Renal and Urinary Tract Imaging

On this page

Imaging Modalities & Normal Anatomy - Toolkit Tour

  • Key Structures: Kidneys (cortex, medulla, pelvicalyceal system; 9-13 cm length), ureters (constrictions: PUJ, pelvic brim, VUJ), bladder, urethra. Visualized variably by modality.
ModalityFocusPro(s)Con(s)
X-ray KUBCalcification, gasBasic, cheapLow detail
USGHydronephrosis, cysts, renal stonesNo radiation, real-timeOperator-dependent, gas
IVUUrothelial detail, functionFunctional, anatomyContrast risk, radiation
CT (NCCT/CECT)Stones (NCCT), masses, trauma (CECT)Gold standard (stones), detailRadiation, contrast (CECT)
MRISoft tissue, problem-solvingNo X-ray, superior contrast resCost, time, limited availability
Nuclear ScansRenal function (GFR), drainageQuantitative functionPoor anatomy

⭐ Non-contrast CT (NCCT) KUB is the gold standard for suspected renal/ureteric colic.

Urolithiasis & Obstruction - Stone Patrol

  • NCCT KUB: Gold standard for stone detection (all types).
  • USG KUB: Initial, pregnancy, children; detects hydronephrosis, renal stones.
    • Twinkling artifact on color Doppler.
  • X-ray KUB: Only radiopaque stones (Calcium, Struvite).
  • Stone Types:
    • Calcium Oxalate (most common, opaque).
    • Struvite (infection, staghorn, opaque).
    • Uric Acid (lucent on X-ray, visible on CT/USG). 📌 Radiolucent: Uric acid, Xanthine, Indinavir.
    • Cystine (faintly opaque/lucent).
  • Obstruction Signs: Hydronephrosis (Grades I-IV), perinephric stranding on CT.
  • Intervention: Often for stones >5-7 mm.

Loading diagram…

⭐ Twinkling artifact on color Doppler USG is highly suggestive of small renal calculi, even when not clearly visible on B-mode imaging.

Renal Masses & Cysts - Lump Busters

  • Renal Cell Carcinoma (RCC): Most common renal malignancy.
    • Subtypes: Clear Cell (most common), Papillary, Chromophobe.
    • CT: Solid, enhancing mass (>15-20 HU ↑). Necrosis, calcification.
  • Angiomyolipoma (AML): Benign; fat, smooth muscle, vessels.
    • CT: Fat (HU < -10).
    • Bleed risk if > 4 cm.
  • Oncocytoma: Benign; central scar (non-specific).
  • Transitional Cell Carcinoma (TCC): Urothelial origin; filling defect in collecting system.

Bosniak Classification of Renal Cysts

CategoryDescriptionMalignancy RiskManagement
ISimple cyst, thin wall, no septa/calcification~0%Ignore
IIFew thin septa, fine calcification~0%Ignore
IIFMore septa, minimal smooth wall thickening~5%Follow-up
IIIThick/irregular septa/wall, measurable enhancement~50%Surgery/Biopsy
IVSolid enhancing components~100%Surgery

Approach to Renal Mass

Loading diagram…

Renal Infections & Trauma - Crisis Crew

  • Acute Pyelonephritis (APN):

    • USG: Often normal; ↑renal size, ↓CMD.
    • CECT (Gold Std): Wedge-shaped ↓enhancement, perinephric stranding.
  • Complications:

    • Renal Abscess: CECT: liquefaction, ring enhancement.
    • Emphysematous Pyelonephritis (EPN): Gas in kidney. CECT for staging (Type 1 vs 2).

      ⭐ Emphysematous pyelonephritis, characterized by gas in the renal parenchyma/collecting system, is a life-threatening infection often seen in diabetics.

    • Pyonephrosis: Pus in obstructed system. USG: debris/levels.
    • XGPN: Chronic; staghorn (Proteus). "Bear paw sign" (CECT).
  • Renal Trauma:

    • CECT: Modality of choice.
    • AAST Renal Injury Scale:
      GradeDescription
      IContusion/subcapsular hematoma, non-expanding.
      IILaceration < 1 cm cortex, no urine extravasation.
      IIILaceration > 1 cm cortex, no urine extravasation.
      IVLaceration to collecting system; segmental vascular injury.
      VShattered kidney; main renal artery/vein injury.

High‑Yield Points - ⚡ Biggest Takeaways

  • IVU is gold standard for papillary necrosis & medullary sponge kidney.
  • USG is initial choice for hydronephrosis, renal masses & calculi in pregnancy.
  • CT Urography excels in hematuria evaluation, complex cysts & RCC staging.
  • Doppler USG is key for renal artery stenosis & renal vein thrombosis.
  • MCU for VUR & PUV; RGU for anterior urethral strictures.
  • Wilms' tumor shows "claw sign", indicating intrarenal origin_

Unlock the full lesson and continue reading

Signup to continue reading this lesson and unlimited access questions, flashcards, AI notes, and more

Scan to download app

Scan to download
UNLOCK FREE ACCESS

Practice Questions: Renal and Urinary Tract Imaging

  1. 1. A patient with previous pulmonary tuberculosis presents with abdominal pain, diarrhoea, and weight loss. Which abnormality is demonstrated on this barium study?

    • A. Pulled-up cecum
    • B. Dilated small-bowel loops
    • C. Colonic diverticular outpouchings
    • D. Extraluminal contrast leakage
    Show answer

    Answer: A. Pulled-up cecum

    Pulled-up cecum is demonstrated by the elevated, contracted cecal region on the barium study, a classical association of ileocecal tuberculosis. Dilated small-bowel loops would support obstruction, which tuberculous strictures can cause, but an obstructive pattern is not the defining finding shown here. Colonic diverticular outpouchings would appear as contrast-filled sacs extending beyond the bowel contour and are not demonstrated. Extraluminal contrast leakage would indicate perforation and is not demonstrated.

  2. 2. What is the most specific diagnosis of the tooth indicated by the arrow in this maxillary occlusal radiograph of an 8-year-old child?

    • A. Ghost tooth
    • B. Odontoma
    • C. Mesiodens
    • D. Impacted tooth
    Show answer

    Answer: C. Mesiodens

    The arrow identifies an additional tooth in the anterior maxillary midline, characteristic of a mesiodens. This diagnosis is based on the supernumerary tooth’s location, as described in standard oral pathology and oral radiology texts. Impaction describes eruption status rather than the specific developmental anomaly: a mesiodens may itself be impacted, and non-eruption on a single radiograph does not by itself establish impaction. Regional odontodysplasia produces poorly mineralised, ghost-like teeth rather than this discrete additional tooth. Odontoma is an odontogenic hamartoma appearing as a cluster of denticles or an irregular calcified mass, rather than a solitary supernumerary tooth in the maxillary midline.

  3. 3. What is the most likely diagnosis of a child with the following chest X-ray finding?

    • A. TGA
    • B. TOF
    • C. TAPVC
    • D. EA
    Show answer

    Answer: B. TOF

    Tetralogy of Fallot (TOF) - The boot-shaped heart of TOF results from right ventricular hypertrophy, an upturned apex, and a concave pulmonary artery segment; associated reduced pulmonary vascularity supports this diagnosis. - This radiographic appearance reflects the classic TOF combination of VSD, pulmonary stenosis, overriding aorta, and right ventricular hypertrophy, making TOF the most likely diagnosis. Transposition of Great Arteries (TGA) - TGA classically produces an “egg-on-a-string” or “egg-on-side” appearance, with a narrow upper mediastinum and cardiomegaly rather than the described boot-shaped configuration. - TGA results from parallel circulations, with the aorta arising from the right ventricle and the pulmonary artery from the left ventricle; this anatomy does not explain the characteristic pulmonary oligemia described here. Total Anomalous Pulmonary Venous Connection (TAPVC) - Supracardiac TAPVC classically causes a “snowman” or “figure-of-8” heart, produced by enlargement of the vertical vein and superior vena cava, not a boot-shaped cardiac silhouette. - TAPVC involves all four pulmonary veins draining abnormally into the systemic circulation; its characteristic radiographic configuration differs from the pulmonary oligemia associated with TOF. Ebstein's Anomaly (EA) - Ebstein’s anomaly typically causes massive right atrial enlargement and cardiomegaly, sometimes described as a “box-shaped” heart, rather than an upturned apex with a concave pulmonary artery segment. - The underlying abnormality is apical displacement of the tricuspid valve, causing right ventricular atrialization; this does not produce the classic boot-shaped heart with pulmonary oligemia.

  4. 4. Most common type of renal carcinoma is:

    • A. Clear cell type
    • B. Papillary type
    • C. Chromophobe type
    • D. Collecting duct type
    Show answer

    Answer: A. Clear cell type

    Clear cell type - Clear cell carcinoma is the most common renal carcinoma subtype, constituting approximately 70–80% of cases. - It is associated with von Hippel–Lindau syndrome and characteristically contains clear or foamy cells because of lipid accumulation. Collecting duct type - Collecting duct carcinoma is not the usual predominant renal carcinoma subtype; it represents a much less common form than clear cell carcinoma. - The key distinguishing fact is that clear cell carcinoma accounts for approximately 70–80% of renal carcinomas, making collecting duct type an unsuitable answer. Papillary type - Papillary carcinoma accounts for approximately 10–15% of renal carcinomas, substantially less than the clear cell type. - Its characteristic papillary structures and distinct chromosomal mutation profile distinguish it from the more common clear cell carcinoma. Chromophobe type - Chromophobe carcinoma comprises approximately 5–10% of renal cell carcinomas, so it is less common than clear cell carcinoma. - Its pale cells with distinct borders and generally better prognosis distinguish it from the predominant clear cell type.

  5. 5. Which of the following is NOT a complication of nephrotic syndrome?

    • A. Hypoalbuminemia
    • B. Infection risk
    • C. Hypertension
    • D. Hypercoagulability
    Show answer

    Answer: A. Hypoalbuminemia

    Hypoalbuminemia - Hypoalbuminemia is a defining feature of nephrotic syndrome rather than a complication developing from it. - It results directly from massive urinary protein loss, which is central to the diagnosis of nephrotic syndrome. Infection risk - Infection risk is increased because urinary loss of immunoglobulins and complement factors impairs host defense. - This predisposition may manifest as peritonitis, cellulitis, or pneumonia in patients with nephrotic syndrome. Hypertension - Hypertension can complicate nephrotic syndrome through fluid retention, renin-angiotensin-aldosterone system activation, or underlying renal dysfunction. - It contributes to kidney disease progression and increases cardiovascular morbidity, making it a recognized complication. Hypercoagulability - Hypercoagulability develops from urinary loss of antithrombin III and other anticoagulant proteins, along with increased synthesis of prothrombotic factors. - This increases the risk of thromboembolic events, including deep vein thrombosis and pulmonary embolism.

  6. 6. A 19-year-old boy presents with a swollen lip and fractured maxillary central incisors following trauma. The encircled area in the radiograph shows:

    • A. Metallic foreign body
    • B. Dystrophic soft-tissue calcification
    • C. Fractured tooth fragment
    • D. Salivary duct calculus
    Show answer

    Answer: C. Fractured tooth fragment

    Fractured tooth fragment - A fractured incisor fragment can be displaced into the lip during dental trauma and appear as a radiopaque structure on soft-tissue radiography. - Identifying an embedded tooth fragment is important because it may require surgical removal to prevent infection and a foreign-body reaction. Salivary duct calculus - Salivary duct calculus usually occurs in major ducts such as Wharton’s or Stensen’s duct, rather than becoming embedded in lip tissue after trauma. - Sialolithiasis commonly causes gland swelling and pain during eating, findings not suggested by this patient’s acute dental injury and swollen lip. Metallic foreign body - Metallic foreign body can also produce a radiopaque soft-tissue opacity, but the tooth-like shape and associated fractured incisors favour a dental fragment. Dystrophic soft-tissue calcification - Dystrophic soft-tissue calcification involves calcium deposition in soft tissue from chronic irritation, not the immediate displacement of material after acute dental trauma. - This condition generally develops over months to years, whereas the sudden swollen lip and fractured teeth favor an embedded tooth fragment.

  7. 7. A 26-year-old male presents with abdominal pain and episodes of hematuria. His blood pressure is 160/100 mm Hg and is refractory to standard antihypertensive drugs. Renal Doppler shows a parvus tardus pattern. Which condition primarily causes hypertension through renal parenchymal disease rather than renal artery stenosis?

    • A. Systemic lupus erythematosus
    • B. Takayasu aortoarteritis
    • C. Fibromuscular dysplasia
    • D. Renal artery atherosclerosis
    Show answer

    Answer: A. Systemic lupus erythematosus

    Systemic lupus erythematosus - Systemic lupus erythematosus primarily causes glomerulonephritis and small-vessel disease rather than stenosis of the large or medium renal arteries. - SLE is therefore not typically a cause of renovascular hypertension through proximal renal artery narrowing or the associated parvus tardus waveform. Takayasu aortoarteritis - Takayasu aortoarteritis is a large-vessel vasculitis that can involve the renal arteries, causing inflammatory stenosis and renovascular hypertension. - Renal arterial narrowing from Takayasu aortoarteritis may produce downstream parvus tardus waveforms, particularly in young patients with systemic inflammatory features. Fibromuscular dysplasia - Fibromuscular dysplasia is a recognized cause of renal artery stenosis in young adults and classically produces a string-of-beads appearance on angiography. - Alternating stenoses and dilatations from medial fibroplasia can reduce renal perfusion and cause downstream parvus tardus waveforms. Renal artery atherosclerosis - Renal artery atherosclerosis commonly causes renal artery stenosis, typically involving the ostium, and can produce renovascular hypertension with downstream parvus tardus changes. - Although more common in patients over 50 years, atherosclerotic renal artery disease can occur in younger individuals with relevant vascular risk factors.

  8. 8. A patient presents with a renal mass leading to hematuria and flank pain. The histological image below is shown. What is the likely diagnosis?

    • A. Clear cell renal carcinoma
    • B. Chromophobe renal cell carcinoma
    • C. Collecting duct carcinoma
    • D. Papillary renal cell carcinoma
    Show answer

    Answer: A. Clear cell renal carcinoma

    Clear cell renal carcinoma - Clear cell carcinoma is the most common renal cell carcinoma and can present with hematuria, flank pain, and a palpable renal mass. - Its characteristic clear cytoplasm results from lipid and glycogen accumulation, with tumor cells often arranged in nests or cords around a rich vascular network. Papillary renal cell carcinoma - Papillary renal cell carcinoma shows papillary or tubulopapillary architecture with fibrovascular cores, rather than the clear-cell morphology described. - Its cells typically have basophilic cytoplasm, making it less consistent with the prominent clear cytoplasm associated with the diagnosis. Collecting duct carcinoma - Bellini duct carcinoma is a rare, aggressive tumor arising from the medullary collecting ducts, not the typical clear-cell subtype. - It usually demonstrates infiltrative growth and high-grade nuclear features, which are not described in the provided histological explanation. Chromophobe renal cell carcinoma Chromophobe renal cell carcinoma may contain pale reticulated or eosinophilic cells with prominent cell borders, perinuclear halos, and irregular wrinkled nuclei. The image instead shows clear-cell nests separated by a delicate capillary network, favouring clear cell renal carcinoma.

  9. 9. A 46-year-old chronic diabetic presents to the emergency department with high-grade fever and dysuria. Urine analysis reveals multiple leukocytes and glycosuria. A CT scan of the abdomen shows the following image. What is the most likely diagnosis?

    • A. Acute bacterial pyelonephritis
    • B. Renal abscess
    • C. Emphysematous pyelonephritis
    • D. Perinephric abscess
    Show answer

    Answer: C. Emphysematous pyelonephritis

    Emphysematous pyelonephritis - Gas within the renal parenchyma on CT, combined with high-grade infection in a chronic diabetic, is characteristic of emphysematous pyelonephritis. - Diabetes, fever, dysuria, and pyuria indicate a severe gas-forming renal infection, making this the most likely diagnosis. Acute bacterial pyelonephritis - Fever, dysuria, and pyuria are compatible with acute bacterial pyelonephritis, but these findings are nonspecific in severe urinary infection. - Acute bacterial pyelonephritis usually shows renal inflammation and edema without intraparenchymal gas, which distinguishes it from the diagnosis here. Renal abscess - A renal abscess is a localized pus collection within the renal parenchyma and typically appears as a low-attenuation lesion on CT. - The characteristic finding here is intraparenchymal gas, rather than a discrete fluid-filled abscess, making renal abscess less likely. Perinephric abscess - A perinephric abscess is a pus collection outside the renal capsule, within the tissues surrounding the kidney. - CT would be expected to show a perinephric fluid collection, not gas primarily located within the renal parenchyma.

  10. 10. Renal stones which are laminated and have an irregular, spiculated outline are

    • A. Calcium oxalate
    • B. Magnesium ammonium phosphate
    • C. Cystine
    • D. Uric acid
    Show answer

    Answer: A. Calcium oxalate

    Calcium oxalate - Calcium oxalate stones characteristically have a laminated, irregular, spiculated outline because of their crystalline structure. - Their calcium content makes them typically radio-opaque on X-rays, supporting this identification. Magnesium ammonium phosphate - Magnesium ammonium phosphate stones are associated with urease-producing bacteria and urinary tract infections rather than a laminated, irregular outline. - They may form large staghorn calculi and are often friable, filling the renal pelvis. Cystine - Cystine stones result from an inherited amino acid transport disorder, not the characteristic calcium oxalate crystalline pattern. - They are typically smooth and waxy, with characteristic hexagonal crystals, rather than irregular outlines. Uric acid - Uric acid stones are usually smooth and yellowish-brown, so they do not match the described laminated, irregular appearance. - They are typically radiolucent on standard X-rays and are associated with acidic urine or gout.

Flashcards: Renal and Urinary Tract Imaging

  1. 1. Investigation of choice in renal cell carcinoma to evaluate IVC and renal vein involvement is .

    Show answer

    MRI

  2. 2. What is the best diagnostic modality for diagnosis of Emphysematous Pyelonephritis?

    Show answer

    CT scan

  3. 3. Minimally complex, non malignant cysts, with septa <1mm, _____ calcifications, renal lesions <3 cm are classified as Bosniak stage _____

    Show answer

    thin · 2

  4. 4. _____ sign in _____ is seen due to edema around the kidney due to the involvement of _____ fat

    Show answer

    Renal halo · Acute Pancreatitis · paranephric

  5. 5. Acute _____ may be characterized by _____ parenchymal enhancement of the kidney on CT

    Show answer

    pyelonephritis · striated

  6. 6. Investigation of choice for urinary stones is

    Show answer

    non-contrast CT

  7. 7. Ball on tee, Forniceal excavation, Lobster claw and Signet ring signs are all seen in

    Show answer

    Renal papillary necrosis

  8. 8. The given image shows the presence of a _____ in lower end of esophagus.

    Show answer

    Schatzki’s ring

  9. 9. The given Retrograde ureterogram showing dilated clubbed calyces with stricture of the left ureteropelvic junction is suggestive of _____

    Show answer

    Hydronephrosis

  10. 10. In _____ sign or double wall sign, inner mucosal and outer serosal layers of bowel are enhanced in pneumoperitoneum

    Show answer

    Rigler's
