Respiratory mechanics and work of breathing US Medical PG Practice Questions and MCQs
Practice US Medical PG questions for Respiratory mechanics and work of breathing. These multiple choice questions (MCQs) cover important concepts and help you prepare for your exams.
Respiratory mechanics and work of breathing US Medical PG Question 1: A 60-year-old woman with a history of emphysema has been referred by her pulmonologist for follow-up pulmonary function testing. During the test, the patient reaches a point where her airway pressure is equal to the atmospheric pressure. Which of the following is most likely to be found during this respiratory state?
- A. Pulmonary vascular resistance is at a maximum
- B. Transmural pressure of the lung-chest wall system is at a maximum
- C. Transmural pressure of the chest wall is at a minimum
- D. Pulmonary vascular resistance is at a minimum (Correct Answer)
- E. Transmural pressure of the lung-chest wall system is at a minimum
Respiratory mechanics and work of breathing Explanation: ***Pulmonary vascular resistance is at a minimum***
- When airway pressure equals atmospheric pressure during a pulmonary function test, the lungs are at **functional residual capacity (FRC)** or resting state.
- At FRC, **pulmonary vascular resistance (PVR)** is at its lowest point due to the optimal balance between alveolar and extra-alveolar vessel compression/distension.
- Extra-alveolar vessels are compressed at low lung volumes, while alveolar vessels are compressed at high lung volumes. At FRC, both are optimally distended, resulting in **minimal PVR**.
*Pulmonary vascular resistance is at a maximum*
- PVR increases at very low lung volumes (due to extra-alveolar vessel compression) and very high lung volumes (due to alveolar vessel compression).
- The resting state (airway pressure equals atmospheric pressure) corresponds to FRC, where PVR is **minimal, not maximal**.
*Transmural pressure of the lung-chest wall system is at a maximum*
- Transmural pressure of the lung-chest wall system represents the pressure difference across the entire respiratory system.
- This pressure is higher during inspiration or forced expiration when the system is stretched or compressed.
- At FRC (airway pressure equals atmospheric pressure), the system is at **resting equilibrium**, not at maximal transmural pressure.
*Transmural pressure of the chest wall is at a minimum*
- Transmural pressure across the chest wall is the difference between intrapleural pressure and atmospheric pressure.
- This pressure is not at a minimum when airway pressure equals atmospheric pressure.
- Chest wall transmural pressure is actually minimal near **residual volume (RV)**, where the chest wall recoils inward most strongly.
*Transmural pressure of the lung-chest wall system is at a minimum*
- Transmural pressure of the lung-chest wall system reflects the elastic recoil forces of the combined system.
- At FRC (airway pressure equals atmospheric pressure), elastic recoil forces are balanced at equilibrium, but transmural pressure is **not at a minimum**—it represents the neutral resting state.
Respiratory mechanics and work of breathing US Medical PG Question 2: A 55-year-old woman comes to the physician with a 6-month history of cough and dyspnea. She has smoked 1 pack of cigarettes daily for the past 30 years. Analysis of the sputum sample from bronchoalveolar lavage shows abnormal amounts of an isoform of elastase that is normally inhibited by alpha-1 antitrypsin. The cell responsible for secreting this elastase is most likely also responsible for which of the following functions?
- A. Phagocytosis of foreign material (Correct Answer)
- B. Production of lactoferrin
- C. Degradation of toxins
- D. Secretion of mucus
- E. Diffusion of gases
Respiratory mechanics and work of breathing Explanation: ***Phagocytosis of foreign material***
- The abnormal elastase described is **neutrophil elastase**, which is normally inhibited by **alpha-1 antitrypsin**.
- **Neutrophils** are the primary cells responsible for secreting this elastase, and their main function is the **phagocytosis of foreign material** and pathogens.
*Production of lactoferrin*
- **Lactoferrin** is an iron-binding protein with antimicrobial properties, primarily produced by **neutrophils**, but it is not their defining or most unique function in the context of elastase secretion and lung pathology.
- While neutrophils do produce lactoferrin, the question asks for a function that aligns with the described cellular pathology following elastase release.
*Degradation of toxins*
- While certain immune cells and organs (e.g., liver) are involved in **detoxification**, it is not a primary or most characteristic function of **neutrophils** in the lung.
- Neutrophils are more focused on direct microbial killing and inflammation rather than broad toxin degradation.
*Secretion of mucus*
- **Mucus secretion** in the airways is primarily a function of **goblet cells** and submucosal glands, not neutrophils.
- Excessive mucus secretion is a feature of chronic bronchitis, which can coexist with emphysema, but neutrophils themselves do not secrete mucus.
*Diffusion of gases*
- **Gas diffusion** is the primary function of **type I pneumocytes** in the alveolar sacs, which form the thin barrier between air and blood.
- This function is entirely unrelated to the role of neutrophils or the secretion of elastase.
Respiratory mechanics and work of breathing US Medical PG Question 3: A 57-year-old man presents to the clinic for a chronic cough over the past 4 months. The patient reports a productive yellow/green cough that is worse at night. He denies any significant precipitating event prior to his symptoms. He denies fever, chest pain, palpitations, weight changes, or abdominal pain, but endorses some difficulty breathing that waxes and wanes. He denies alcohol usage but endorses a 35 pack-year smoking history. A physical examination demonstrates mild wheezes, bibasilar crackles, and mild clubbing of his fingertips. A pulmonary function test is subsequently ordered, and partial results are shown below:
Tidal volume: 500 mL
Residual volume: 1700 mL
Expiratory reserve volume: 1500 mL
Inspiratory reserve volume: 3000 mL
What is the functional residual capacity of this patient?
- A. 4500 mL
- B. 2000 mL
- C. 2200 mL
- D. 3200 mL (Correct Answer)
- E. 3500 mL
Respiratory mechanics and work of breathing Explanation: ***3200 mL***
- The **functional residual capacity (FRC)** is the volume of air remaining in the lungs after a normal expiration.
- It is calculated as the sum of the **expiratory reserve volume (ERV)** and the **residual volume (RV)**. In this case, 1500 mL (ERV) + 1700 mL (RV) = 3200 mL.
*4500 mL*
- This value represents the sum of the **inspiratory reserve volume (3000 mL)** and the **residual volume (1700 mL)**, which does not correspond to a standard lung volume or capacity.
- It does not logically relate to the definition of functional residual capacity.
*2000 mL*
- This value represents the sum of the **tidal volume (500 mL)** and the **expiratory reserve volume (1500 mL)**, which is incorrect for FRC.
- This would represent the inspiratory capacity minus the inspiratory reserve volume, which is not a standard measurement used in pulmonary function testing.
*2200 mL*
- This value could be obtained by incorrectly adding the **tidal volume (500 mL)** and the **residual volume (1700 mL)**, which is not the correct formula for FRC.
- This calculation represents a miscombination of lung volumes that does not correspond to any standard pulmonary capacity measurement.
*3500 mL*
- This value is the sum of the **tidal volume (500 mL)**, the **expiratory reserve volume (1500 mL)**, and the **residual volume (1700 mL)**.
- This would represent the FRC plus the tidal volume, which is not a standard measurement and does not represent the functional residual capacity.
Respiratory mechanics and work of breathing US Medical PG Question 4: A 32-year-old woman comes to the physician for a screening health examination that is required for scuba diving certification. The physician asks her to perform a breathing technique: following deep inspiration, she is instructed to forcefully exhale against a closed airway and contract her abdominal muscles while different cardiovascular parameters are evaluated. Which of the following effects is most likely after 10 seconds in this position?
- A. Decreased intra-abdominal pressure
- B. Decreased left ventricular stroke volume (Correct Answer)
- C. Decreased pulse rate
- D. Decreased systemic vascular resistance
- E. Increased venous return to left atrium
Respiratory mechanics and work of breathing Explanation: ***Decreased left ventricular stroke volume***
- After 10 seconds of performing the **Valsalva maneuver**, the increased intrathoracic pressure significantly reduces **venous return** to the heart.
- Reduced venous return leads to decreased **ventricular filling** (preload), which in turn diminishes **left ventricular stroke volume** and cardiac output.
*Decreased intra-abdominal pressure*
- The instruction to "contract her abdominal muscles" during forceful exhalation against a closed airway (Valsalva maneuver) directly leads to an **increase** in **intra-abdominal pressure**, not a decrease.
- This increase in intra-abdominal pressure further impedes venous return from the lower extremities to the heart.
*Decreased pulse rate*
- In the initial phase of the Valsalva maneuver (first 5-10 seconds), the decrease in cardiac output triggers a **reflex tachycardia** to maintain blood pressure, leading to an **increased pulse rate**.
- A decrease in pulse rate (bradycardia) is more characteristic of the release phase, not during the sustained strain.
*Decreased systemic vascular resistance*
- During the Valsalva maneuver, the body attempts to compensate for the drop in cardiac output and blood pressure by increasing **sympathetic tone**, which causes **vasoconstriction** and thus **increases systemic vascular resistance**.
- A decrease in systemic vascular resistance would further drop blood pressure and is not the physiological response during this phase.
*Increased venous return to left atrium*
- The Valsalva maneuver dramatically **reduces venous return** to both the right and left atria due to the high intrathoracic pressure compressing the great veins.
- This decreased venous return is the primary mechanism leading to the subsequent fall in cardiac output during the maneuver.
Respiratory mechanics and work of breathing US Medical PG Question 5: A 57-year-old man comes to the physician because of a 2-year history of fatigue, worsening shortness of breath, and a productive cough for 2 years. He has smoked 1 pack of cigarettes daily for the past 40 years. Examination shows pursed-lip breathing and an increased anteroposterior chest diameter. There is diffuse wheezing bilaterally and breath sounds are distant. Which of the following parameters is most likely to be decreased in this patient?
- A. Thickness of small airways
- B. Work of breathing
- C. Lung elastic recoil (Correct Answer)
- D. Lower airway resistance
- E. Pulmonary vascular pressure
Respiratory mechanics and work of breathing Explanation: ***Lung elastic recoil***
- The patient's presentation (long smoking history, dyspnea, pursed-lip breathing, increased AP diameter, distant breath sounds, and wheezing) is classic for **emphysema**, a form of **COPD**.
- Emphysema involves the destruction of **alveolar walls** and **elastic fibers**, leading to a significant decrease in the lung's ability to passively recoil during expiration.
*Thickness of small airways*
- In COPD, particularly chronic bronchitis, there is often **inflammation and thickening of the small airways** due to goblet cell hyperplasia and mucus gland hypertrophy, increasing their thickness, not decreasing it.
- This thickening contributes to increased airway resistance.
*Work of breathing*
- The **destruction of elastic recoil** in emphysema means the patient must actively use accessory muscles to exhale, significantly **increasing the work of breathing**, which is evident from pursed-lip breathing.
- Patients with COPD expend much more energy to breathe than healthy individuals.
*Lower airway resistance*
- Emphysema, while characterized by alveolar destruction, also has an obstructive component due to **airway collapse during expiration** (loss of radial traction) and potential inflammation/mucus, which leads to **increased lower airway resistance**, not decreased resistance.
- This increased resistance contributes to air trapping and wheezing.
*Pulmonary vascular pressure*
- Chronic hypoxia resulting from severe COPD can lead to **pulmonary vasoconstriction** and remodeling of the pulmonary arteries, causing **pulmonary hypertension** and an increase in pulmonary vascular pressure.
- This is a common complication in advanced COPD, not a decreased parameter.
Respiratory mechanics and work of breathing US Medical PG Question 6: A 72-year-old obese man presents as a new patient to his primary care physician because he has been feeling tired and short of breath after recently moving to Denver. He is a former 50 pack-year smoker and has previously had deep venous thrombosis. Furthermore, he previously had a lobe of the lung removed due to lung cancer. Finally, he has a family history of a progressive restrictive lung disease. Laboratory values are obtained as follows:
Oxygen tension in inspired air = 130 mmHg
Alveolar carbon dioxide tension = 48 mmHg
Arterial oxygen tension = 58 mmHg
Respiratory exchange ratio = 0.80
Respiratory rate = 20/min
Tidal volume = 500 mL
Which of the following mechanisms is consistent with these values?
- A. Shunt physiology
- B. High altitude
- C. V/Q mismatch
- D. Pulmonary fibrosis
- E. Hypoventilation (Correct Answer)
Respiratory mechanics and work of breathing Explanation: ***Hypoventilation***
- The arterial oxygen tension (PaO2) of 58 mmHg is consistent with hypoxemia, and the alveolar carbon dioxide tension (PACO2) of 48 mmHg (normal 35-45 mmHg) indicates **hypercapnia**, a hallmark of hypoventilation.
- The **alveolar-arterial (A-a) gradient** can be calculated using the alveolar gas equation: PAO2 = PiO2 - PACO2/R. Here, PAO2 = 130 mmHg - 48 mmHg/0.8 = 130 - 60 = 70 mmHg. The A-a gradient is PAO2 - PaO2 = 70 - 58 = 12 mmHg, which is within the normal range (5-15 mmHg), indicating that the hypoxemia is primarily due to **decreased alveolar ventilation**.
*Shunt physiology*
- A shunt would cause a significant reduction in PaO2 and a **widened A-a gradient** (typically >15 mmHg) due to deoxygenated blood bypassing ventilated areas.
- While shunts do not typically cause hypercapnia unless very severe, the normal A-a gradient here rules out a significant shunt as the primary mechanism for hypoxemia.
*High altitude*
- Moving to a high altitude (like Denver) causes a decrease in **inspired oxygen tension (PiO2)**, leading to hypoxemia.
- However, the provided inspired oxygen tension (130 mmHg) is above what would be expected for significant high-altitude hypoxemia at sea level equivalent, and the hypoxemia here is associated with hypercapnia, which is not a direct result of high altitude itself.
*V/Q mismatch*
- A V/Q mismatch leads to hypoxemia and a **widened A-a gradient**, as some areas of the lung are either underventilated or underperfused.
- While it can cause hypoxemia, a V/Q mismatch is typically associated with **normal or low PaCO2** due to compensatory hyperventilation, not hypercapnia, and the A-a gradient would be elevated.
*Pulmonary fibrosis*
- Pulmonary fibrosis is a restrictive lung disease that leads to impaired gas exchange, causing hypoxemia primarily due to **V/Q mismatch** and **diffusion limitation**.
- This would result in a **widened A-a gradient** and often a **low PaCO2** due to compensatory hyperventilation, rather than the elevated PaCO2 observed in this patient.
Respiratory mechanics and work of breathing US Medical PG Question 7: A 21-year-old lacrosse player comes to the doctor for an annual health assessment. She does not smoke or drink alcohol. She is 160 cm (5 ft 3 in) tall and weighs 57 kg (125 lb); BMI is 22 kg/m2. Pulmonary function tests show an FEV1 of 90% and an FVC of 3600 mL. Whole body plethysmography is performed to measure airway resistance. Which of the following structures of the respiratory tree is likely to have the highest contribution to total airway resistance?
- A. Conducting bronchioles
- B. Terminal bronchioles
- C. Segmental bronchi (Correct Answer)
- D. Respiratory bronchioles
- E. Mainstem bronchi
Respiratory mechanics and work of breathing Explanation: ***Segmental bronchi***
- In healthy individuals, **medium-sized bronchi** (including segmental and subsegmental bronchi, approximately generations 4-8) contribute approximately **80% of total airway resistance**.
- While **Poiseuille's Law** states resistance is inversely proportional to radius to the fourth power (R ∝ 1/r⁴), the key factor is the **total cross-sectional area** and **degree of branching**.
- Medium-sized bronchi have moderate individual resistance and **limited parallel branching**, making them the dominant site of resistance.
- This is why diseases affecting medium-sized airways (e.g., asthma, bronchitis) cause significant increases in airway resistance.
*Terminal bronchioles*
- Although individual terminal bronchioles have small radii and high individual resistance, there are **millions of them arranged in parallel**.
- With parallel resistances, total resistance decreases: 1/R_total = 1/R₁ + 1/R₂ + 1/R₃...
- The **massive number** of small airways means their collective resistance is actually quite **low** (~10-20% of total).
- This is why small airways disease is called the "**silent zone**" - significant pathology can occur before detection.
*Conducting bronchioles*
- These airways also benefit from extensive **parallel branching**, reducing their contribution to total resistance.
- They contribute less than medium-sized bronchi due to their large cumulative cross-sectional area.
*Respiratory bronchioles*
- Part of the **respiratory zone** with the largest total cross-sectional area in the lungs.
- Minimal contribution to airway resistance due to enormous parallel arrangement.
- Primary function is **gas exchange**, not air conduction.
*Mainstem bronchi*
- These large airways have **low individual resistance** due to large diameter.
- Together with the trachea, they contribute approximately **20% of total airway resistance**.
- Not the primary site despite being early in the airway tree.
Respiratory mechanics and work of breathing US Medical PG Question 8: A 15-year-old boy and his mother were referred to a pulmonology clinic. She is concerned that her son is having some breathing difficulty for the past few months, which is aggravated with exercise. The family is especially concerned because the patient’s older brother has cystic fibrosis. The past medical history is noncontributory. Today, the vital signs include: blood pressure 119/80 mm Hg, heart rate 90/min, respiratory rate 17/min, and temperature 37.0°C (98.6°F). On physical exam, he appears well-developed and well-nourished. The heart has a regular rate and rhythm, and the lungs are clear to auscultation bilaterally. During the exam, he is brought into a special room to test his breathing. A clamp is placed on his nose and he is asked to take in as much air as he can, and then forcefully expire all the air into a spirometer. The volume of expired air represents which of the following?
- A. Tidal volume
- B. Total lung capacity
- C. Functional residual capacity
- D. Expiratory reserve volume
- E. Vital capacity (Correct Answer)
Respiratory mechanics and work of breathing Explanation: ***Vital capacity***
- **Vital capacity (VC)** is the maximum volume of air exhaled after a maximal inspiration. The maneuver described ("take in as much air as he can, and then forcefully expire all the air") directly measures vital capacity.
- VC includes the **tidal volume (TV)**, **inspiratory reserve volume (IRV)**, and **expiratory reserve volume (ERV)**.
*Tidal volume*
- **Tidal volume (TV)** is the volume of air inspired or expired with a normal breath, not the maximal forceful expiration described.
- It represents the usual volume of air exchanged during quiet breathing.
*Total lung capacity*
- **Total lung capacity (TLC)** is the maximum volume of air that the lungs can hold after a maximal inspiration, including the residual volume.
- This cannot be measured directly by spirometry alone, as it includes the **residual volume** which is the air remaining in the lungs after maximal expiration.
*Functional residual capacity*
- **Functional residual capacity (FRC)** is the volume of air remaining in the lungs after a normal, quiet expiration.
- Like TLC and residual volume, FRC cannot be measured directly by standard spirometry.
*Expiratory reserve volume*
- **Expiratory reserve volume (ERV)** is the maximum volume of air that can be *additionally* exhaled after a normal exhalation.
- The patient was asked to expire all the air after a maximal inspiration, which is a measure of vital capacity, not just ERV.
Respiratory mechanics and work of breathing US Medical PG Question 9: A 21-year-old man is admitted to the intensive care unit for respiratory failure requiring mechanical ventilation. His minute ventilation is calculated to be 7.0 L/min, and his alveolar ventilation is calculated to be 5.1 L/min. Which of the following is most likely to decrease the difference between minute ventilation and alveolar ventilation?
- A. Increasing the partial pressure of inhaled oxygen
- B. Decreasing the affinity of hemoglobin for oxygen
- C. Increasing the respiratory depth
- D. Decreasing the physiologic dead space (Correct Answer)
- E. Increasing the respiratory rate
Respiratory mechanics and work of breathing Explanation: ***Decreasing the physiologic dead space***
- The difference between **minute ventilation (VE)** and **alveolar ventilation (VA)** is the **dead space ventilation (VD)**, calculated as: VE - VA = VD
- In this case: 7.0 L/min - 5.1 L/min = 1.9 L/min of dead space ventilation
- Decreasing the **physiologic dead space** directly reduces this difference by allowing a greater proportion of each breath to participate in gas exchange
- This is the most direct way to narrow the gap between VE and VA
*Increasing the partial pressure of inhaled oxygen*
- This intervention primarily affects **oxygenation** by increasing the driving pressure for oxygen diffusion into the blood
- It does not directly change the volume of air participating in alveolar ventilation or reduce dead space ventilation
- The distribution of ventilation between alveolar and dead space remains unchanged
*Decreasing the affinity of hemoglobin for oxygen*
- A decrease in hemoglobin affinity for oxygen facilitates **oxygen unloading** to the tissues (rightward shift of the oxygen-hemoglobin dissociation curve)
- This effect is related to **oxygen delivery** and does not alter the proportion of minute ventilation that reaches the alveoli for gas exchange
- Dead space ventilation remains unchanged
*Increasing the respiratory depth*
- Increasing respiratory depth increases **tidal volume (VT)**, which improves the **ratio** of alveolar ventilation to minute ventilation (VA/VE efficiency)
- However, the **absolute difference** (VE - VA) in L/min depends on the **total dead space volume**, which is not changed by increasing tidal volume alone
- While this improves ventilation efficiency, it does not directly reduce the dead space ventilation measured in L/min unless physiologic dead space itself decreases
*Increasing the respiratory rate*
- While increasing respiratory rate increases **minute ventilation (VE)**, it also increases the frequency of ventilating the **dead space** with each breath
- Since dead space ventilation (VD) = respiratory rate × dead space volume, increasing rate while keeping tidal volume constant will proportionally increase both VE and VD
- This can actually widen the absolute gap between VE and VA, making it less efficient
Respiratory mechanics and work of breathing US Medical PG Question 10: A 47-year-old patient returns to his primary care physician after starting aspirin two weeks ago for primary prevention of coronary artery disease. He complains that he wakes up short of breath in the middle of the night and has had coughing "attacks" three times. After discontinuing aspirin, what medication is most appropriate for prevention of similar symptoms in this patient?
- A. Prednisone
- B. Montelukast (Correct Answer)
- C. Albuterol
- D. Fluticasone
- E. Tiotropium
Respiratory mechanics and work of breathing Explanation: ***Montelukast***
- The patient is experiencing symptoms consistent with **aspirin-exacerbated respiratory disease (AERD)**, characterized by asthma symptoms, nasal polyps, and aspirin sensitivity.
- **Montelukast**, a **leukotriene receptor antagonist**, is effective in preventing these symptoms by blocking the inflammatory effects of leukotrienes, which are overproduced in AERD.
*Prednisone*
- While **oral corticosteroids** like prednisone can treat acute exacerbations of AERD, they are not suitable for long-term primary prevention due to significant side effects.
- Long-term use of prednisone is associated with issues like **osteoporosis**, **diabetes**, and **hypertension**.
*Albuterol*
- **Albuterol** is a **short-acting beta-agonist (SABA)** used for rescue relief of acute asthma symptoms and bronchospasm, not for long-term prevention.
- It does not address the underlying inflammatory pathway triggered by aspirin in AERD.
*Fluticasone*
- **Fluticasone** is an **inhaled corticosteroid (ICS)** primarily used for long-term control of asthma by reducing airway inflammation.
- While it can help with some asthma symptoms, it does not specifically prevent the aspirin-induced bronchospasm seen in AERD as effectively as leukotriene modifiers.
*Tiotropium*
- **Tiotropium** is a **long-acting muscarinic antagonist (LAMA)** primarily used in the maintenance treatment of **COPD** and sometimes for severe asthma.
- It works by bronchodilation but does not target the specific leukotriene pathway involved in AERD.
More Respiratory mechanics and work of breathing US Medical PG questions available in the OnCourse app. Practice MCQs, flashcards, and get detailed explanations.
