V/Q Mismatch - The Great Divide

  • Goal: To improve arterial oxygenation by matching ventilation to perfusion, primarily by recruiting atelectatic lung tissue and optimizing gas distribution.
  • Key Strategies:
    • PEEP: Recruits collapsed alveoli (improves low V/Q), increases FRC. Titrate to best compliance/oxygenation.
    • Recruitment Maneuvers (RMs): Sustained high pressure (e.g., 30-40 cmH2O for 30-40s) to open atelectatic lung.
    • Prone Positioning: Gravitationally shifts perfusion to better-ventilated dorsal lung regions, improving V/Q matching in ARDS.

⭐ PEEP primarily addresses intrapulmonary shunt. By recruiting alveoli, it can improve oxygenation but may increase dead space if it overdistends healthy lung regions, impairing their perfusion.

Ventilator Levers - Twisting the Knobs

  • Oxygenation Knobs (Correcting ↓ PaO₂):

    • FiO₂ (Fraction of Inspired Oxygen): Primary lever. Directly ↑ alveolar oxygen ($P_A O_2$). Titrate to keep $SpO_2$ > 90%, aiming for FiO₂ < 0.6 to avoid oxygen toxicity.
    • PEEP (Positive End-Expiratory Pressure): Recruits collapsed alveoli, ↑ FRC, and improves V/Q matching. Crucial for intrapulmonary shunts (e.g., ARDS).
  • Ventilation Knobs (Correcting ↑ PaCO₂):

    • Respiratory Rate (RR): Main driver of minute ventilation. ↑ RR to blow off more CO₂.
    • Tidal Volume ($V_T$): Volume per breath. Secondary lever for CO₂ control.

Compliance curve: alveolar recruitment and lung function

High-Yield: For ARDS, use low tidal volume ventilation (4-8 mL/kg of ideal body weight). This lung-protective strategy is proven to reduce mortality by minimizing ventilator-induced lung injury (VILI).

Strategic Maneuvers - The Lung Savers

  • Goal: Recruit alveoli, improve oxygenation, and prevent Ventilator-Induced Lung Injury (VILI).
  • Positive End-Expiratory Pressure (PEEP):
    • Keeps alveoli open at end-expiration, ↑ functional residual capacity (FRC).
    • Recruits collapsed alveoli, converting shunt (V/Q = 0) to functional units.
    • Optimal PEEP balances improved $PaO_2$ against risk of overdistension & barotrauma.
  • Prone Positioning:
    • Improves V/Q matching by redirecting ventilation to better-perfused dorsal lung regions.
    • Reduces compression of lung bases by the heart and abdominal contents. Prone positioning effect on V/Q matching in ARDS
  • Low Tidal Volume Ventilation (LTVV):
    • Core of lung-protective strategy; targets 4-6 mL/kg ideal body weight.
    • Minimizes volutrauma (overstretching alveoli).

Driving Pressure ($P_{plat} - PEEP$) is a key mortality predictor in ARDS. Aim for a driving pressure $< extbf{15}$ cm H₂O.

  • V/Q mismatch is the most common cause of hypoxemia; ventilator strategies aim to improve this relationship.
  • PEEP is the cornerstone, recruiting collapsed alveoli and increasing functional residual capacity (FRC).
  • Recruitment maneuvers (sustained high pressure) can open atelectatic lung regions.
  • Prone positioning improves oxygenation by redirecting perfusion to better-ventilated dorsal lung zones.
  • In unilateral lung disease, placing the "good lung down" optimizes V/Q matching.

Practice Questions: Ventilator strategies addressing V/Q

Test your understanding with these related questions

A 32-year-old woman presents with progressive shortness of breath and a dry cough. She says that her symptoms onset recently after a 12-hour flight. Past medical history is unremarkable. Current medications are oral estrogen/progesterone containing contraceptive pills. Her vital signs include: blood pressure 110/60 mm Hg, pulse 101/min, respiratory rate 22/min, oxygen saturation 88% on room air, and temperature 37.9℃ (100.2℉). Her weight is 94 kg (207.2 lb) and height is 170 cm (5 ft 7 in). On physical examination, she is acrocyanotic. There are significant swelling and warmth over the right calf. There are widespread bilateral rales present. Cardiac auscultation reveals accentuation of the pulmonic component of the second heart sound (P2) and an S3 gallop. Which of the following ventilation/perfusion (V/Q) ratios most likely corresponds to this patient’s condition?

1 of 5

Flashcards: Ventilator strategies addressing V/Q

1/10

What type of V/Q mismatch occurs due to airway obstruction? _____

TAP TO REVEAL ANSWER

What type of V/Q mismatch occurs due to airway obstruction? _____

Shunt (perfusion but no ventilation)
