STEMI management algorithm

STEMI management algorithm

STEMI management algorithm

On this page

STEMI Recognition - Spotting the Tombstone

  • ECG Criteria: New ST-segment elevation at the J-point in ≥2 contiguous leads.

    • ≥1 mm in most leads.
    • ≥2 mm in leads V2-V3 (men ≥40), ≥2.5 mm (men <40), ≥1.5 mm (women).
  • Localization via ECG Leads:

MI LocationLeads with ST ElevationArtery Involved
AnteriorV1-V4LAD
SeptalV1-V2LAD
LateralI, aVL, V5-V6LCx
InferiorII, III, aVFRCA/LCx
PosteriorST depression V1-V3RCA/LCx

Immediate Therapy - MONA's Swift Kick

  • 📌 MONA guides initial therapy, but prioritize based on clinical need, not the acronym's order. Goal: ↓ myocardial O₂ demand & ↑ supply.
  • Aspirin: Chew 162-325 mg immediately.
  • Oxygen: Supplemental O₂ only if saturation < 90% or respiratory distress.
  • Nitroglycerin: Sublingual 0.4 mg q5min for pain; reduces preload.
    • ⚠️ Contraindications: Hypotension (SBP < 90), RV infarct, recent PDE-5 inhibitor use.
  • Morphine: For refractory chest pain despite nitrates.
  • Beta-Blockers: Oral metoprolol within 24h if stable (no HF, shock).

⭐ Of the initial therapies, only Aspirin has been proven to reduce mortality in acute MI.

Reperfusion Strategy - The Clock is Ticking

Primary goal is to restore coronary blood flow. The choice between PCI and fibrinolysis is time-critical, guided by facility capability and transfer times.

  • Percutaneous Coronary Intervention (PCI):

    • Preferred reperfusion strategy.
    • Goal: Door-to-balloon time < 90 minutes.
  • Fibrinolysis (e.g., Alteplase, Tenecteplase):

    • Use if timely PCI is unavailable.
    • Goal: Door-to-needle time < 30 minutes.

⭐ If a patient is at a non-PCI capable hospital, the decision to transfer for PCI vs. giving fibrinolysis hinges on the expected First Medical Contact-to-device time. If this time is anticipated to be > 120 minutes, fibrinolysis is the correct immediate action.

  • ⚠️ Key Absolute Contraindications to Fibrinolysis:
    • Any prior intracranial hemorrhage
    • Known structural cerebral vascular lesion
    • Ischemic stroke within 3 months
    • Suspected aortic dissection
    • Active bleeding or bleeding diathesis

Post-Reperfusion Care - Keep the Flow Going

  • Dual Antiplatelet Therapy (DAPT): Lifelong Aspirin + P2Y12 inhibitor (e.g., Ticagrelor, Prasugrel) for at least 12 months.
  • High-Intensity Statin: Atorvastatin 80 mg or Rosuvastatin 40 mg for all patients, regardless of baseline cholesterol.
  • Beta-Blocker: Start within 24 hrs if no signs of HF/shock. Continue for ≥3 years (indefinite if LVEF <40%).
  • ACE Inhibitor / ARB: Start within 24 hrs, especially with anterior MI, LVEF <40%, or heart failure.
  • Aldosterone Antagonist: Add if LVEF ≤40% with HF symptoms or diabetes.
  • 📌 Mnemonic: BASAA (Beta-blocker, Antiplatelet, Statin, ACEi, Aldosterone antagonist).

⭐ Prasugrel is contraindicated in patients with a prior history of stroke or TIA due to an increased risk of intracranial hemorrhage.

High‑Yield Points - ⚡ Biggest Takeaways

  • Time is muscle: Rapid EKG diagnosis is paramount for initiating reperfusion.
  • PCI is the gold standard: Aim for a door-to-balloon time of < 90 minutes.
  • Use fibrinolysis if PCI is delayed > 120 minutes; door-to-needle goal is < 30 minutes.
  • Immediate medications: Give chewed aspirin, a P2Y12 inhibitor, and anticoagulation.
  • Post-reperfusion care: Continue Dual Antiplatelet Therapy (DAPT), a high-intensity statin, beta-blocker, and ACE inhibitor.
  • Avoid nitrates in right-sided MI or with recent PDE-5 inhibitor use.

Practice Questions: STEMI management algorithm

Test your understanding with these related questions

A 58-year-old man comes to the emergency department for complaints of crushing chest pain for 4 hours. He was shoveling snow outside when the pain started. It is rated 7/10 and radiates to his left arm. An electrocardiogram (ECG) demonstrates ST-segment elevation in leads V2-4. He subsequently undergoes percutaneous coronary intervention (PCI) and is discharged with aspirin, clopidogrel, carvedilol, atorvastatin, and lisinopril. Five days later, the patient is brought to the emergency department by his wife with complaints of dizziness. He reports lightheadedness and palpitations for the past 2 hours but otherwise feels fine. His temperature is 99.7°F (37.6°C), blood pressure is 95/55 mmHg, pulse is 105/min, and respirations are 17/min. A pulmonary artery catheter is performed and demonstrates an increase in oxygen concentration at the pulmonary artery. What finding would you expect in this patient?
