🍳 The Pressure Cooker

A fixed fascial compartment cannot expand. An insult (trauma, reperfusion) causes edema/bleeding, rapidly ↑ intracompartmental pressure. This compresses veins, obstructing outflow and creating a vicious cycle. The arteriovenous gradient falls, ↓ capillary blood flow and causing tissue ischemia. This ischemia worsens edema, perpetuating the cycle and leading to irreversible muscle and nerve damage.

⭐ Fasciotomy is indicated when compartment pressure is >30 mmHg or when delta pressure ($ΔP$ = Diastolic BP - Compartment Pressure) is <30 mmHg.

🩺 Clinical Manifestations - The 6 Ps

📌 The classic signs of acute limb ischemia, progressing from early to late findings:

  • Pain: Out of proportion to the apparent injury. The earliest and most sensitive sign. Worsens significantly with passive stretch of the affected muscles.
  • Paresthesia: "Pins and needles" sensation or numbness. An early indicator of nerve ischemia.
  • Pallor: Pale, dusky, or mottled skin due to ↓ arterial flow.
  • Poikilothermia: The limb becomes cool to the touch (assumes ambient temperature).
  • Paralysis: A late and ominous sign indicating significant muscle and nerve damage.
  • Pulselessness: A very late, often irreversible sign. Limb-threatening.

Pain out of proportion and pain on passive stretch are the earliest and most reliable clinical signs. The other "Ps" (Pallor, Paralysis, Pulselessness) are late findings indicating advanced ischemia.

📏 Diagnosis - Measure the Pressure

  • Primarily a clinical diagnosis. Objective measurement is crucial for equivocal cases (e.g., obtunded, intoxicated, or unreliable patients).
  • Use a compartment pressure monitor (e.g., Stryker device) for direct intracompartmental pressure measurement.

Stryker Compartment Pressure Monitor in Use

  • Fasciotomy Thresholds:
    • Absolute Pressure: > 30 mmHg.
    • Delta Pressure ($ΔP$): < 20-30 mmHg.
      • Calculated as: $ΔP = \text{Diastolic BP} - \text{Compartment Pressure}$.

⭐ Delta pressure is more reliable than absolute pressure, especially in hypotensive patients, as it better reflects compartment perfusion. A lower $ΔP$ indicates higher risk.

🔪 Management - Slice for Life

  • Immediate Intervention: Emergent surgical fasciotomy is the definitive, limb-saving treatment. Do not delay for imaging if clinical suspicion is high.
  • Goal: Fully decompress all affected fascial compartments to restore tissue perfusion and prevent necrosis.

Leg Fasciotomy (Standard Two-Incision):

  • Anterolateral Incision:
    • Releases Anterior & Lateral compartments.
  • Posteromedial Incision:
    • Releases Superficial Posterior & Deep Posterior compartments.

Leg Fasciotomy: Incision and Compartment Release

⭐ Irreversible muscle and nerve damage can occur within 4-6 hours of ischemia. A delta pressure (ΔP = Diastolic BP - Compartment Pressure) < 30 mmHg is a strong indication for fasciotomy.

  • Post-Op Care:
    • Wounds are left open, often managed with vacuum-assisted closure (VAC).
    • Delayed primary closure or skin grafting in 3-5 days.

💀 Complications - When Pressure Prevails

Delayed diagnosis leads to severe, irreversible outcomes:

  • Muscle Necrosis: Becomes irreversible after 4-8 hours of ischemia.
  • Volkmann's Ischemic Contracture: Permanent flexion deformity (e.g., claw-like hand) from muscle and nerve fibrosis.
  • Systemic: Rhabdomyolysis → myoglobinuria → Acute Kidney Injury (AKI).
  • Limb Loss: Amputation is the final consequence of untreated compartment syndrome.

⭐ Muscle is the least tolerant tissue to ischemia; irreversible damage begins within 4 hours and is complete by 8 hours.

Volkmann's ischemic contracture of the hand

⚡ Biggest Takeaways

  • Pain out of proportion to the injury is the earliest and most reliable symptom.
  • Paresthesias are an early sign; pulselessness and paralysis are very late findings.
  • Diagnosis is primarily clinical, but can be confirmed with compartment pressure measurement.
  • A delta pressure (diastolic BP − compartment pressure) of < 30 mmHg is diagnostic.
  • Treatment is emergent surgical fasciotomy to prevent irreversible muscle and nerve damage within 4-6 hours.
