Pulmonary Circulation

On this page

Pulmonary Circulation - Lung's Low‑Pressure Lane

  • Pathway: Right Ventricle → Pulmonary Artery (deoxygenated blood) → Pulmonary Capillaries (gas exchange) → Pulmonary Veins (oxygenated blood) → Left Atrium.
  • Vessel Characteristics:
    • Pulmonary arteries: Thin-walled, larger diameter, less smooth muscle, high compliance compared to systemic arteries.
    • Pulmonary veins: Short, carry oxygenated blood back to the heart.
  • Hemodynamics:
    • Low-pressure system: Mean Pulmonary Artery Pressure (mPAP) $ \approx $ 15 mmHg (systemic circulation mean arterial pressure $ \approx $ 90-100 mmHg).
    • Low-resistance system: Pulmonary Vascular Resistance (PVR) $ \approx \frac{1}{10} $ Systemic Vascular Resistance (SVR).
    • High flow: Accommodates entire cardiac output (CO).

⭐ During exercise, pulmonary vascular resistance (PVR) normally decreases due to recruitment (opening of previously closed capillaries) and distension (widening of already open capillaries), allowing increased blood flow with only a slight rise in pulmonary arterial pressure. This protects the right ventricle from overload and prevents pulmonary edema.

Pulmonary Circulation - Gentle Flow Dynamics

  • Characterized by low pressure, low resistance, and high compliance, facilitating large blood volume passage.
  • Key Pressures:
    • Mean Pulmonary Artery Pressure (PAP): ~15 mmHg (Normal range: 9-18 mmHg).
    • Pulmonary Capillary Wedge Pressure (PCWP): 2-12 mmHg; reflects Left Atrial Pressure (LAP).
    • Mean Pulmonary Capillary Pressure: ~7 mmHg, crucial for Starling forces & fluid exchange.
  • Pulmonary Vascular Resistance (PVR):
    • Represents resistance to blood flow through pulmonary vasculature.
    • Formula: $PVR = (Mean PAP - PCWP) / CO$ (CO = Cardiac Output).
    • Normal: <2.5 Wood units (or <200 dynes.sec.cm⁻⁵).

⭐ Hypoxic Pulmonary Vasoconstriction (HPV) is a critical adaptive mechanism: alveolar hypoxia triggers localized pulmonary artery vasoconstriction, diverting blood from poorly ventilated to well-ventilated lung segments, thus optimizing ventilation/perfusion (V/Q) matching.

  • Major Factors Affecting PVR:
Loading diagram…

Pulmonary Circulation - Breath & Blood Harmony

  • Low pressure, high flow, low resistance; handles full Cardiac Output. Mean PAP ~15 mmHg.
  • Regulation:
    • Hypoxic Pulmonary Vasoconstriction (HPV): Low alveolar $O_2$ → arteriolar constriction → diverts blood, optimizes V/Q.
    • Others: NO (dilation), ET-1 (constriction).
  • V/Q Ratio (Ventilation/Perfusion): Normal ~0.8.
    • Apex: ↑V/Q (Zone 1).
    • Base: ↓V/Q (Zone 3).
  • West's Zones: (PA=Alveolar, Pa=Arterial, Pv=Venous pressure)
    • Zone 1: PA > Pa > Pv (Min. flow)
    • Zone 2: Pa > PA > Pv (Intermittent flow)
    • Zone 3: Pa > Pv > PA (Continuous, largest)
  • V/Q Mismatch & Effects:
Loading diagram…

⭐ Chronic hypoxia (e.g., high altitude, COPD) → sustained HPV → pulmonary HTN & RV hypertrophy.

Pulmonary Circulation - Traffic Control Lungs

  • Low pressure (~25/10 mmHg, mean ~15 mmHg), low resistance (1/10th of systemic).
  • Regulation:
    • Hypoxic Pulmonary Vasoconstriction (HPV): Key! Alveolar hypoxia ($P_{A}O_2$ < 70 mmHg) → local vasoconstriction.
      • Redirects blood to well-ventilated areas; optimizes $V/Q$ match.
    • Humoral: Vasoconstrictors (Endothelin, Thromboxane A2); Vasodilators (NO, Prostacyclin).
    • Neural: Minor role (Sympathetic α1-receptors: vasoconstriction; β2-receptors: vasodilation).
  • Pulmonary Vascular Resistance (PVR):
    • $PVR = (Mean P_{PA} - P_{LA}) / Cardiac Output$
    • ↑ by: Hypoxia, acidosis, hypercapnia, ↑ lung volumes (extremes), serotonin.
    • ↓ by: $O_2$, NO, prostacyclin, β-agonists, ↓ lung volumes (from high).
  • Shunts: Blood bypassing gas exchange.
    • Physiological: ~2-5% Cardiac Output (bronchial & Thebesian veins).
    • Pathological: ↑ in ARDS, pneumonia, atelectasis → hypoxemia.

⭐ HPV is significantly blunted by volatile anesthetics, sepsis, and certain vasodilators (e.g., nitroglycerin, CCBs).

High‑Yield Points - ⚡ Biggest Takeaways

  • Pulmonary circulation is a low-pressure, low-resistance system, distinct from systemic circulation.
  • Pulmonary artery carries deoxygenated blood to lungs; pulmonary veins carry oxygenated blood to the left atrium.
  • Hypoxic pulmonary vasoconstriction (HPV) optimizes V/Q matching by diverting blood from hypoxic alveoli.
  • PVR decreases with increased cardiac output (recruitment/distension) and at moderate lung volumes.
  • Normal mPAP is ~15 mmHg; pulmonary hypertension is mPAP >20 mmHg.
  • West's lung zones (1, 2, 3) describe gravity-dependent perfusion patterns.
  • PCWP estimates left atrial pressure and left ventricular end-diastolic pressure (LVEDP).

Unlock the full lesson and continue reading

Signup to continue reading this lesson and unlimited access questions, flashcards, AI notes, and more

Scan to download app

Scan to download
UNLOCK FREE ACCESS

Practice Questions: Pulmonary Circulation

  1. 1. What happens to gas exchange when the Va/Q ratio approaches infinity?

    • A. Increased exchange of both gases
    • B. Normal exchange of both gases
    • C. No exchange of either gas
    • D. Selective exchange of oxygen alone
    Show answer

    Answer: C. No exchange of either gas

    > Key point: As Va/Q approaches infinity, alveoli are ventilated but not perfused, so neither gas is exchanged. Why no exchange of either gas is correct - An infinitely high Va/Q ratio represents ventilation without perfusion. - Without blood flow, oxygen cannot enter blood and carbon dioxide cannot be delivered to the alveolus for exchange. Mechanism mermaid flowchart TD A[" Va/Q approaches infinity "]:::input --> B[" Ventilation without perfusion "]:::step B --> C[" No blood reaches alveolus "]:::step C --> D[" No exchange of either gas "]:::outcome Why the other options are wrong - Increased exchange of both gases: Without perfusing blood, neither gas can transfer between alveolus and blood. - Normal exchange of both gases: Normal gas exchange requires perfusion. - Selective exchange of oxygen alone: Oxygen transfer also requires perfusing blood.

  2. 2. Which test is most useful for initial evaluation of suspected pulmonary sarcoidosis?

    • A. Bronchoalveolar lavage (BAL)
    • B. Chest radiograph
    • C. Cutaneous skin biopsy
    • D. Serum ACE measurement
    Show answer

    Answer: B. Chest radiograph

    > Key point: Chest radiography is the most useful listed test for the initial evaluation of suspected pulmonary sarcoidosis. Why Chest radiograph is correct - It can reveal bilateral hilar lymphadenopathy and pulmonary infiltrates, making it useful for initial evaluation. - It is the best initial test among the listed choices. How they compare | Test | Role in this question | |---|---| | Chest radiograph | Initial evaluation; shows thoracic findings | | Bronchoalveolar lavage | Invasive adjunct; findings are not definitive | | Cutaneous skin biopsy | Tissue confirmation if a suspicious lesion is present | | Serum ACE measurement | Not sufficiently sensitive or specific as the primary test | Why the other options are wrong - Bronchoalveolar lavage (BAL): It is an invasive adjunct, not the initial investigation; its findings are not definitive. - Cutaneous skin biopsy: It may provide tissue confirmation when an accessible suspicious skin lesion is present, but none is described. - Serum ACE measurement: It lacks sufficient sensitivity and specificity to serve as the primary initial test.

  3. 3. The initiation of the first breath in a newborn is due to changes in which of the following parameters?

    • A. pH, PaO2, and PaN2
    • B. pH, PaN2, and PaCO2
    • C. PaN2, PaO2, and PaCO2
    • D. pH, PaO2, and PaCO2
    Show answer

    Answer: D. pH, PaO2, and PaCO2

    > Key point: The first breath is stimulated by changes in pH, PaO₂, and PaCO₂ as placental gas exchange stops. Why pH, PaO₂, and PaCO₂ is correct - After birth, interruption of placental gas exchange leads to rising PaCO₂ and acidosis, while falling PaO₂ also contributes to respiratory stimulation. Mechanism mermaid flowchart TD A[" Placental gas exchange stops "]:::input --> B[" Blood-gas changes pH, PaO₂, and PaCO₂ change "]:::step B --> C[" Respiratory drive rises "]:::step C --> D[" First breath "]:::outcome Why the other options are wrong - pH, PaO₂, and PaN₂: PaN₂ replaces PaCO₂, omitting the rise in carbon dioxide that contributes to respiratory stimulation. - pH, PaN₂, and PaCO₂: PaN₂ replaces PaO₂, omitting the contribution of falling oxygen tension. - PaN₂, PaO₂, and PaCO₂: PaN₂ replaces pH, omitting the contribution of acidosis.

  4. 4. The CT chest shows presence of:

    • A. Pulmonary embolism
    • B. Alveolar proteinosis
    • C. Bronchiectasis
    • D. Aspergillosis
    Show answer

    Answer: C. Bronchiectasis

    > Key point: Dilated, thick-walled bronchi with cystic airway changes indicate bronchiectasis. Why Bronchiectasis is correct - The CT description includes bilateral dilated, thick-walled bronchi and cystic bronchial dilatation. - Airways larger than their accompanying pulmonary arteries support bronchiectasis. Why the other options are wrong - Pulmonary embolism: This is identified by filling defects in pulmonary arteries, not dilated airways. - Aspergillosis: It may cause nodules, cavitation, an aspergilloma, or mucoid impaction; the described diffuse cystic bronchial dilatation points to bronchiectasis. - Alveolar proteinosis: Its described CT pattern is ground-glass opacity with septal thickening, rather than dilated thick-walled bronchi.

  5. 5. A 15-year-old patient presents with joint swelling, a pan-systolic murmur, negative rheumatoid factor (RF), and elevated ESR. The patient also reports a recent history of sore throat and exhibits subcutaneous nodules and erythema marginatum on physical examination. What is the most likely diagnosis?

    • A. Acute rheumatic fever
    • B. Seronegative rheumatoid arthritis
    • C. Juvenile idiopathic arthritis
    • D. Ankylosing spondylitis
    Show answer

    Answer: A. Acute rheumatic fever

    > Key point: Joint swelling with erythema marginatum, subcutaneous nodules, and a murmur after a sore throat points to acute rheumatic fever. Why Acute rheumatic fever is correct - The recent sore throat followed by joint swelling and a pansystolic murmur supports a post-streptococcal rheumatic illness with cardiac involvement. - Erythema marginatum and subcutaneous nodules are characteristic manifestations that strongly favor acute rheumatic fever; elevated ESR supports inflammation. Clues in the question | Clue | What it points to | |---|---| | “recent history of sore throat” | Preceding pharyngeal illness | | “subcutaneous nodules and erythema marginatum” | Characteristic rheumatic manifestations | | “joint swelling” and “a pan-systolic murmur” | Joint and cardiac involvement | Why the other options are wrong - Seronegative rheumatoid arthritis: A negative RF does not explain the characteristic skin findings and post-sore-throat cardiac presentation. - Juvenile idiopathic arthritis: It can cause joint swelling and elevated ESR, but the rheumatic skin findings and murmur favor acute rheumatic fever. - Ankylosing spondylitis: It primarily affects the axial skeleton and does not fit the acute post-sore-throat pattern with these skin and cardiac findings.

  6. 6. The spirogram uses maximal expiration as its zero-volume reference; residual volume remains in the lungs. Which lung volume or capacity does the arrow indicate?

    • A. TV
    • B. TLC
    • C. ERV
    • D. VC
    Show answer

    Answer: D. VC

    > Key point: Vital capacity is the exhalable volume from maximal inspiration to maximal expiration; residual volume remains in the lungs. Why VC is correct - The arrow spans the full excursion between maximal inspiration and maximal expiration. - That excursion is VC = IRV + TV + ERV; it does not include residual volume. How they compare | Choice | What it represents | |---|---| | VC | Maximal inspiration to maximal expiration | | TV | Small excursion during quiet breathing | | TLC | Absolute lung volume at maximal inspiration, including residual volume | | ERV | End of normal expiration to maximal expiration | Why the other options are wrong - TV: It is only the small quiet-breathing excursion, not the full arrow. - TLC: It includes residual volume and represents the volume at maximal inspiration. - ERV: It covers only the portion from normal expiration to maximal expiration.

  7. 7. Regarding Caisson's disease which statement among the following is CORRECT?

    • A. HPNS prevention by heliox
    • B. Tremors from nitrogen narcosis
    • C. Pulmonary barotrauma from air embolism
    • D. Joint pain from nitrogen bubbles
    Show answer

    Answer: D. Joint pain from nitrogen bubbles

    > Key point: Caisson’s disease causes joint pain when nitrogen bubbles form during decompression. Why Joint pain from nitrogen bubbles is correct - Rapid decompression lets dissolved nitrogen form bubbles in tissues and blood. - Bubbles in or around joints cause the characteristic pain known as “the bends.” How they compare | Statement | Condition or effect | Why it fits or fails | |---|---|---| | Joint pain from nitrogen bubbles | Caisson’s disease | Decompression bubbles cause joint pain | | Pulmonary barotrauma from air embolism | Arterial gas embolism | A distinct complication of ascent, not the typical cause of caisson’s disease | | Tremors from nitrogen narcosis | Nitrogen narcosis | Narcosis causes intoxication-like changes; tremors are more characteristic of HPNS | | HPNS prevention by heliox | HPNS | Heliox alone does not reliably prevent it; adding a small amount of nitrogen or another narcotic gas may mitigate it | Why the other options are wrong - Pulmonary barotrauma from air embolism: This describes a distinct ascent complication, not the characteristic mechanism of caisson’s disease. - Tremors from nitrogen narcosis: This assigns tremors to the wrong condition; they are more characteristic of HPNS. - HPNS prevention by heliox: Heliox alone does not reliably prevent HPNS.

  8. 8. Holding one's breath after hyperventilating for some time can be accompanied by carpopedal spasm chiefly because of:

    • A. Hypercapnia-induced respiratory depression
    • B. Increased haemoglobin oxygen affinity
    • C. Alkalosis-induced tetany
    • D. Hypocapnia-delayed respiratory drive
    Show answer

    Answer: C. Alkalosis-induced tetany

    > Key point: Hyperventilation can cause respiratory alkalosis, lowering ionized calcium and triggering tetany. Why alkalosis-induced tetany is correct - Hyperventilation lowers carbon dioxide, causing respiratory alkalosis. - Alkalosis increases calcium binding to albumin, reducing ionized calcium and increasing neuromuscular excitability; this can cause carpopedal spasm. Mechanism mermaid flowchart TD A[" Hyperventilation Carbon dioxide falls "]:::input --> B[" Respiratory alkalosis "]:::step B --> C[" More calcium binds albumin "]:::step C --> D[" Ionized calcium falls "]:::step D --> E[" Carpopedal spasm Tetany from excitability "]:::outcome Why the other options are wrong - Hypercapnia-induced respiratory depression: Hyperventilation lowers carbon dioxide rather than causing hypercapnia; this does not explain the spasm. - Increased haemoglobin oxygen affinity: This may occur with alkalosis, but it does not account for carpopedal spasm. - Hypocapnia-delayed respiratory drive: This may affect breathing during breath-holding, but it does not explain the spasm.

  9. 9. During heavy exercise the cardiac output (CO) increases up to five fold while pulmonary arterial pressure rises very little. This physiological ability of the pulmonary circulation is best explained by

    • A. Large amount of smooth muscle in pulmonary arterioles
    • B. Increase in the number of open capillaries
    • C. Sympathetically mediated greater distensibility of pulmonary vessels
    • D. Smaller surface area of pulmonary circulation
    Show answer

    Answer: B. Increase in the number of open capillaries

    Increase in the number of open capillaries - Heavy exercise recruits previously closed pulmonary capillaries, increasing the vascular channels available for the marked rise in cardiac output. - Recruitment, together with distension of existing capillaries, lowers pulmonary vascular resistance and permits increased flow without a substantial pressure rise. Sympathetically mediated greater distensibility of pulmonary vessels - Pulmonary vessels have limited sympathetic innervation, so sympathetic activation does not substantially increase their distensibility during exercise. - The fall in pulmonary vascular resistance is mainly caused by capillary recruitment and distension, rather than neurogenic control of vessel compliance. Smaller surface area of pulmonary circulation - The pulmonary circulation has a vast capillary surface area, supporting efficient gas exchange and accommodating increased blood flow. - A smaller surface area would produce higher vascular resistance, causing pulmonary arterial pressure to rise more substantially during exercise. Large amount of smooth muscle in pulmonary arterioles - Pulmonary arterioles contain relatively little smooth muscle and are a low-resistance, high-capacitance vascular bed. - Their smooth muscle mainly regulates regional blood flow and hypoxic responses, rather than accommodating the large increase in total flow during exercise.

  10. 10. An infant presents with LVH and pulmonary complications. ECG shows left axis deviation. The most likely diagnosis is:

    • A. Tricuspid atresia
    • B. TAPVC
    • C. VSD
    • D. TGA
    Show answer

    Answer: A. Tricuspid atresia

    Tricuspid atresia - Left ventricular hypertrophy (LVH) is common because the left ventricle must pump blood to both the systemic and pulmonary circulations through a ventricular septal defect (VSD) and/or patent ductus arteriosus (PDA). - Left axis deviation on ECG is characteristic of tricuspid atresia due to the hypoplasia or absence of the right ventricle and the dominance of the left ventricle. TAPVC - Total anomalous pulmonary venous connection (TAPVC) typically presents with right ventricular hypertrophy and right axis deviation on ECG, as the right ventricle handles the entire systemic venous return. - Pulmonary complications are common, but the cardiac structural changes and ECG findings differentiate it from tricuspid atresia. VSD - A ventricular septal defect (VSD) alone would typically cause right ventricular hypertrophy or biventricular hypertrophy depending on the size and shunt direction. - While a large VSD can cause pulmonary hypertension and complications, it usually does not present with isolated LVH and left axis deviation without other associated anomalies. TGA - Transposition of the great arteries (TGA) typically presents with right ventricular hypertrophy and right axis deviation on ECG, as the RV functions as the systemic ventricle. - While cyanosis and pulmonary complications occur, the ECG pattern shows RVH, not LVH with left axis deviation.

Flashcards: Pulmonary Circulation

  1. 1. In zone _____ of the lung, blood flow (Q) is _____

    Show answer

    3 (base) · highest

  2. 2. The _____ of a respiratory system pressure-volume curve represents lung _____

    Show answer

    slope · compliance

  3. 3. In zone 2 of the lung, blood flow is driven by the difference between _____ and _____ pressure

    Show answer

    arteriolar · alveolar

  4. 4. The two sources of the physiologic shunt are _____ blood flow and a small portion of _____ venous blood (drains into the left ventricle via the thebesian vein)

    Show answer

    bronchial · coronary

  5. 5. Water fall effect has been used to describe the blood flow in the  portion of lung.

    Show answer

    middle

  6. 6. The graph given below shows _____ _____thoracic obstruction

    Show answer

    variable · intra

  7. 7. The graph given depicts the _____ effect

    Show answer

    Haldane

  8. 8. The alveolar gas equation states that the alveolar PO2 (PAO2) equals:

    Show answer

    PAO2 = PIO2 – (PaCO2 / R) (PIO2 = FiO2 × [Patm – PH2O])

  9. 9. The _____ is used to determine physiologic dead space ($VD$).

    Show answer

    Bohr equation — Formula: $VD = VT \times \frac{PaCO2 - PeCO2}{PaCO2}$ Mnemonic: Taco Paco Peco ($VT$, $PaCO2$, $PeCO2$)

  10. 10. What type of upper airway obstruction is depicted by the following flow-volume loop? _____

    Show answer

    Variable intrathoracic obstruction
