Compliance 101 - The Stretch Factor

Pressure-volume loops showing decreasing compliance

  • Compliance ($C$) is the measure of lung and chest wall distensibility, or "stretch." It's the change in volume ($\[Delta V$) for a given change in pressure ($\[Delta P$).
    • Formula: $C = \Delta V / \Delta P$.
  • Total respiratory compliance depends on both the lungs and the chest wall.
    • Their individual compliances add reciprocally: $1/C_{Total} = 1/C_{Lung} + 1/C_{Chest Wall}$.

⭐ At Functional Residual Capacity (FRC), the outward recoil of the chest wall perfectly balances the inward recoil of the lungs. This is the equilibrium point of the combined system.

Lungs vs. Chest Wall - The Opposing Forces

  • Lungs: Possess elastic recoil, tending to collapse inward.
  • Chest Wall: Naturally recoils outward.
  • These opposing forces create negative intrapleural pressure, keeping the lungs expanded within the chest.

Lung-thorax relaxation pressure curve and compliance

  • Functional Residual Capacity (FRC): The equilibrium point.
    • Volume after normal, passive exhalation.
    • Inward pull of lungs is perfectly balanced by the outward pull of the chest wall.
    • Intrapleural pressure is negative (~-5 cm H₂O).
    • Total respiratory system compliance is highest at this volume.

⭐ At FRC, the stored potential energy in the respiratory system is minimal, meaning the work of breathing for the next tidal breath is minimized.

  • Compliance ($C$) is the change in volume for a given change in pressure: $C = \Delta V / \Delta P$.

Combined Compliance - The Sum of Parts

  • The total compliance of the respiratory system ($C_{total}$) depends on the individual compliances of the lung ($C_L$) and the chest wall ($C_{CW}$).
  • These components function in series, meaning their reciprocal compliances (elastances) are additive.
    • Formula: $1/C_{total} = 1/C_{L} + 1/C_{CW}$
    • Think of it like electrical resistors connected in parallel; the total resistance is less than any individual resistor.
  • Typical Values:
    • $C_L$ ≈ 200 mL/cm H₂O
    • $C_{CW}$ ≈ 200 mL/cm H₂O
    • $C_{total}$ ≈ 100 mL/cm H₂O

Lung, chest wall, and system compliance curves

⭐ At Functional Residual Capacity (FRC), the outward recoil of the chest wall is perfectly balanced by the inward recoil of the lungs. The system is at equilibrium, and the tendency of the chest wall to expand is equal and opposite to the tendency of the lungs to collapse.

Pathological States - When Compliance Fails

  • ↓ Decreased Compliance (Stiff Lungs): Lungs require more work to inflate.

    • Causes (Restrictive Diseases):
      • Pulmonary Fibrosis
      • Acute Respiratory Distress Syndrome (ARDS)
      • Pulmonary Edema
      • Pneumonia
  • ↑ Increased Compliance (Floppy Lungs): Lungs have reduced elastic recoil, impairing expiration.

    • Causes (Obstructive Diseases):
      • Emphysema (elastin degradation)
      • Aging

⭐ In ARDS, diffuse alveolar damage and inflammatory exudates inactivate surfactant, causing a severe drop in compliance and characteristic bilateral "ground-glass opacities" on imaging.

Flow-volume loops in lung diseases

High‑Yield Points - ⚡ Biggest Takeaways

  • Total respiratory compliance is less than the individual compliance of the lungs or chest wall, as they are in series.
  • The relationship is defined by the formula: 1/C_total = 1/C_lung + 1/C_chest_wall.
  • At Functional Residual Capacity (FRC), the system is at equilibrium; the inward recoil of the lungs is perfectly balanced by the outward spring of the chest wall.
  • Pulmonary fibrosis (↓ lung compliance) decreases total compliance.
  • Emphysema (↑ lung compliance) increases total compliance.

Practice Questions: Combined respiratory system compliance

Test your understanding with these related questions

An 85-year-old man with hypertension and type 2 diabetes mellitus is brought to the emergency department because of a 2-day history of shortness of breath. He has smoked one pack of cigarettes daily for 30 years. His temperature is 36.9°C (98.4°F), pulse is 100/min, respirations are 30/min, and blood pressure is 138/75 mm Hg. Pulmonary function testing shows decreased tidal volume and normal lung compliance. Which of the following is the most likely underlying etiology of this patient's tachypnea?

1 of 5

Flashcards: Combined respiratory system compliance

1/10

At highest lung volumes, both the lungs and the chest wall contribute to _____ forces on the lung-chest wall system

TAP TO REVEAL ANSWER

At highest lung volumes, both the lungs and the chest wall contribute to _____ forces on the lung-chest wall system

collapsing
