITS L'.
  • Anterior Relations:
    Right KidneyLeft Kidney
    Suprarenal, Liver, Duodenum (2nd)Suprarenal, Stomach, Spleen
    Hepatic flexure (Colon), JejunumPancreas (tail), Splenic flexure (Colon), Jejunum

⭐ The hilum of the left kidney lies near the transpyloric plane (L1), about 5 cm from the midline.

Kidney anterior and posterior relations Renal fascia and surrounding structures

Kidneys - Inside Story & Plumbing

  • Hilum: Structures anterior to posterior: Renal Vein, Renal Artery, Renal Pelvis (VAP 📌).
  • Renal Sinus: Fat-filled central cavity; houses renal vessels, nerves, calyces, and pelvis.
  • Internal Structure:
    • Outer Cortex: Contains glomeruli, convoluted tubules, cortical collecting ducts. Extends into medulla as renal columns of Bertin.
    • Inner Medulla: Composed of 8-18 renal pyramids; apex is renal papilla, projecting into a minor calyx. Each papilla drains into one of 7-14 minor calyces.
  • Collecting System (Urine Flow): Minor calyces merge to form 2-3 major calyces, then the renal pelvis.
  • Renal Segments: 5 segments based on arterial supply: Apical, Anterosuperior, Anteroinferior, Posterior, Inferior.

Coronal section of kidney with labeled structures

⭐ Renal columns (of Bertin) are inward extensions of cortical tissue that separate the renal pyramids.

Kidneys - Red Rivers & Wires

  • Arterial Supply: Abd. Aorta (L1-L2) → Renal arteries → 5 Segmental (end arteries) → Lobar → Interlobar (renal columns) → Arcuate (corticomedullary jn.) → Interlobular (cortex) → Afferent arterioles.
  • Venous Drainage: Stellate veins → Interlobular → Arcuate → Interlobar → Segmental → Renal vein → IVC.
    • 📌 Left renal vein: longer, anterior to Aorta, posterior to SMA; receives left suprarenal & gonadal veins.
  • Lymphatics: Lateral aortic (paraaortic/lumbar) nodes.
  • Nerves: Renal plexus (around renal artery).
    • Sympathetic (T10-L1/L2, least splanchnic): vasoconstriction, ↑ renin.
    • Parasympathetic (Vagus): function less clear.

⭐ The segmental arteries of the kidney are anatomical end arteries; their occlusion can lead to infarction of the renal segment they supply.

Suprarenals - Adrenal Rush Hour

  • Location: Retroperitoneal, superomedial to kidneys, within renal fascia (but separate).
  • Shape: Right: pyramidal; Left: semilunar.
  • Parts & Origin:
    • Cortex (mesoderm): 📌 Mnemonic 'GFR - Salt, Sugar, Sex'
      ZoneProduct (e.g.)Primary Role
      GlomerulosaMineralocorticoids (Aldosterone)Salt balance
      FasciculataGlucocorticoids (Cortisol)Sugar metabolism
      ReticularisAndrogensSex hormones
    • Medulla (neural crest): Chromaffin cells (modified postganglionic sympathetic neurons) secrete Catecholamines (Adrenaline, Noradrenaline).
  • Arterial Supply (Rich): 📌 Superior (from inferior phrenic a.), Middle (from abdominal aorta), Inferior (from renal a.).
  • Venous Drainage (Single vein/gland): 📌 Right suprarenal v. → IVC; Left suprarenal v. → Left renal v.
  • Lymphatics: Lumbar (para-aortic) nodes.
  • Nerve Supply: Preganglionic sympathetic fibers (splanchnic nerves) to medullary chromaffin cells. Kidneys and suprarenal glands with arterial supply

⭐ The left suprarenal vein drains into the left renal vein, then to IVC; the right suprarenal vein drains directly into the IVC.

High‑Yield Points - ⚡ Biggest Takeaways

  • Kidneys: Retroperitoneal, T12-L3 level; right kidney slightly lower.
  • Renal hilum (anterior to posterior): Vein, Artery, Pelvis (VAP).
  • Left suprarenal veinleft renal vein; Right suprarenal veinIVC.
  • Suprarenal cortex (GFR): Glomerulosa (Aldosterone), Fasciculata (Cortisol), Reticularis (Androgens).
  • Suprarenal medulla: Chromaffin cells secrete catecholamines.
  • Nutcracker syndrome: Left renal vein compression by SMA and Aorta.
  • Horseshoe kidney: Ascent blocked by Inferior Mesenteric Artery.
