Compliance Basics - The Lung's Stretchiness

  • Definition: The lung's ability to stretch and expand in response to pressure changes. A measure of lung "stretchiness."
  • Formula: $C = \Delta V / \Delta P$ (Change in Volume / Change in Pressure).
    • High Compliance: Lungs are easy to inflate (e.g., emphysema).
    • Low Compliance: Lungs are stiff and difficult to inflate (e.g., fibrosis).
  • Graphically, it's the slope of the pressure-volume loop. Pressure-volume loops: Normal, Emphysema, Fibrosis, Saline

⭐ The two major determinants of lung compliance are the elastic properties of the lung tissue itself (elastin and collagen fibers) and the surface tension at the air-water interface within the alveoli.

  • ↓ Compliance significantly ↑ the work of breathing.

Restrictive Mechanics - The Stiff Lung

  • Pathophysiology: Characterized by ↓ lung compliance (stiff lungs), leading to ↑ elastic recoil.
  • Mechanism: Lungs cannot expand fully, requiring greater pressure change for a given volume change. This results in ↑ work of breathing.
  • Pulmonary Function Tests (PFTs):
    • Hallmark is a ↓ Total Lung Capacity (TLC).
    • ↓ Forced Vital Capacity (FVC) and ↓ Forced Expiratory Volume in 1 second (FEV₁).
    • The ratio $FEV₁/FVC$ is normal or ↑ (≥ 80%).

⭐ Because of the high elastic recoil, the expiratory flow rate is high relative to the small lung volume. This keeps the $FEV₁/FVC$ ratio normal or even elevated.

PV loop: Restrictive lung disease vs. normal

📌 Mnemonic (Causes): PAINT

  • Pleural abnormalities
  • Alveolar filling (edema)
  • Interstitial lung disease
  • Neuromuscular disease
  • Thoracic wall defects

PFTs & Diagnosis - Reading the Squiggles

  • Primary Defect: ↓ Total Lung Capacity (TLC) < 80% of predicted. All lung volumes are proportionally reduced (↓ FVC, RV, FRC).
  • Spirometry:
    • ↓ Forced Vital Capacity (FVC)
    • ↓ Forced Expiratory Volume in 1 sec (FEV1)
    • Normal or ↑ FEV1/FVC ratio (typically > 0.7). Both values decrease, but FVC often decreases more, raising the ratio.
  • Diffusing Capacity (DLCO): Crucial for localizing the problem.
    • Normal DLCO: Suggests an extrinsic cause (chest wall, pleura, neuromuscular).
      • Examples: Obesity, kyphoscoliosis, Myasthenia Gravis, ALS.
    • ↓ DLCO: Suggests an intrinsic (parenchymal) cause.
      • Examples: Idiopathic pulmonary fibrosis (IPF), asbestosis, sarcoidosis.

Flow-volume loops: normal, obstructive, restrictive

⭐ The classic restrictive flow-volume loop is a miniature version of the normal loop-a "witch's hat" shape-reflecting low volumes but normal expiratory airflow for that volume.

High‑Yield Points - ⚡ Biggest Takeaways

  • Restrictive lung diseases are defined by decreased lung compliance, making lungs stiff and increasing the work of breathing.
  • This leads to a uniform decrease in all lung volumes (↓ TLC, ↓ FRC, ↓ RV).
  • The lung pressure-volume loop is shifted down and to the right, reflecting lower volumes at any given pressure.
  • The FEV1/FVC ratio is characteristically normal or increased (typically > 80%).
  • Patients adopt a rapid, shallow breathing pattern to minimize elastic work.

Practice Questions: Restrictive lung disease mechanics

Test your understanding with these related questions

A 60-year-old woman with a history of emphysema has been referred by her pulmonologist for follow-up pulmonary function testing. During the test, the patient reaches a point where her airway pressure is equal to the atmospheric pressure. Which of the following is most likely to be found during this respiratory state?

1 of 5

Flashcards: Restrictive lung disease mechanics

1/10

At the original FRC, the tendency of the lung to collapse in a patient with pulmonary fibrosis is _____ than the tendency of the chest wall to expand

TAP TO REVEAL ANSWER

At the original FRC, the tendency of the lung to collapse in a patient with pulmonary fibrosis is _____ than the tendency of the chest wall to expand

greater
