Polysomnography - Sleep Study Secrets

  • Polysomnography (PSG) is a comprehensive, multi-parametric test that records various physiological variables during sleep. 📌 PSG: Patient Sleep Graphed.
  • Primary Goals:
    • Diagnose Obstructive Sleep Apnea (OSA) and assess its severity.
    • Differentiate central, obstructive, and mixed apneas.
    • Evaluate other sleep disorders (e.g., narcolepsy, periodic limb movement disorder).

⭐ Polysomnography is the gold standard for the diagnosis of Obstructive Sleep Apnea (OSA).

Polysomnography - Sensor Central Station

📌 SEE Cardio-Respiratory Activity: Sensors (EEG, EOG, EMG), Cardiac (ECG), Respiratory (Airflow, Effort, SpO2), Additional (Snoring, Position).

Sensor/ChannelParameter MeasuredClinical Significance (OSA/SDB)
Electroencephalogram (EEG)Brain activitySleep staging; arousals
Electrooculogram (EOG)Eye movementsREM sleep identification
Electromyogram (EMG) - ChinChin muscle activityMuscle atonia (REM); bruxism
Electromyogram (EMG) - LimbsLimb muscle activityPeriodic Limb Movements (PLMS)
Electrocardiogram (ECG)Heart rate/rhythmArrhythmias; event-related HR changes
Nasal/Oral Airflow (Thermistor/Pressure)AirflowApneas/hypopneas detection
Thoracic & Abdominal Effort (RIP)Respiratory movementsDifferentiates central vs. obstructive events
Pulse Oximetry (SpO2)Oxygen saturationOxygen desaturation with events
Snoring Sensor (Microphone)SnoringUpper airway resistance indicator
Body Position SensorSupine, prone, lateralPositional OSA/SDB identification

⭐ Chin EMG demonstrating muscle atonia is a key feature for identifying REM sleep.

Polysomnography - Decoding Dream Data

Polysomnography (PSG) records multiple physiological parameters during sleep to diagnose sleep disorders.

  • Sleep Staging (AASM Criteria):
    • NREM Sleep: N1, N2, N3 (Slow Wave Sleep).
    • REM Sleep.
    • Key parameters: EEG (brain activity), EOG (eye movements), EMG (muscle tone).
  • Respiratory Event Definitions:
    • Apnea: Cessation of airflow ≥90% for ≥10s. Types: Obstructive, Central, Mixed.
    • Hypopnea: Airflow reduction ≥30% for ≥10s associated with ≥3% O2 desaturation or an arousal.
  • Key Indices:
    • Apnea-Hypopnea Index (AHI): $AHI = \frac{\text{Total Apneas + Total Hypopneas}}{\text{Total Sleep Time (hours)}}$
    • Respiratory Disturbance Index (RDI)
    • Oxygen Desaturation Index (ODI)
    • Arousal Index
  • OSA Severity (AHI): 📌 5 (Normal limit), 15 (Mild ends), 30 (Moderate ends). Thresholds: Normal <5/hr; Mild 5-14.9/hr; Moderate 15-29.9/hr; Severe ≥30/hr.

⭐ An obstructive apnea is defined by continued or increased respiratory effort despite airflow cessation, distinguishing it from central apnea where effort is absent.

Polysomnography data: apnea & blood pressure

📌 PSG Types: Type I is In-Lab, the Ideal standard. As numbers go up (II, III, IV), comprehensiveness typically goes down.

TypeSettingKey Channels MonitoredAttended?Primary UseAdvantagesDisadvantages
IIn-LaboratoryEEG, EOG, EMG, ECG, Airflow, Effort, SpO2, Snoring, Leg movementsYesGold standard; Complex sleep disorders, CPAP titrationHighest accuracy, comprehensive dataCostly, inconvenient, less natural sleep
IIHome (Unattended)Similar to Type INoOSA diagnosis, CPAP titration in select casesComprehensive data at homeLess accurate than Type I, no direct observation
IIIHome (Unattended)≥3 channels (e.g., Airflow, Effort, SpO2, HR)NoUncomplicated OSA diagnosisConvenient, lower costLimited data, may miss other disorders, higher failure rate
IVHome (Unattended)1-2 channels (e.g., SpO2 ± Airflow/HR)NoScreening for OSA, oximetryVery convenient, lowest costLowest accuracy, high false negative rate

High‑Yield Points - ⚡ Biggest Takeaways

  • Polysomnography (PSG) is the gold standard for diagnosing Obstructive Sleep Apnea (OSA).
  • Key parameters include EEG, EOG, EMG, ECG, airflow, respiratory effort, and SaO2.
  • Apnea-Hypopnea Index (AHI) quantifies OSA severity: Mild (5-15), Moderate (15-30), Severe (>30 events/hr).
  • Differentiates obstructive, central, and mixed apneas.
  • Assesses sleep architecture, including sleep stages and arousals.
  • Oxygen Desaturation Index (ODI) is also a critical measure of nocturnal hypoxemia related to OSA events.
