Anatomical variants in imaging US Medical PG Practice Questions and MCQs
Practice US Medical PG questions for Anatomical variants in imaging. These multiple choice questions (MCQs) cover important concepts and help you prepare for your exams.
Anatomical variants in imaging US Medical PG Question 1: A 75-year-old man presents to the clinic for chronic fatigue of 3 months duration. Past medical history is significant for type 2 diabetes and hypertension, both of which are controlled with medications, as well as constipation. He denies any fever, weight loss, pain, or focal neurologic deficits. A complete blood count reveals microcytic anemia, and a stool guaiac test is positive for blood. He is subsequently evaluated with a colonoscopy. The physician notes some “small pouches” in the colon despite poor visualization due to inadequate bowel prep. What is the blood vessel that supplies the area with the above findings?
- A. Ileocolic artery
- B. Superior mesenteric artery
- C. Inferior mesenteric artery (Correct Answer)
- D. Middle colic artery
- E. Right colic artery
Anatomical variants in imaging Explanation: ***Inferior mesenteric artery***
- The patient's **microcytic anemia** and **positive stool guaiac test** indicate chronic gastrointestinal blood loss, highly suggestive of **diverticulosis** presenting as "small pouches" in the colon.
- Diverticulosis commonly affects the **descending colon** and **sigmoid colon**, which are primarily supplied by branches of the **inferior mesenteric artery**.
*Ileocolic artery*
- The ileocolic artery is a branch of the **superior mesenteric artery** and supplies the **ileum**, **cecum**, and **ascending colon**.
- Diverticula are less commonly found in these regions compared to the left colon.
*Superior mesenteric artery*
- The superior mesenteric artery supplies the **midgut derivatives**, including the **small intestine** and the **right half of the large intestine** (up to the distal transverse colon).
- While it supplies a large portion of the GI tract, the typical location of diverticulosis (descending and sigmoid colon) is outside its primary distribution.
*Middle colic artery*
- The middle colic artery is a branch of the **superior mesenteric artery** and supplies the **transverse colon**.
- While diverticula can occur in the transverse colon, it is not the most common location, and the inferior mesenteric artery supplies the areas most frequently affected.
*Right colic artery*
- The right colic artery is a branch of the **superior mesenteric artery** and supplies the **ascending colon**.
- Diverticula are less frequently found in the ascending colon compared to the descending and sigmoid colon.
Anatomical variants in imaging US Medical PG Question 2: A 56-year-old man presents to the emergency room after being in a motor vehicle accident. He was driving on an icy road when his car swerved off the road and ran head on into a tree. He complains of severe pain in his right lower extremity. He denies loss of consciousness during the accident. His past medical history is notable for poorly controlled hypertension, hyperlipidemia, and major depressive disorder. He takes enalapril, atorvastatin, and sertraline. His temperature is 99.1°F (37.3°C), blood pressure is 155/85 mmHg, pulse is 110/min, and respirations are 20/min. On exam, he is alert and fully oriented. He is unable to move his right leg due to pain. Sensation is intact to light touch in the sural, saphenous, tibial, deep peroneal, and superficial peroneal distributions. His leg appears adducted, flexed, and internally rotated. An anteroposterior radiograph of his pelvis would most likely demonstrate which of the following findings?
- A. Fracture line extending between the greater and lesser trochanters
- B. Femoral head larger than contralateral side and inferior to acetabulum
- C. Fracture line extending through the femoral neck
- D. Fracture line extending through the subtrochanteric region of the femur
- E. Femoral head smaller than contralateral side and posterior to acetabulum (Correct Answer)
Anatomical variants in imaging Explanation: ***Femoral head smaller than contralateral side and posterior to acetabulum***
- This presentation is consistent with a **posterior hip dislocation**, which typically occurs with an **axial load** on a flexed hip, common in head-on collisions.
- On radiographs, the femoral head appears **smaller** due to magnification differences and is displaced **posteriorly** relative to the acetabulum. The affected leg is classically **shortened, adducted, and internally rotated**.
*Fracture line extending between the greater and lesser trochanters*
- This describes an **intertrochanteric hip fracture**, which typically presents with the leg **externally rotated** and **abducted**, not internally rotated and adducted.
- While caused by trauma, the clinical presentation does not align with the patient's physical exam findings.
*Femoral head larger than contralateral side and inferior to acetabulum*
- This describes an **anterior hip dislocation**, which is far less common and would present with the leg typically held in **abduction** and **external rotation**. The femoral head would also appear **larger** due to magnification from being anteriorly displaced.
- The patient's presentation of adduction and internal rotation is inconsistent with an anterior dislocation.
*Fracture line extending through the femoral neck*
- A **femoral neck fracture** usually presents with the leg in **external rotation** and **shortening**, and often involves older patients with osteoporosis after falls.
- While a severe impact could cause this, the characteristic adduction and internal rotation point more strongly to a dislocation.
*Fracture line extending through the subtrochanteric region of the femur*
- A **subtrochanteric fracture** involves the shaft of the femur just below the trochanters and commonly presents with significant pain and inability to bear weight.
- This type of fracture does not typically result in the specific adducted and internally rotated leg position seen with hip dislocations.
Anatomical variants in imaging US Medical PG Question 3: A newborn of a mother with poor antenatal care is found to have a larger than normal head circumference with bulging fontanelles. Physical examination reveals a predominant downward gaze with marked eyelid retraction and convergence-retraction nystagmus. Ultrasound examination showed dilated lateral ventricles and a dilated third ventricle. Further imaging studies reveal a solid mass in the pineal region. Which of the following is the most likely underlying pathophysiological mechanism responsible for the neurological signs in this patient?
- A. Stenotic intraventricular foramina
- B. Dilated cisterna magna
- C. Hypertrophic arachnoid granulations
- D. Normal lumbar puncture opening pressure
- E. Compression of periaqueductal grey matter (Correct Answer)
Anatomical variants in imaging Explanation: ***Compression of periaqueductal grey matter***
- The constellation of a **large head circumference**, **bulging fontanelles**, **dilated lateral and third ventricles**, and a **pineal region mass** indicates **obstructive hydrocephalus**.
- The **downward gaze** (sunsetting sign), **marked eyelid retraction**, and **convergence-retraction nystagmus** are classic signs of **Parinaud's syndrome**, which results from compression of the **dorsal midbrain** (periaqueductal gray matter and superior colliculi) due to **hydrocephalus** or a **pineal tumor**.
*Stenotic intraventricular foramina*
- While **stenotic intraventricular foramina** (of Monro) can lead to **hydrocephalus** by obstructing CSF flow from the lateral to the third ventricle, the imaging specifically mentions a **dilated third ventricle**.
- This suggests the obstruction is *distal* to the third ventricle, likely at the aqueduct of Sylvius, rather than the foramina of Monro.
*Dilated cisterna magna*
- A **dilated cisterna magna** is a characteristic finding in conditions like the **Dandy-Walker malformation** or benign enlargement of the subarachnoid spaces.
- This finding would not directly explain the obstructive hydrocephalus with dilated lateral and third ventricles, nor the specific signs of Parinaud's syndrome.
*Hypertrophic arachnoid granulations*
- **Arachnoid granulations** are responsible for **CSF reabsorption** into the venous system. Hypertrophic arachnoid granulations would theoretically increase CSF reabsorption, leading to **decreased intracranial pressure**, rather than hydrocephalus.
- They do not cause compressive syndromes associated with a pineal mass and obstructive hydrocephalus.
*Normal lumbar puncture opening pressure*
- A **normal lumbar puncture opening pressure** in the presence of **bulging fontanelles** and **dilated ventricles** is diagnostically contradictory for hydrocephalus.
- Obstructive hydrocephalus, as described, would typically lead to **elevated intracranial pressure** and thus an **elevated opening pressure**.
Anatomical variants in imaging US Medical PG Question 4: A 72-year-old man presents to his physician’s office with complaints of a cough and painful breathing for the last 2 months. He says that he has also observed a 5 kg (11 lb) weight loss during the past month. He is relatively healthy but the sudden change in his health worries him. Another problem that he has been facing is the swelling of his face and arms at unusual times of the day. He says that the swelling is more prominent when he is supine. He has also lately been experiencing difficulty with his vision. He consumes alcohol occasionally and quit smoking last year following a 25-year history of smoking. On examination, the patient is noted to have distended veins in the chest and arms. His jugular veins are distended. Physical examination shows ptosis of the right eye and miosis of the right pupil. His lungs are clear to auscultation. He is sent for an X-ray for further evaluation of his condition. Which of the following is the most likely site for the detection of the nodule on CT scan?
- A. Right upper lobe (Correct Answer)
- B. Brain stem metastasis
- C. Left upper lobe
- D. Central hilar region
- E. Peripheral bronchial region
Anatomical variants in imaging Explanation: ***Right upper lobe***
- The patient's symptoms, including **Ptosis**, **Miosis**, and **Anhidrosis** of the right side of the face, are indicative of **Horner's syndrome**.
- **Horner's syndrome** in a patient with a smoking history, cough, weight loss, and edema of the face and arms (suggesting **SVC syndrome**) points strongly to a **Pancoast tumor** (superior sulcus tumor).
- The tumor is located in the **right upper lobe** specifically because the **Horner's syndrome is right-sided** (right ptosis, right miosis). Pancoast tumors cause **ipsilateral** Horner's syndrome by invading the sympathetic chain on the same side as the tumor.
*Brain stem metastasis*
- While a brain stem lesion could cause vision difficulties and neurological deficits, it does not explain the **SVC syndrome** (facial/arm swelling, distended veins) or the pulmonary symptoms like cough and weight loss.
- **Pancoast tumors** can cause vision changes due to **Horner's syndrome**, not necessarily brain metastasis.
*Left upper lobe*
- Although a tumor in the left upper lobe could cause similar symptoms to a right upper lobe tumor, the examination findings of **ptosis** and **miosis** on the **right side** localize the lesion to the **right apex**.
- **Horner's syndrome** develops on the **ipsilateral side** of the sympathetic chain disruption.
*Central hilar region*
- A tumor in the central hilar region would typically cause symptoms related to bronchial obstruction or compression of central structures, such as a persistent cough, hemoptysis, or SVC syndrome if it's large enough.
- However, it is less likely to directly cause **Horner's syndrome** with ptosis and miosis localized to one eye, which is a hallmark of an apical (Pancoast) tumor affecting the sympathetic chain.
*Peripheral bronchial region*
- A peripheral bronchial nodule would usually present with a cough, possibly hemoptysis, or be asymptomatic until it grows large enough to cause obstructive symptoms or pleural involvement.
- It is unlikely to cause both **SVC syndrome** and **Horner's syndrome** simultaneously, which are characteristic of an apical lung tumor.
Anatomical variants in imaging US Medical PG Question 5: A 2-year-old child is brought to the emergency department with rapid breathing and a severe cyanotic appearance of his lips, fingers, and toes. He is known to have occasional episodes of mild cyanosis, especially when he is extremely agitated. This is the worst episode of this child’s life, according to his parents. He was born with an APGAR score of 8 via a normal vaginal delivery. His development is considered delayed compared to children of his age. History is significant for frequent squatting after strenuous activity. On auscultation, there is evidence of a systolic ejection murmur at the left sternal border. On examination, his oxygen saturation is 71%, blood pressure is 81/64 mm Hg, respirations are 42/min, pulse is 129/min, and temperature is 36.7°C (98.0°F). Which of the following will most likely be seen on chest x-ray (CXR)?
- A. Egg on a string
- B. Boot-shaped heart (Correct Answer)
- C. Increased pulmonary vascular markings
- D. Cardiomegaly with globular heart
- E. Figure-3 sign
Anatomical variants in imaging Explanation: ***Boot-shaped heart***
- The patient's presentation with **cyanosis**, **squatting spells**, and a **systolic ejection murmur** is classic for **Tetralogy of Fallot** (TOF).
- A **boot-shaped heart** (Coeur en sabot) on chest X-ray is a characteristic finding in TOF, caused by **right ventricular hypertrophy** and an upturned cardiac apex, leading to a concave pulmonary artery segment.
*Egg on a string*
- This CXR finding is characteristic of **Transposition of the Great Arteries (TGA)**, where the aorta and pulmonary artery are switched, creating an "egg" outline with a narrow vascular pedicle ("string").
- TGA typically presents with severe **cyanosis** from birth and does not usually involve squatting spells or a loud systolic murmur from a prominent **right ventricular outflow tract obstruction**.
*Increased pulmonary vascular markings*
- This finding is common in conditions with **left-to-right shunting** or **increased pulmonary blood flow**, such as a **ventricular septal defect (VSD)** or **patent ductus arteriosus (PDA)**.
- In Tetralogy of Fallot, there is typically **decreased pulmonary blood flow** due to **pulmonic stenosis**, leading to *decreased* pulmonary vascular markings.
*Cardiomegaly with globular heart*
- A **globular heart** is a non-specific finding often associated with **pericardial effusion** or **dilated cardiomyopathy**, where the heart appears enlarged and rounded.
- While TOF can cause cardiomegaly (specifically **right ventricular hypertrophy**), the characteristic shape is "boot-shaped," not globally enlarged or globular.
*Figure-3 sign*
- The **figure-3 sign** on CXR is pathognomonic for **aortic coarctation**, caused by indentation of the aorta at the coarctation site and post-stenotic dilation.
- This condition presents with signs of **heart failure**, **differential cyanosis** (if preductal), and **blood pressure discrepancies** between upper and lower extremities, not the cyanotic spells and squatting seen in this case.
Anatomical variants in imaging US Medical PG Question 6: An 11-year-old girl is brought to the office by her mother due to complaint of intermittent and severe periumbilical pain for 1 day. She does not have any significant past medical history. She provides a history of a recent school trip to the suburbs. On physical examination, there is a mild tenderness around the umbilicus without any distension or discharge. There is no rebound tenderness. Bowel sounds are normal. An abdominal imaging shows enlarged mesenteric lymph nodes, and she is diagnosed with mesenteric lymphadenitis. However, incidentally, a mass of tissue was seen joining the inferior pole of both kidneys as shown in the image. Which of the following best describes this renal anomaly?
- A. Fused kidneys ascend beyond superior mesenteric artery.
- B. Rapid progression to acute renal failure
- C. Kidneys are usually non-functional.
- D. Increased risk of developing renal vein thrombosis
- E. Association with ureteropelvic junction obstruction (UPJO) (Correct Answer)
Anatomical variants in imaging Explanation: ***Association with ureteropelvic junction obstruction (UPJO)***
- **Horseshoe kidney** is characterized by the fusion of the lower poles (most common) or upper poles of the kidneys, forming a U-shape. This anomaly is associated with an increased incidence of **ureteropelvic junction obstruction (UPJO)** due to the abnormal course of the ureters over the isthmus.
- The abnormal ascent of the fused kidneys can also lead to an increased incidence of other anomalies such as **vesicoureteral reflux**, **renal calculi**, and recurrent urinary tract infections.
*Fused kidneys ascend beyond superior mesenteric artery.*
- The **horseshoe kidney** typically **fails to ascend** completely during development because its isthmus (the fused part) can get trapped under the **inferior mesenteric artery**.
- Therefore, fused kidneys in horseshoe kidney are often found in a **lower position** than normal, not ascended beyond the superior mesenteric artery.
*Rapid progression to acute renal failure*
- While horseshoe kidney can be associated with an increased risk of complications (like UPJO, stones, infections), it does not inherently lead to **rapid progression to acute renal failure**.
- Many individuals with a horseshoe kidney have **normal renal function** without significant clinical manifestations.
*Kidneys are usually non-functional.*
- The presence of a horseshoe kidney **does not typically mean the kidneys are non-functional**.
- In most cases, both renal units of a horseshoe kidney are **functional**, although they may be at increased risk for complications that could impact function over time.
*Increased risk of developing renal vein thrombosis*
- There is **no established increased risk** of developing **renal vein thrombosis** specifically associated with horseshoe kidney.
- The primary vascular anomalies associated with horseshoe kidney relate to the arterial supply and variations in the number and origin of renal arteries, not typically venous thrombosis.
Anatomical variants in imaging US Medical PG Question 7: A 65-year-old man presents to the emergency department with abdominal pain and a pulsatile abdominal mass. Further examination of the mass shows that it is an abdominal aortic aneurysm. A computed tomography scan with contrast reveals an incidental finding of a horseshoe kidney, and the surgeon is informed of this finding prior to operating on the aneurysm. Which of the following may complicate the surgical approach in this patient?
- A. Anomalous origins of multiple renal arteries (Correct Answer)
- B. Low glomerular filtration rate due to unilateral renal agenesis
- C. Proximity of the fused kidney to the celiac artery
- D. Abnormal relationship between the kidney and the superior mesenteric artery
- E. There are no additional complications
Anatomical variants in imaging Explanation: ***Anomalous origins of multiple renal arteries***
- A horseshoe kidney often receives its blood supply from **multiple renal arteries** arising anomalously from the aorta, iliac arteries, or inferior mesenteric artery.
- These aberrant vessels can cross the surgical field and complicate **abdominal aortic aneurysm repair**, increasing the risk of injury and hemorrhage.
*Low glomerular filtration rate due to unilateral renal agenesis*
- This patient has a **horseshoe kidney**, which involves fused kidneys, not renal agenesis (absence of a kidney).
- While chronic kidney disease can be associated with horseshoe kidneys, **unilateral agenesis** is a distinct condition and not described in this scenario.
*Proximity of the fused kidney to the celiac artery*
- The fused portion of a horseshoe kidney (the **isthmus**) typically lies anterior to the great vessels at the L3-L5 vertebral level, below the origin of the celiac artery.
- Therefore, its proximity to the **celiac artery** is generally not the primary surgical concern during abdominal aortic aneurysm repair.
*Abnormal relationship between the kidney and the superior mesenteric artery*
- The superior mesenteric artery typically originates from the aorta above the level of the horseshoe kidney's isthmus.
- While other anomalies can exist, an **abnormal relationship** between the kidney and the superior mesenteric artery is not a classic or primary complication of horseshoe kidney during AAA repair.
*There are no additional complications*
- The presence of a horseshoe kidney significantly increases the complexity of **abdominal aortic aneurysm** surgery.
- The potential for **vascular anomalies** and altered anatomical relationships makes this statement incorrect, as there are definite additional surgical considerations.
Anatomical variants in imaging US Medical PG Question 8: A 23-year-old woman presents to the emergency department with an acute exacerbation of her 3-month history of low back and right leg pain. She says she has had similar symptoms in the past, but this time the pain was so excruciating, it took her breath away. She describes the pain as severe, shock-like, and localized to her lower back and radiating straight down the back of her right thigh and to her calf, stopping at the ankle. Her pain is worse in the morning, and, sometimes, the pain wakes her up at night with severe buttock and posterior thigh pain but walking actually makes the pain subside somewhat. The patient reports no smoking history or alcohol or drug use. She has been working casually as a waitress and does find bending over tables a strain. She is afebrile, and her vital signs are within normal limits. On physical examination, her left straight leg raise test is severely limited and reproduces her buttock pain at 20° of hip flexion. Pain is worsened by the addition of ankle dorsiflexion. The sensation is intact. Her L4 and L5 reflexes are normal, but her S1 reflex is absent on the right side. A CT of the lumbar spine shows an L5–S1 disc protrusion with right S1 nerve root compression. Which of the following muscle-nerve complexes is involved in producing an S1 reflex?
- A. Adductors-obturator nerve
- B. Gastrocnemius/soleus-tibial nerve (Correct Answer)
- C. Sartorius-femoral nerve
- D. Tibialis posterior-tibial nerve
- E. Quadriceps femoris-femoral nerve
Anatomical variants in imaging Explanation: ***Gastrocnemius/soleus-tibial nerve***
- The S1 reflex (also known as the **Achilles reflex**) tests the integrity of the **S1 nerve root**.
- This reflex arc involves the **gastrocnemius and soleus muscles**, which are innervated by the **tibial nerve** (derived primarily from S1).
*Adductors-obturator nerve*
- The **adductor muscles** of the thigh are primarily innervated by the **obturator nerve** (L2-L4).
- This complex is not involved in generating the **Achilles reflex**.
*Sartorius-femoral nerve*
- The **sartorius muscle** is innervated by the **femoral nerve** (L2-L4).
- This muscle and nerve are not part of the **S1 reflex arc**.
*Tibialis posterior-tibial nerve*
- The **tibialis posterior muscle** is innervated by the **tibial nerve** (L4-S3), but its primary role is in ankle inversion and plantarflexion, not the main component of the **Achilles reflex**.
- While the tibial nerve is involved in the S1 reflex, the **gastrocnemius and soleus** are the primary muscles for this reflex.
*Quadriceps femoris-femoral nerve*
- The **quadriceps femoris muscle** is responsible for the **patellar reflex** (knee jerk reflex), which tests the integrity of the **L3-L4 nerve roots**.
- It is innervated by the **femoral nerve** and is not involved in the **S1 reflex**.
Anatomical variants in imaging US Medical PG Question 9: A 27-year-old female ultramarathon runner presents to the physician with complaints of persistent knee pain. She describes the pain to be located in the anterior area of her knee and is most aggravated when she performs steep descents down mountains, though the pain is present with running on flat roads, walking up and down stairs, and squatting. Which of the following would most likely be an additional finding in this patient’s physical examination?
- A. Pain upon pressure placed on the lateral aspect of the knee
- B. Pain upon pressure placed on the medial aspect of the knee
- C. Pain upon compression of the patella while the patient performs flexion and extension of the leg (Correct Answer)
- D. Excessive posterior displacement of the tibia
- E. Excessive anterior displacement of the tibia
Anatomical variants in imaging Explanation: ***Pain upon compression of the patella while the patient performs flexion and extension of the leg***
- The patient's symptoms (anterior knee pain aggravated by activity, especially descents, stairs, and squatting) are classic for **patellofemoral pain syndrome (runner's knee)**.
- The **patellofemoral grind test** (compressing the patella during knee flexion and extension) is a specific diagnostic maneuver that reproduces this pain in affected individuals.
*Pain upon pressure placed on the lateral aspect of the knee*
- This finding is more characteristic of conditions like **iliotibial band syndrome** or **lateral meniscus injury**, which typically present with lateral knee pain.
- The patient describes general anterior knee pain, not specifically lateral pain.
*Pain upon pressure placed on the medial aspect of the knee*
- This suggests conditions such as **medial collateral ligament (MCL) injury**, **pes anserine bursitis**, or **medial meniscus injury**.
- These conditions typically present with medial knee pain, which does not match the patient's anterior knee pain.
*Excessive posterior displacement of the tibia*
- This indicates **posterior cruciate ligament (PCL) insufficiency**, which is assessed by the posterior drawer test or sag sign.
- PCL injuries typically result from direct trauma to the anterior tibia or hyperflexion, and pain is often localized posteriorly or deep within the knee, not specifically anteriorly aggravated by the described activities.
*Excessive anterior displacement of the tibia*
- This finding is indicative of an **anterior cruciate ligament (ACL) rupture**, assessed by the Lachman test or anterior drawer test.
- ACL injuries usually result from a twisting injury or hyperextension and often present with acute swelling, instability, and giving way, which are not the primary complaints of this patient with chronic, activity-related anterior knee pain.
Anatomical variants in imaging US Medical PG Question 10: A 13-year-old girl is brought to the physician by her father because of a 1-month history of pain in her right knee. She is a competitive volleyball player and has missed several games recently due to pain. Examination shows swelling distal to the right knee joint on the anterior surface of the proximal tibia; there is no overlying warmth or deformity. Extension of the right knee against resistance is painful. Which of the following structures is attached to the affected anterior tibial area?
- A. Patellar ligament (Correct Answer)
- B. Iliotibial band
- C. Pes anserinus tendon
- D. Quadriceps tendon
- E. Anterior cruciate ligament
Anatomical variants in imaging Explanation: ***Patellar ligament***
- The symptoms described, particularly **pain in the right knee worse with activity** in a young, active individual with **swelling distal to the knee joint on the anterior surface of the proximal tibia**, are classic for **Osgood-Schlatter disease**.
- This condition involves inflammation of the **patellar ligament** (also known as the patellar tendon) insertion onto the **tibial tuberosity**, which is the bony prominence on the anterior proximal tibia.
*Iliotibial band*
- The **iliotibial band (IT band)** runs along the lateral aspect of the thigh and inserts on the **lateral condyle of the tibia (Gerdy's tubercle)**, not the anterior proximal tibia.
- **IT band syndrome** typically causes lateral knee pain, often seen in runners, and not central anterior tibial swelling.
*Pes anserinus tendon*
- The **pes anserinus tendon** is formed by the conjoined tendons of the **sartorius**, **gracilis**, and **semitendinosus muscles**, inserting on the **medial proximal tibia**.
- Inflammation here (**pes anserinus bursitis/tendinitis**) would cause pain and swelling on the medial side of the knee, not the anterior aspect.
*Quadriceps tendon*
- The **quadriceps tendon** connects the quadriceps muscles to the **superior pole of the patella**, not the anterior proximal tibia.
- Conditions affecting this tendon typically cause pain above or at the patella, not distal to the knee joint.
*Anterior cruciate ligament*
- The **anterior cruciate ligament (ACL)** is an intra-articular ligament that connects the **femur to the tibia within the knee joint**.
- An **ACL injury** typically presents with acute pain, instability, and a "popping" sensation, not chronic swelling on the anterior aspect of the proximal tibia.
More Anatomical variants in imaging US Medical PG questions available in the OnCourse app. Practice MCQs, flashcards, and get detailed explanations.
